V606e+ OPERATING INSTRUCTIONS
Make sure that the delivered unit conforms to your requirement, and also check for any missing or damaged parts.
Before using this V606e+, be sure to read this OPERATING INSTRUCTIONS thoroughly to ensure proper operation.
[Accessories]
V606e+ OPERATING INSTRUCTIONS 1 copy
Fixtures 4 pcs
[Models]
Notes on Safe Usage
In this "V606e+ OPERATING INSTRUCTIONS", you will find various notes categorized under the following two levels with
the signal words "Danger" and "Caution."
Indicates an imminently hazardous situation which, if not avoided, will result in death or serious
injury.
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate
injury and could cause property damage.
Even some items indicated
○Never use the output function of AnyTouch such as the touch switch for an emergency switch because it could
threaten a human life or break a part of the unit. Please design the system of the unit in order to respond to a
malfunction of the touch switch. A malfunction of the touch switch will result in machine accident or damage.
○Turn off the power supply when you set up the system, connect the cables, maintaining or checking, otherwise you
will get an electric shock or damage the unit.
○Never touch the terminals while the power supply is on, otherwise you will get an electric shock.
○You must put the cover of the terminals on the unit when you turn on the power and operate it.
○The liquid (liquid crystal) on the liquid crystal display is harmful. If it has been damaged, it must not get into the
mouth. If the skin or clothes are stained with in, rinse them with soapy water.
○For AnyTouch using a lithium battery, never disassemble, recharge, deform by pressure, short-circuit, nor reverse the
polarity of the battery, and never dispose of the battery in fire.Failure to follow these conditions will lead to explosion
or ignition.
○For AnyTouch using a lithium battery, never use a battery that is deformed, leaks, or shows any other signs of
abnormality. Failure to follow these conditions will lead to explosion or ignition.
○Do not use the unit found damaged or deformed when unpacked. Otherwise, it could cause fire, malfunction or
trouble.
○For use in a facility or for a system related to nuclear energy, aerospace, medical, traffic equipment, or mobile
installations, please consult your local distributor.
○Operate AnyTouch under the conditions indicated by OPERATING INSTRUCTIONS or relevant manual. If you
do not set the conditions indicated by the manual for the unit, it could cause fire, malfunction, physical damage or
deterioration.
V6 0 6 e 0
(Comply with CE/UL/cUL)
may also result in a serious accident.
1
1: Standard model (For V606eM+ only)
2: SRAM/Built-in clock function
C: STN color LCD (16 colors)
M: STN monochrome LCD (Monochrome 8-grade)
