STATESMAN TF160LW User/Installer Instruction Booklet

Single door tall freezer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER / INSTALLER INSTRUCTION
BOOKLET
Please read the instructions before using the appliance
TF160LW - 55cm
Single Door Tall Freezer
Record Serial Number Here

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TF160LW and is the answer not in the manual?

Questions and answers

Related Manuals for STATESMAN TF160LW

Summary of Contents for STATESMAN TF160LW

  • Page 1 USER / INSTALLER INSTRUCTION BOOKLET Please read the instructions before using the appliance TF160LW - 55cm Single Door Tall Freezer Record Serial Number Here...

  • Page 2: Table Of Contents

    Contents SAFETY WARNINGS ......................1 INSTALLATION ........................2 Location ........................2 Reversing the Door Swing ..................2-5 Door Space Requirements ..................6 Levelling the Unit ....................... 6 Cleaning Before Use ....................6 Before Using Your Unit .................... 6-7 Interior Accessories ....................7 PRODUCT OVERVIEW ......................

  • Page 3: Safety Warnings

    1. SAFETY WARNINGS WARNING―Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING―Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. WARNING―Do not damage the refrigerant circuit. 4) WARNING―Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

  • Page 4: Installation

    2. INSTALLATION 2.1 Location When selecting a position for your unit you should make sure the floor is flat and firm, and the room is well ventilated. Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the electrical consumption.
  • Page 5 2) Remove the screws from the fixed top-hinge with cross-slot screwdriver. 3) Replace the top-hinge and the top-door limit block and the door bearing bush to the other side. Remove the nut with sleeve. Take off the washer then remove the axes to the other side and fixed.
  • Page 6 4) Disassemble the screws fixed to the bottom-hinge with cross-slot screwdriver . Note：the freezer incline angle less 45°. 5) Replace the bottom hinge to the other side then fix it with screws. 6) Set the door to the right position, fix the mid-hinge.
  • Page 7 7) Replace the top-hinge. 8) Set the top door to the right position, fix the top-hinge and the cover. 9) Replace the leveler to the other side and adjust it to make sure the cabinet is level.

  • Page 8: Door Space Requirements

    Door Space Requirements The unit's door must be able to open fully as shown. W×D≥902×1052mm Levelling the Unit To do this adjust the two levelling feet at the front of the unit. If the unit is not level, the door and magnetic seal alignments will not be covered properly.

  • Page 9: Interior Accessories

    ◆ Before Turning On! Do not turn on until two hours after moving the unit. 2.7 Interior Accessories Various glass or plastic storage shelves are included with your appliance - different models have different combinations. 3. PRODUCT OVERVIEW *All images in this instruction manual are for indication only; please refer to your individual unit fordetails. 4.

  • Page 10: Noise Inside The Unit

    Setting“Max” ：Coolest Temperature ◆During high ambient temperatures e.g. On hot summer days. It may be necessary to set the Thermostat to the Coolest setting (position“Max”).This may cause the compressor running Continuously in order to maintain a low temperature in the cabinet. ◆For the first time you install your freezer, set the thermostat knob at “Med”.

  • Page 11: Maintenance

    technician for assistance. 6. MAINTENANCE 6.1 Care When Handling / Moving Your Unit Hold the unit around its sides or base when moving it. Under no circumstances should it be lifted by holding the edges of the top surface. 6.2 Servicing The unit should be serviced by an authorized engineer and only genuine spare parts should be used.

  • Page 12: Warm Tips

    balanced; Whether the freezer parts are properly placed. 7.1 Warm tips: ◆The freezer enclosure may emit heat during operation specially in summer, this is caused by the radiation of the condenser, and it is normal. ◆Condensation: condensation phenomenon will be detected on the exterior surface and door seals of the freezer when the ambient humidity is large, this is a normal phenomenon, and the condensation can be wiped away with a dry towel.
  • Page 13 of disposing of your old unit and packaging from the new one can be obtained from your local council office. When disposing of an old unit break of any old locks or latches and remove the door as a safeguard. Correct Disposal of this product Correct Disposal of this product This marking indicates that this product should not be disposed with other...
