IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY
Tools Needed
Helpline
If you have any problems with this
product or require any replacement
ttings please contact Customer
Services Tel: 0333 777 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed
unless the item is found to be faulty. Should you need to return the unassembled product,
please repack in the original packaging.
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple
step by step instructions.
• Carefully check that you have all parts before beginning assembly
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly
• A minimum of 2 persons is required to assemble this product.
• We recommend the use of the wall attachment bracket for safety reasons.
PRODUCT INFORMATION
Made in Poland.
CARE INSTRUCTIONS
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Always use a non-silicone based furniture polish. Silicone in furniture polishes can break down
the lacquer finish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately
Avoid keeping furniturein direct sunlight or closeto any heat sources as this can cause cracking,
discolouration or warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
All assembly fixings should always be tightened properly and periodically check all fixings and
tighten if necessary.
• The finish will mellow and change colour over time.
144439 MODULAR BLACK SINGLE
ASSEMBLY INSTRUCTIONS.
1 of 13
option"a"
.
option"b"
.
MODULAR P480MRK0
.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 144439 and is the answer not in the manual?

Questions and answers

Summary of Contents for Next 144439

  • Page 1 144439 MODULAR BLACK SINGLE ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY Tools Needed option”a” option”b” Helpline If you have any problems with this product or require any replacement ttings please contact Customer Services Tel: 0333 777 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
  • Page 2 DESCRIPTION: Assembly MODULAR Instruction 144439 BLACK SINGLE FLOOR AREA 3.0 M x 1,0 M 1.5 hrs 2 PERSON ASSEMBLY APPROXIMATE ASSEMBLY TIME REQUIRED ASSEMBLY SPACE REQUIRED ASSEMBLY TOOLS ASSEMBLED DIMENSIONS option”a” option”b” 520 mm 2 of 13 MODULAR P480MRK0...
  • Page 3: Parts List

    DESCRIPTION: Assembly MODULAR Instruction 144439 BLACK SINGLE PARTS LIST NO PART LIST (1) RIGHT SIDE PANEL (2) LEFT SIDE PANEL (3) TOP PANEL (4) HORIZONTAL DIVIDER (5) BOTTOM PANEL (6) PLINTH (7) BACK PANEL (8) SHELF 3 of 13 MODULAR P480MRK0...
  • Page 4: Hardware List

    DESCRIPTION: Assembly MODULAR Instruction 144439 BLACK SINGLE HARDWARE LIST DO NOT MIX CONTENT OF HARDWARE BOXES 3,0x13mm 6,3x13mm 3,5x13mm HINGE PLATE SCREW FEET SHELF PEG SCREW SCREW CLOTHES BAR SUPPORT BAG 2 BAG 2 BAG 1 BAG 1 BAG 1 HINGES PLATE “C”...
  • Page 5 DESCRIPTION: Assembly MODULAR Instruction 144439 BLACK SINGLE Top Tips before you start! Please check that all parts are present before you start the assembly of your furniture, as once assembled, the furniture is exempt from our home approval policy. For ease and speed of assembly, we recommend that before you commence each step of the assembly, that you identify all the parts required for that step.
  • Page 6 DESCRIPTION: Assembly MODULAR Instruction 144439 BLACK SINGLE SCREW IN CAM SCREWS PRESS IN CAM LOCKS. ARROW ON CAM ONLY DOWN TO FIRST RING. LOCK MUST FACE HOLE IN PANEL EDGE. FLUSH WITH DO NOT INSERT DOWELS PANEL IN CAM SCREW / LOCK HOLES.
  • Page 7 DESCRIPTION: Assembly MODULAR Instruction 144439 BLACK SINGLE HINGES PLATE “C” FOR FIXING DOORS Type:Left ARE INCLUDED WITH THE DOORS. Type:Right f r o 7 of 13 MODULAR P480MRK0...
  • Page 8 DESCRIPTION: Assembly MODULAR Instruction 144439 BLACK SINGLE 8 of 13 MODULAR P480MRK0...
  • Page 9 DESCRIPTION: Assembly MODULAR Instruction 144439 BLACK SINGLE 1/2 TURN CLOCKWISE. 1/2 TURN CLOCKWISE. 9 of 13 MODULAR P480MRK0...
  • Page 10 DESCRIPTION: Assembly MODULAR Instruction 144439 BLACK SINGLE option”a” 10 of 13 MODULAR P480MRK0...
  • Page 11 DESCRIPTION: Assembly MODULAR Instruction 144439 BLACK SINGLE option”b” 11 of 13 MODULAR P480MRK0...
  • Page 12 DESCRIPTION: Assembly MODULAR Instruction 144439 BLACK SINGLE STEP STEP NOT SUPPLIED WHEN CARCASS IS ASSEMBLED PLEASE REFER TO FURTHER INSTRUCTIONS INCLUDED WITH THE DOORS Wall fixings are not supplied with this product as different wall materials require different types of fixing devices( such as Rawl plugs used on brick work).You must use fixing devices suitable for the type of wall you intend to mount this product to.
  • Page 13 Loosen fixing screw “A”, push hinge arm forwards or backwards, re-tighten screw “A” ,fix screw “B” with a 1/4-turn in clock-wise direction. c) Height adjustment: Loosen screw “C”, adjust height, re-tighten screw “C”. NEXT Retail Ltd, Desford Road, Enderby Leicester, LE19 4AT 13 of 13 MODULAR P480MRK0...
