- Page 1 CM-EF-NZ Electronic AF Lens Mount Adapter from EF/EF-S Lens to Nikon Z-Mount Mirrorless Camera User Manual...
-
Page 2: Main Features
Foreword Thanks for purchasing Commlite electronic lens mount adapter EF-NZ. Before usage of the adapter, please ensure the adapter is compatible with your camera and lens. In order to avoid the damage of product caused by incorrect use, please read the user manual carefully. - Page 3 Notice 1. This adapter is built-in with USB firmware upgrade port, please pay attention to Commlite website (www.commlite.com) to learn the update information in the first place; 2. After installing EF-NZ adapter, please set the lens to AF mode if the AF function is required;...
- Page 4 Components Metal Signal Contact 1/4 Screw Base Plate Camera Connecting Side Camera Connecting Side Cap Lens Mounting Mark USB Port Lens Release Button Metal Signal Contact Lens Connecting Side Cap Lens Connecting Side...
-
Page 5: Assemble And Disassemble
Assemble and Disassemble 1. Assemble Step 1. Connect the EF/EF-S lens to EF-NZ mount adapter Refer to the follow illustration, press down the ‘lens release button’ of the adapter, align the red mark on the EF/EF-S lens to the correspond- ing mark on the adapter, and turn clockwise until tightened... - Page 6 Step 2 . Connect the mount adapter to Z-Mount camera Refer to the follow illustration, press down the ‘lens release button’ of the Z-Mount camera, align the red mark on the adapter to the corresponding mark on the camera, and turn clockwise until tightened...
- Page 7 2. Disassemble Step 1. Turn off the camera power, then take off the adapter which is connected with EF/EF-S lens from Z-Mount camera Refer to the follow illustration, press down the ‘lens release button’ of the Z-Mount camera, turn counterclockwise the adapter which is connected with EF/EF-S lens until it can be easily taken off...
- Page 8 . Take off the EF/EF-S lens from the Z-Mount adapter Step 2 Refer to the follow illustration, press down the ‘lens release button’ of the mount adapter, turn counterclockwise the EF/EF-S lens until it can be easily taken off...
-
Page 9: Specification
Specification EF/EF-S Series Lens (For specific compatible lens models, please enter the official Compatible Lens website to view the compatibility table) Z-Mount Camera (For specific compatible camera models, please enter Compatible Camera the official website to view the compatibility table) Front Installation EF/EF-S Series Lens Rear Installation... - Page 10 ShenZhen Commlite Technology Co.,LTD Email:support@commlite.com Web:www.commlite.com...
