S N ( M-B
ECTION ODES W US NODES
In the field "Manufacturer
the Manufacturer ID of the wM-Bus node.
In the field "Address" it is necessary to define the ID of
the wM-Bus node.
If the field "Version" it is necessary to define the version
of the wM-Bus node.
In the field "Device Type" it is possible to define the
Type of the wM-Bus node.
The field "Key Enable" is used to decode the M-Bus
frame sent by the wM-Bus node if it uses encrypted
communication. In the following 16 fields, you have to
In the field "Variables
which type of variables definition to use. If is selected "By
Type" it is necessary to fill all fields, in the section
Variables, with the correct values; otherwise if "By
Position" is selected you can insert the progressive
number of the variable that you need (page 30 for more
information).
After that, pressing the "ADD
appears in the left side of the window. In order to modify a
created node it is necessary to select the desired node,
change the wrong items and then press the
NODE" button.
ADFweb.com S.r.l.
):
ID" it is necessary to define
List" it is necessary to select
NODE" button, a new node
"MODIFY
User Manual M-Bus / M-Bus Wireless / MQTT
Document code: MN67931_ENG
Figure 5b: "M-Bus Network" window
