Next 145779 Assembly Instructions Manual

Smoked glass hideaway set

Advertisement

Quick Links

IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.

Tools Needed

Helpline

If you have any problems with this product or
require any replacement fittings please contact
Customer Services Tel: 0844 844 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to
be faulty. Should you need to return the unassembled product, please repack in the original packaging.

IMPORTANT

• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of 2 persons is required to assemble this product.
• Do not use this item if any structual part is broken or missing.

PRODUCT INFORMATION

• Glass table top and MDF with black paint.
• Made in China

CARE INSTRUCTIONS

• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the products is protected with mats and coasters when item are placed on the surfaces. to prevent scratching.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or
warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if necessary.
• Do not place very hot or cold items against or in close proximity to the glass surface unless adequately thick insulation
material is used to prevent such item from coming into contact with the glass.
• Do not strike the glass with hard or pointed items.
• Clean using a glass cleaner and soft cloth. Do not use cleaning products containing abrasives as these will scratch .
• Please remove plastic protection film on glass table top before use.

GLASS INFORMATION

• This item contains glass. Please handle with extreme care.
• If the glass is chipped or broken, stop using the product and consult the manufacturer or supplier.
• This product contains 8mm glass that does not conform to BS 6206. If the glass is chipped or broken replace with glass
of the type described.
145779 SMOKED GLASS HIDEAWAY SET
ASSEMBLY INSTRUCTIONS.
Page 1 of 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 145779 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Next 145779

  • Page 1 145779 SMOKED GLASS HIDEAWAY SET ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0844 844 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
  • Page 2 FITTINGS ( 17) (M6x46mm) (M8x49mm) (M8x75mm) ( 12.5) ( 12.5) (M8) Ø Ø Ø (M13.6) (M4) (M5) ( 12x30mm) ( 12x60mm) Ø Ø PARTS Bottom bar x 1 Table top x 1 Table leg x 4 Bottom Bar x 1 Top bar x 1 Top bar x 1 Page 2 of 6...
  • Page 3 STEP ONE 1. Insert 2 x bolts (C) and 6 x wood dowels (J) to table legs (2). 2. Repeat step 1 for another 3 x table legs (2). STEP TWO 1. Attach Bottom bar (4) & Top bar (6) to one of the table leg (2) with 2 x half moon fittings (H), 2 x washers (E) &...
  • Page 4 STEP THREE 1. Attach another table leg (2) to the assembled unit with 2 x half moon fittings (H), 2 x washers (E) & 2 x nuts (G) and tighten by using spanner (K). STEP FOUR 1. Insert 4 x wooden dowels (I) into the assembled unit.
  • Page 5 STEP FIVE 1. Attach 2 x table legs (2) to the assembled unit with 4 x half moon fittings (H), 4 x washers (E) & 4 x nuts (G) and tighten by using spanner (K). STEP SIX 1. Fasten the cross bars with 2 x bolts (A) & 2 x washers (D) and tighten by using allen key (L).
  • Page 6 4 washers (E), 4 x spring washers (F) & 4 x bolts (B) and tighten by using allen key (M). STEP EIGHT 1. Upside down the table to correct position and remove the plastic protection film on top. Next Retail Ltd, Desford Road, Leicester, LE 19 4 AT Page 6 of 6...
