P.I.P.-XOV
Programmable Input Processor
REFERENCE
Obtaining Other Language Versions: To obtain information in another language about
the use of this product, please contact your local Crown Distributor. If you need assis-
tance locating your local distributor, please contact Crown at 574-294-8000.
This manual does not include all of the details of design, production, or variations of
the equipment. Nor does it cover every possible situation which may arise during in-
stallation, operation or maintenance.
The information provided in this manual was deemed accurate as of the publication
date. However, updates to this information may have occurred. To obtain the latest
version of this manual, please visit the Crown website at www.crownaudio.com.
Trademark Notice: PIP and PIP2 are trademarks and Crown, Macro-Tech , Com-Tech ,
IOC and P.I.P. are registered trademarks of Crown International. Other trademarks are
the property of their respective owners.
©2002 by Crown Audio, Inc. P.O. Box 1000, Elkhart, Indiana 46515-1000 U.S.A.
MANUAL
Telephone: 574-294-8000
125975-2
2/02
