AXIS M11 Series AXIS M1134 Network Camera AXIS M1135 Network camera AXIS M1137 Network camera User Manual...
AXIS M11 Series About this manual About this manual This user manual describes multiple products. Some of the instructions may not be relevant for your product.
Get started Find the device on the network To find Axis devices on the network and assign them IP addresses in Windows®, use AXIS IP Utility or AXIS Device Manager. Both applications are free and can be downloaded from axis.com/support.
Secure passwords Important Axis devices send the initially set password in clear text over the network. To protect your device after the first login, set up a secure and encrypted HTTPS connection and then change the password. The device password is the primary protection for your data and services. Axis devices do not impose a password policy as they may be used in various types of installations.
Page 7
AXIS M11 Series Get started Settings toggle Settings tabs...
AXIS M11 Series Setup Setup Adjust the image To find out more about what you can do with the image, see Learn more on page 14. Level the camera To adjust the view in relation to a reference area or object, use the leveling guide in combination with a mechanical adjustment of the camera.
Page 9
AXIS M11 Series Setup • To slow down the shutter speed, set max shutter to the highest possible value. • Set the max gain to a lower value. Reduce motion blur in low-light conditions To reduce motion blur in low-light conditions, you can adjust one or more of the following settings: Note Image noise will increase if you increase the gain.
Page 10
Note WDR may cause artifacts in the image. Find out more about WDR and how to use it at axis.com/web-articles/wdr. Improve license plate recognition To better recognize the license plate of a car passing by the camera, you can apply and adjust a number of things.
AXIS M11 Series Setup 1. Go to Settings > Apps > AXIS Video Motion Detection. 2. Start the application if it is not already running. 3. Make sure you have set up the application according to your needs. Add the overlay text: 4.
Record video when the camera detects motion This example explains how to set up the camera to start recording to the SD card five seconds before it detects motion and to stop one minute after. Make sure the AXIS Video Motion Detection application is running:...
Page 13
1. Go to Settings > System > Events and add a rule. 2. Type a name for the rule. 3. In the list of conditions, under Application, select AXIS Video Motion Detection (VMD). 4. In the list of actions, under Recordings, select Record video while the rule is active.
Page 14
AXIS M11 Series Setup 2. Turn on Trigger on dark images. This will trigger an alarm if the lens is sprayed, covered, or rendered severely out of focus. 3. Set a duration for Trigger after. The value indicates the time that must pass before an email is sent.
AXIS M11 Series Learn more Learn more Bitrate control By setting the bitrate control you can manage the bandwidth consumption for your video stream. Variable bitrate (VBR) With variable bitrate the bandwidth varies based on the level of activity in the scene. The more activity in the scene, the more bandwidth is required.
Stream tab. Applications AXIS Camera Application Platform (ACAP) is an open platform that enables third parties to develop analytics and other applications for Axis products. To find out more about available applications, downloads, trials and licenses, go to axis.com/applications.
Using firmware from the active track is recommended if you want to access the newest features, or if you use Axis end-to-end system offerings. The LTS tracks are recommended if you use third-party integrations, which are not continuously validated against the latest active track.
Axis device. Check all cabling and reinstall the device. Possible IP address conflict The static IP address in the Axis device is used before the DHCP server sets a dynamic address. with another device on the...
IP addresses obtained from a DHCP server are dynamic and may change. If the IP address has been changed by DHCP changed, use AXIS IP Utility or AXIS Device Manager to locate the device on the network. Identify the device using its model or serial number, or by the DNS name (if the name has been configured).
Heavy network utilization due to poor infrastructure affects the bandwidth. • Viewing on poorly performing client computers lowers perceived performance and affects frame rate. • Running multiple AXIS Camera Application Platform (ACAP) applications simultaneously may affect the frame rate and the general performance. Need more help? Useful links •...
AXIS M11 Series Specifications Specifications To find the latest version of the product’s datasheet, go to the product page at axis.com and locate Support & Documentation. Product overview Focus ring Focus ring lock Zoom puller I/O connector Iris connector Power connector ¼...
Resetting the product to factory default settings. See Reset to factory default settings on page 16. • Connecting to an AXIS Video Hosting System service. To connect, press and hold the button for about 3 seconds until the status LED flashes green.
Page 23
AXIS M11 Series Specifications Digital Input 0 to max 30 V DC Connect to pin 1 to activate, or leave floating (unconnected) to deactivate. Digital Output 0 to max 30 V DC, open drain, Internally connected to pin 1 (DC ground) when active, 100 mA and floating (unconnected) when inactive.
