DAYTEK Mk 2 Instruction Manual page 3

2. In cabinet wall side, turn mounting bracket facing
against the wall and mark two hole positions.
Drill two holes with 8mm (5/64") diameter x
35 – 40mm (1.4 – 1.6 inch) depth.
4. To install retaining hook, insert
plug into the hole and screw
hook into position. (For Twin
Line model, repeat Step 4 to
install second retaining hook)
5. To install cabinet, insert plastic plug into the
hole and affix screws leaving 6–8mm (15/64 –
5/16") distance from shoulder head to the wall.
WALL
6 – 8mm
3. In retaining hook wall side, drill hook position with
8mm diameter x 35 – 40mm depth (1.4 – 1.6 inch).
(For Twin Line model, repeat Step 3 to drill second
hook position. Recommended center to center hole
positions 50mm – 80mm [2 – 3.2 inch].)
6. Align and locate cabinet mounting hole into
screw and pull down slightly to secure correctly.
Tighten screws into positions.
WALL
MOUNTING HOLE
3
50 – 80mm
PRODUCT
CENTER LINE
