- Page 1 CM-EF-EOSR VCPL AF Mount Adapter from EF/EF-S Lens to EOSR/RF Camera with Variable CPL EXIF Support Electronic Variable CPL Transmitting Auto-focus Aperture Control Function User Manual...
-
Page 3: Main Features
Description Thanks for purchasing Commlite CM-EF-EOSR VCPL Main Features 1.Drop-in Variable Circular Polarizer Filter A 2.Support EXIF INFO. Transmitting 3.Support Auto-focus Function 4.Electronic Aperture Control 5.Support IS Image Stabilization Function 6.Full Metal Made, Powerful and Stable Notice 1.Some functions of EF lenses may not be supported due to camera specifications 2.The closest focus distance, maximum magnification and view angle of the... - Page 4 Components Metal Signal Contact Camera Connecting Side Lens Mounting Mark Polarizer Rotation Wheel Lens Release Button Metal Signal Contact Polarizer Release Button Lens Connecting Side...
- Page 5 Polarizer Polarizer is a type of color filter, it is useful for minimizing reflections and glare, and enhances overall color and tonal saturation by filtering out light that has become polarized due to reflection from a non-metallic surface. It also helps to lessen haze in distant landscapes and increase apparent contrast.
-
Page 6: Assemble And Disassemble
Assemble and Disassemble 1. Assemble Step1. Connect the EF/EF-S lens to CM-EF-EOSR VCPL Refer to the follow illustration, press down the ‘lens release button’ of the mount adapter, align the EF/EF-S lens mounting mark to the corresponding mark on the mount adapter, and turn clockwise until... - Page 7 Step2. Connect the CM-EF-EOSR VCPL to EOSR/RF camera Refer to the follow illustration, press down the ‘lens release button’ of the EOSR/RF camera, align the red mark on the mount adapter to the red mark on the camera, and turn clockwise until tightened...
- Page 8 2. Disassemble Step1. Turn off the camera, then take off the CM-EF-EOSR VCPL Refer to the follow illustration, press down the ‘lens release button’ of EOSR/RF camera, turn counterclockwise the mount adapter until it can be easily taken off...
- Page 9 Step2. Take off the EF/EF-S lens from the CM-EF-EOSR VCPL Refer to the follow illustration, press down the ‘lens release button’ of the mount adapter, turn counterclockwise the EF/EF-S lens until it can be easily taken off...
-
Page 10: Specification
Specification Compatible Lens EF/EF-S Series Lens Compatible Camera EOSR/RF Camera Front Installation EF/EF-S Series Lens Rear Installation EOSR/RF Camera Camera-Mount Outer Diameter 67mm Lens-Mount Outer Diameter 65mm Length 30mm Net Weight 121g... - Page 11 CM-EF-EOSR VCPL EF/EF-S镜头转佳能EOSR/RF微单转接环（含CPL） 偏振镜可调 EXIF 信息 可自动对焦 电子可调光圈 防抖功能 产品使用说明书...
- Page 13 描 述 感谢您购买咔莱CM-EF-EOSR VCPL 主要功能 1.插入式圆形偏振镜可调 4.电子光圈可调 2.支持EXIF信息传输 5.支持IS防抖功能 3.支持AF自动对焦 6.金属材质，稳固耐用 注意事项 1.根据相机规格的不同，部分EF镜头的功能可能无法使用 2.转接后所安装镜头的最近对焦距离、最大放大倍率和视角会略产生变化 3.本产品虽然具有一定的防水滴性能，但是在雨天拍摄时，请尽量不要淋湿...
- Page 14 部件名称 电子信号触点 相机连接端 镜头安装标记 偏振镜调节旋钮 镜头释放拨杆 电子信号触点 偏振镜释放按钮 镜头连接端...
- Page 15 偏振镜 偏振镜,也叫偏光镜，是一种滤色镜。偏振镜的除色功用是能有选择地让某 个方向振动的光线通过,在彩色和黑白摄影中常用来消除或减弱非金属表面 的强反光，从而消除或减轻光斑 镜头端保护盖 相机端保护盖...
- Page 16 安装及拆卸转接环 1. 安装 步骤1. 将EF/EF-S卡口镜头安装到CM-EF-EOSR VCPL上 如图，按下转接环上的镜头释放拔杆，将EF/EF-S镜头上的红色标记对 准转接环镜头端卡口上的相应标记，顺时针方向旋入至拧紧为止...
- Page 17 步骤2. 将CM-EF-EOSR VCPL安装到EOSR/RF卡口相机 如图，按下EOSR/RF卡口相机上的镜头释放按钮，将转接环上的红色标 记对准相机端卡口处的红色标记，顺时针方向旋入至拧紧为止 使用转接环上的偏振镜调节旋钮可改变偏振镜的 偏光角度，以满足您不同的拍摄需求...
- Page 18 2. 拆卸 步骤1. 关闭相机，然后将CM-EF-EOSR VCPL从EOSR/RF卡口相机上取下 如图，按下EOSR/RF卡口相机的镜头释放按钮，逆时针旋转转接环直至 可轻松取下为止...
- Page 19 步骤2. 将EF/EF-S镜头从CM-EF-EOSR VCPL上取下 如图，按下转接环的镜头释放拨杆，逆时针旋转镜头直至可轻松取下为止...
- Page 20 规格与技术参数 兼容镜头 EF/EF-S系列镜头 兼容相机 佳能EOSR/RF卡口机身 正面安装 EF/EF-S系列镜头 背面安装 佳能EOSR/RF卡口机身 相机端外围直径 67mm 镜头端外围直径 65mm 总长度 30mm 重量 121克...
