IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Tools Needed
Helpline
If you have any problems with this
product or require any replacement
ttings please contact Customer
Services Tel: 0333 777 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed
unless the item is found to be faulty. Should you need to return the unassembled product,
please repack in the original packaging.
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple
step by step instructions.
• Carefully check that you have all parts before beginning assembly
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly
• A minimum of 2 persons is required to assemble this product.
• We recommend the use of the wall attachment bracket for safety reasons.
PRODUCT INFORMATION
Made in Poland.
CARE INSTRUCTIONS
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Always use a non-silicone based furniture polish. Silicone in furniture polishes can break down
the lacquer finish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately
Avoid keeping furniturein direct sunlight or closeto any heat sources as this can cause cracking,
discolouration or warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
All assembly fixings should always be tightened properly and periodically check all fixings and
tighten if necessary.
• The finish will mellow and change colour over time.
141952 MODULAR BLACK DOUBLE
ASSEMBLY INSTRUCTIONS.
1 of 14
.
.
MODULAR P480MRK1
.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 141952 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Next 141952

  • Page 1 141952 MODULAR BLACK DOUBLE ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement ttings please contact Customer Services Tel: 0333 777 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
  • Page 2 DESCRIPTION: Assembly MODULAR Instruction 141952 BLACK DOUBLE FLOOR AREA 3.0 M x 1,0 M 1.5 hrs 2 PERSON ASSEMBLY APPROXIMATE ASSEMBLY TIME REQUIRED ASSEMBLY SPACE REQUIRED ASSEMBLY TOOLS ASSEMBLED DIMENSIONS 520 mm 520 mm 2 of 14 MODULAR P480MRK1...
  • Page 3: Parts List

    DESCRIPTION: Assembly MODULAR Instruction 141952 BLACK DOUBLE PARTS LIST NO PART LIST NO PART LIST (1) RIGHT SIDE PANEL (2) LEFT SIDE PANEL (3) TOP PANEL (4) HORIZONTAL DIVIDER (5) BOTTOM PANEL (6) PLINTH (7) HORIZONTAL SLAT (8) BACK PANEL...
  • Page 4: Hardware List

    DESCRIPTION: Assembly MODULAR Instruction 141952 BLACK DOUBLE HARDWARE LIST DO NOT MIX CONTENT OF HARDWARE BOXES 4+4x 3,0x13mm 6,3x13mm 3,5x13mm HINGE PLATE SCREW FEET SCREW SCREW CLOTHES BAR BAG 2 SUPPORT BAG 2 BAG 1 BAG 1 BAG 1 HINGES PLATE “C” FOR FIXING DOORS ARE INCLUDED WITH THE DOORS.
  • Page 5 DESCRIPTION: Assembly MODULAR Instruction 141952 BLACK DOUBLE Top Tips before you start! Please check that all parts are present before you start the assembly of your furniture, as once assembled, the furniture is exempt from our home approval policy. For ease and speed of assembly, we recommend that before you commence each step of the assembly, that you identify all the parts required for that step.
  • Page 6 DESCRIPTION: Assembly MODULAR Instruction 141952 BLACK DOUBLE SCREW IN CAM SCREWS PRESS IN CAM LOCKS. ARROW ON CAM ONLY DOWN TO FIRST RING. LOCK MUST FACE HOLE IN PANEL EDGE. FLUSH WITH DO NOT INSERT DOWELS PANEL IN CAM SCREW / LOCK HOLES.
  • Page 7 DESCRIPTION: Assembly MODULAR Instruction 141952 BLACK DOUBLE HINGES PLATE “C” FOR FIXING DOORS ARE INCLUDED WITH THE DOORS. Type:Left Type:Right f r o 7 of 14 MODULAR P480MRK1...
  • Page 8 DESCRIPTION: Assembly MODULAR Instruction 141952 BLACK DOUBLE 8 of 14 MODULAR P480MRK1...
  • Page 9 DESCRIPTION: Assembly MODULAR Instruction 141952 BLACK DOUBLE 1/2 TURN CLOCKWISE. 9 of 14 MODULAR P480MRK1...
  • Page 10 DESCRIPTION: Assembly MODULAR Instruction 141952 BLACK DOUBLE 1/2 TURN CLOCKWISE. 1/2 TURN CLOCKWISE. 10 of 14 MODULAR P480MRK1...
  • Page 11 DESCRIPTION: Assembly MODULAR Instruction 141952 BLACK DOUBLE 16x 4x 11 of 14 MODULAR P480MRK1...
  • Page 12 DESCRIPTION: Assembly MODULAR Instruction 141952 BLACK DOUBLE 12 of 14 MODULAR P480MRK1...
  • Page 13 DESCRIPTION: Assembly MODULAR Instruction 141952 BLACK DOUBLE STEP STEP NOT SUPPLIED WHEN CARCASS IS ASSEMBLED PLEASE REFER TO FURTHER INSTRUCTIONS INCLUDED WITH THE DOORS Wall fixings are not supplied with this product as different wall materials require different types of fixing devices( such as Rawl plugs used on brick work).You must use fixing devices suitable for the type of wall you intend to mount this product to.
  • Page 14 Loosen fixing screw “A”, push hinge arm forwards or backwards, re-tighten screw “A” ,fix screw “B” with a 1/4-turn in clock-wise direction. c) Height adjustment: Loosen screw “C”, adjust height, re-tighten screw “C”. NEXT Retail Ltd, Desford Road, Enderby Leicester, LE19 4AT 14 of 14 MODULAR P480MRK1...
