Equipment must be correctly mounted so that the main terminal of AnyTouch will not be touched inadvertently.
Otherwise, an accident or electric shock may occur.
Tighten the fixtures of the AnyTouch with a torque in the specified range. Excessive tightening may distort the panel
surface. Loose tightening may cause AnyTouch to come off, malfunction or be short-circuited.
Check periodically that terminal screws on the power supply terminal block and fixtures are firmly tightened.
Loosened screws may result in fire or malfunction.
Tighten terminal screws on the power supply terminal block equally to a torque of 0.5 N m. Improper tightening of
screws may result in fire, malfunction, or trouble.
AnyTouch has a glass screen. Do not drop or give physical shock to the unit. Otherwise, the screen may be
damaged.
Connect the cables correctly to the terminals of AnyTouch in accordance with the specified voltage and wattage.
Over-voltage, over-wattage or incorrect cable connection could cause fire, malfunction or damage to the unit.
Be sure to establish a ground of AnyTouch. Ground FG terminal which must be used for the unit. Otherwise, electric
shock or a fire may occur.
Prevent any conductive particles from entering into AnyTouch. Failure to do so may lead to fire, damage or
malfunction.
After wiring is finished, remove the paper used as a dust cover before starting to operate AnyTouch. Operation with
the cover attached may result in accident, fire, malfunction, or trouble.
Do not attempt to repair, disassemble or modify AnyTouch at your site. Ask RS Automation Co., Ltd. or the designated
contractor for repair. Otherwise, it may cause a malfunction.
RS Automation Co., Ltd. is not responsible for any damages resulting from repair, overhaul or modification of
AnyTouch that was performed by an unauthorized person.
Do not use a sharp-pointed tool when pressing a touch switch. Doing so may damage the screen.
Only experts are authorized to set up the unit, connect the cables or perform maintenance and inspection.
For AnyTouch using a lithium battery, handle the battery with care. The combustible materials such as lithium or
organic solvent contained in the battery may generate heat, explode, or catch fire, resulting in personal injury or fire.
Read related manuals carefully and handle the lithium battery correctly as instructed.
When using a AnyTouch that has analog switch resolution with resistance film, do not press two or more points on the
screen at the same time. If there is a switch between the two pressed points, it may be activated.
Take safety precautions during such operations as setting change during running, forced output, start, and stop. Any
misoperation may cause unexpected machine motions, resulting in machine accident or damage.
In facilities where a failure of AnyTouch could lead to accident threatening human life or other serious damage, be
sure that the facilities are equipped with adequate safeguards.
At the time of disposal, AnyTouch must be treated as industrial waste.
Before touching AnyTouch, discharge static electricity from your body by touching grounded metal. Excessive static
electricity may cause malfunction or trouble.
UL/c-UL Approval
The V710TD+/V710iTD+/V710SD+/V710iSD+/V710CD+ are UL/cUL-approved.
(File No. : E256956(UL60950-1))
These types conform to the following standards.
・UL60950-1
・CSA-C22.2 No. 60950-1
Information Technology Equipment - Safety - Part 1: General Requirements
Information Technology Equipment - Safety - Part 1
