OPERATIONAL & INSTRUCTION
MANUAL
Model: Ultra 3800FLT
(220v-240V 2Ø)
Voltage Supply to Machine:
L1 to L2: ___________ L1 to Ground: ____________ L2 to Ground ___________
UltraSonic LLC
1200 Ferris Road
Amelia, Ohio 45102
Tel: 513-502-9746
Fax: 513-436-1527
info@ultrasonicllc.com
www.ultrasonicllc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultra 3800FLT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ultrasonic Ultra 3800FLT

Summary of Contents for Ultrasonic Ultra 3800FLT

  • Page 1 OPERATIONAL & INSTRUCTION MANUAL Model: Ultra 3800FLT (220v-240V 2Ø) Voltage Supply to Machine: L1 to L2: ___________ L1 to Ground: ____________ L2 to Ground ___________ UltraSonic LLC 1200 Ferris Road Amelia, Ohio 45102 Tel: 513-502-9746 Fax: 513-436-1527 info@ultrasonicllc.com www.ultrasonicllc.com...

  • Page 2: Safety Requirements

    UltraSonic LLC for safe and proper procedures. SAFE OPERATION  Do not immerse hands or other body parts in the ultrasonic tank. Cleaning agents and contaminants can cause skin irritation and exposure to high intensity ultrasonic energy should be avoided.

  • Page 3: Installation And Initial Setup

     Make sure that the sound levels experienced in your environment are known, and wear hearing protection if necessary. Ultrasonic energy produced by the system is measurable by sound meters and OSHA sound restrictions may apply.
  • Page 4 UltraSonic LLC. Model Ultra 3800FLT switch.  Use only UltraSonic LLC approved cleaning agents and be sure you use the proper, recommended concentrations (typically 10% of approved soap per tank volume for general purpose cleaning). • Check your power supply before connecting unit. The system is designed to operate on (220v-240V 2Ø...
  • Page 5 UltraSonic LLC. Model Ultra 3800FLT Control Panel Control Panel Functions...

  • Page 6: Navigation Functions

    Machine Power: P. Machine On/Off Power Navigation Functions: 1. Cycle Start – Starts Pre-set Timers for Ultrasonic and Agitation 2. Stop – Stops Ultrasonic and Agitation 3. Heater – Manual Start/Stop (Overrides 7-Day Temperature Timer) 4. Ultrasonic – Manual Start/Stop Ultrasonic Timer 5.
  • Page 7 UltraSonic LLC. Model Ultra 3800FLT Control Panel Button/Light Functions: • Cycle Start Button: After pressed Starts the UltraSonic and Agitation timers and Will run according to timer settings (Green Lamp), when Finished the Filtration timer will run according to timer Setting (Yellow Lamp), when cycle is complete or in rest (Red Lamp).

  • Page 8: Display Panel

    Temperature, press Menu Button to Save. Press UP Button to move to next setting. • Ultrasonic Timer Set: In Menu Press UP Button until Ultrasonic Set press Menu Button until Timer use Up/Down Buttons to set time, press Menu Button to Save.
  • Page 9 UltraSonic LLC. Model Ultra 3800FLT use Up/Down Buttons to set time, press Menu Button to Save. Press UP Button to move to next setting. • Auxiliary Control Set: In Menu Press UP Button until Auxiliary Control press Menu Button until Timer On/Off use Up/Down Buttons to set ON or OFF, Press Menu Button to reach Timer and use Up/Down Buttons to set time, press Menu Button to Save.
  • Page 10 UltraSonic LLC. Model Ultra 3800FLT...
  • Page 11 UltraSonic LLC. Model Ultra 3800FLT...
  • Page 12 UltraSonic LLC. Model Ultra 3800FLT...
  • Page 13 UltraSonic LLC. Model Ultra 3800FLT...

  • Page 14: Normal Operation

    O-rings), hand tighten the canister in place to ensure a tight fit, use wrench to snug canister, do not over tighten. NOTE: Consult your UltraSonic LLC representative for recommended schedule for filter and solution changes based on your application.
  • Page 15  Temperature - Temperature has a dramatic effect on the cleaning performance and time needed to clean a part. The recommended temperature range is 140F to 150F. Temperatures above can decrease the ultrasonic action. Consideration needs to be given to the cleaning agent used when determining the proper temperature. NOTE: Always check the MSDS for the cleaning agent and note its boiling point or flash point.
  • Page 16 In general, clean large numbers of parts a few at a time using shorter cleaning cycles.  Contaminated Solution - As contaminants build up in the solution the ultrasonic performance drops. The cavitation bubbles waste their energy imploding on the contaminants and not on the part surface.
  • Page 17 UltraSonic LLC. Model Ultra 3800FLT SERVICE & WARRANTY PROCEDURES NOTE: DO NOT OPEN EQUIPMENT OR ATTEMPT ANY SERVICE OR WARRANTY RELATED WORK BEFORE CALLING ULTRASONIC LLC (513) 502-9746. SPECIAL NOTE: PLEASE RETAIN ORIGINAL SHIPPING CRATE Our service tech will help troubleshoot any problem and instruct user on the safe and proper procedures for repairs.

  • Page 18: Warranty

    Except as specifically provided herein; UltraSonic LLC grants no other warranty, either expressed or implied. UltraSonic LLC shall in no event be liable for damages of any kind as a result of or relating to the sale or use of the products whether such damages are...
  • Page 19 I have received a copy of the Operational & Instruction Manual. I am aware that all personnel attempting to operate, maintain, or service the UltraSonic LLC Cleaning Equipment are required to read & understand the Operational & Instruction Manual. Signed _________________________________________ Print Name ___________________________________Title _______________________ INSTRUCTIONS: Fill out information, sign, email (info@ultrasonicllc.com) or fax form to...
