A S S E M B LY I N S T R U C T I O N S
Beneficial Garden Bed
Please read through before starting assembly.
Check Box for These Contents
In the event of missing or defective parts please call our customer service dept. at 1 800 282 9346 (Mon. to Fri. 8:00 AM to 4:00 PM EST).
1. Wall Boards - A (4) - 7/8" x 11" x 20"
2. Wall Boards - B (5) - 7/8" x 11" x 44"
3. Wall Boards - C (10) - 7/8" x 7 3/8" x 20"
4. Wall Boards - D (5) - 7/8" x 7 3/8" x 44"
5. Posts - A (6) - 3" x 3" x 15 1/2"
6. Posts - B (6) - 3" x 3" x 12"
7. Posts - C (2) - 3" x 3" x 8 1/2"
8. Post Caps (14)
9. 2-1/2" Self-Auguring Stainless Steel Screws (96)
General Information
• Read Instructions through carefully before beginning assembly.
• When assembling components, place on a non-abrasive surface
(i.e. shipping box) to avoid scratching.
• We recommend an area approx 8'x 8' for unobstructed assembling.
• You should not need to use excessive force when assembling components.
45 in
6
1
8
2
7
4
45 in
45 in
4
2
3
9
Not To Scale
Ver 1.0/121515
21 in
21 in
21 in
21 in
14 5/8 in
11 in
5
2
1
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for vita Beneficial Garden
Summary of Contents for vita Beneficial Garden
-
Page 1: General Information
A S S E M B LY I N S T R U C T I O N S Beneficial Garden Bed 45 in 45 in 45 in 21 in 21 in 21 in 21 in 14 5/8 in 11 in Please read through before starting assembly. - Page 2 S T E P O N E Garden Bed Assembly 7 3/8” x 44” Board Insert two Wall Boards “D” between two Posts “A” as shown. Add four more Wall Boards “C” between two more Posts “A” as shown. 15 1/2” Post Fasten the Wall Boards to the Posts using the screws provided.
- Page 3 S T E P T W O Garden Bed Assembly Insert two Wall Boards “A” between two Posts “B” as shown. Add one more Wall Board “B” between the Posts “B” as shown. Fasten the Wall Boards to the Posts using the screws provided. Drive the screws from the inside of the garden bed.
- Page 4 S T E P T H R E E Garden Bed Assembly Insert two Wall Boards “C” between two Posts “C” as shown. Add one more Wall Boards “D” between the Posts “C” as shown. Fasten the Wall Boards to the Posts using the screws provided. Drive the screws from the inside of the garden bed.
- Page 5 S T E P F O U R Garden Bed Assembly Insert two Wall Boards “B” between two Posts “B” as shown. Add one more Wall Board “A” between the two Posts “B” as shown. Fasten the Wall Boards to the Posts using the screws provided. Drive the screws from the inside of the garden bed.
- Page 6 S T E P F I V E Garden Bed Assembly Insert two Wall Boards “B” between two Posts “B” as shown. Add one more Wall Board “A” between the two Posts “B” as shown. Fasten the Wall Boards to the Posts using the screws provided. Drive the screws from the inside of the garden bed.
- Page 7 S T E P S I X Garden Bed Installation Insert the post caps as shown. B e n e c i a l G a r d e n B e d I n s t r u c t i o n s...
