- Page 1 汪凯阁 2020.10.13 TF160LWE 16131000A40475 （CE-BD160-S） 魏赛 scale 曾磊 尺寸：16K,16P。 1、 2、 3、 4、 自首单更改技术要求 2020.11.19 汪凯阁...
- Page 2 TF160LWE 55cm SINGLE DOOR TALL FREEZER Instruction Manual Please read these instructions carefully before use and retain for future reference. Before switching on your appliance – Always check for any damage that may have been caused in transit.
-
Page 3: Table Of Contents
CONTENTS Safety Instructions ............. 3-4 Appliance Overview ............5 Specification ..............6 Installation ..............6-9 Operating Instructions ..........10 Cleaning & Maintenance ..........11 Troubleshooting ............12 Fuse Replacement ............13 Disposal Information ...........13... -
Page 4: Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read and follow all of the instructions even if you feel you are familiar with the product, and find a place to keep this manual handy for future reference. Important: This product is intended for domestic use only; to store and freeze food products only. - Page 5 WARNING: The appliance is heavy and care is needed when unpacking and moving it. Get extra help and only hold the appliance by the casing – never hold by the door or the trim. WARNING: Risk of child entrapment. WARNING: Risk of fire / flammable materials. • When positioning the appliance, ensure the supply cord is not trapped or damaged.
-
Page 6: Appliance Overview
APPLIANCE OVERVIEW... -
Page 7: Specification
SPECIFICATIONS Model TF160LWE Product Dimensions (mm) H 1420 x W 550 x D 550 Frozen Food Storage Volume 160L Climate Class ST/N Energy Consumption 235 (kWh/24h) Airbourne Acoustical Noise 42dB Energy Rating Freezing Capacity 7.2kg/24h Rated Voltage 220-240V~... - Page 8 2. Remove the screws from the fixed top-hinge with cross-slot screwdriver. Screws 3. Replace the top-hinge and the top-door limit block and the door bearing bush to the other side. A. Remove the nut with sleeve. Take off the washer then remove the axes to the other side and fixed. B. Remove the door limit block C. Please taking out another door limit block, with screw mounting to the door 4. Disassemble the screws fixed to the bottom-hinge with cross-slot screwdriver.
- Page 9 Screws fixed to bottom hinge Note: The freezer incline angle less 45°. 5. Replace the bottom hinge to the other side then fix it with screws. 6. Set the door to the right position, fix the mid-hinge. 7. Replace the top-hinge. 8. Set the top door to the right position, fix the top-hinge and the cover.
- Page 10 9. Replace the leveler to the other side and adjust it to make sure the cabinet is level. Door Space Requirements The unit’s door must be able to open fully as shown. W×D≥902 ×1052mm Levelling the Unit To do this adjust the two levelling feet at the front of the unit. If the unit is not level, the door and magnetic seal alignments will not be covered properly. Make sure that the foot touches the ground before use. Look down from the top, turn clockwise to loosen, anti-clockwise to tighten.
-
Page 11: Operating Instructions
OPERATING INSTRUCTIONS Switching On Your Unit • The temperature selector knob is located on the top middle of the freezer interior. Setting “Min”: Less Cool Temperature Setting “Med”: Normal Operation (adequate for most situations) Setting “Max”: Coolest Temperature • During high ambient temperatures e.g. On hot summer days. It may be necessary to set the Thermostat to the Coolest setting (position“Max”).This may cause the compressor running continuously in order to maintain a low temperature in the cabinet. • For the first time you install your freezer, set the thermostat knob at “Med”. -
Page 12: Cleaning & Maintenance
CLEANING & MAINTENANCE Cleaning the Interior and the Exterior of the Unit • Dusts behind the refrigerator and on the ground shall be timely cleaned to improve the cooling effect and energy saving. • The interior of the refrigerator should be cleaned regularly to avoid odor. • Check the door gasket regularly to make sure there are no debris. -
Page 13: Troubleshooting
TROUBLESHOOTING If your refrigerator is not working properly, it may be a minor problem, therefore check the following. The appliance does not operate, Check if; • There is a power failure, • The mains plug is not properly plugged in, or is loose • The thermostat setting is on position “0”, • The socket is defective. To check this, plug in another appliance that you know which is working into the same socket. The appliance performs poorly; Check if; • You have overloaded the appliance, • The doors are not closed perfectly, • There are not enough ventilation ducts on the kitchen unit as mentioned in the... -
Page 14: Fuse Replacement
FUSE REPLACEMENT Fuse Cover Fuse Replacement (Class I) This appliance must be eathed. Remove the fuse cover with a small flat head screw driver. Take out the fuse and replace with a new fuse of the same Amp. Replace the fuse cover and push back into place. DISPOSAL The European Directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), requires that old household electrical appliances must not be disposed of in normal unsorted municipal waste. Old appliances must be collected separately in order to optimise the recovery and recycling of the materials they contain and reduce the impact on human health and the environment. - Page 17 38 Bluestem Road, Ransomes Europark Ipswich, IP3 9RR 0844 848 5861...
