- Page 1 ASSEMBLY GUIDE GUIDE DE MONTAGE GUÍA DE MONTAJE Kingsley Arbor Kingsley Tonnelle Kingsley Cenador VA68094 VER 1.6 01/20/21...
- Page 2 PHILIPS #2 1-844-880-8482 hello@wearevita.com 8:00 AM - 5:00 PM EST WWW.WEAREVITA.COM...
-
Page 3: Parts List
PARTS LIST LISTE DES PIÈCES LISTA DE PARTES 10600 - COUPLER - COUPLEUR - ACOPLADOR 1 1/2” x 1 1/2” (3.8 CM x 3.8 CM) - 10601 - ARCH - ARCADE - ARCO 1 1/2” x 1 1/2” (3.8 CM x 3.8 CM) - 11085 - LEFT POST - POSTE LAISSÉ... - Page 4 PARTS LIST LISTE DES PIÈCES LISTA DE PARTES 11088 - VERTICLE SPOKE - RAYON VERTICAL - RAYO VERTICAL 49 5/8” (126.1 CM) - 10845 - GROUND STAKES - PIQUETS DE TERRE - ESTACAS DE TIERRA 16” (40.6 CM) - 11195 - MIDDLE RAILS - RAILS MOYENS - RIELES MEDIOS 22 5/8”...
-
Page 5: Product Dimensions
PRODUCT DIMENSIONS DIMENSIONS DU PRODUIT DIMENSIONES DEL PRODUCTO 81 1/2” (207 CM) 63 5/8” (161.6 CM) 8 1/2” 20” (21.6 CM) (50.8 CM) 36 1/8” (91.7 CM) 23” (58.4 CM) 39 1/8” (99.3 CM) - Page 6 R-10601 - x4 10600 - x6 20066 - x16 PHILIPS #2 10602 - x6...
- Page 7 11195 - x8 11196 - x2 11085 - x2 10910 - x2 11088 - x4...
- Page 8 11086 - x2 20066 - x16 PHILIPS #2...
- Page 9 20066 - x8 PHILIPS #2...
- Page 10 10646-1 - x4 10845 - x4...
- Page 11 20066 - x8 PHILIPS #2...
- Page 12 Permanent Installation For a permanent installation, measure four 8in (20.3cm) holes in diameter, 37 1/2in (95.25cm) apart by 21 1/2in apart (54.61cm), from center to center. Dig each hole 14in (36cm) deep. Fill excavated holes with mixed concrete 37 1/2in and carefully lift arbor 21 1/2in (95.25cm)
