ADF Web HD67801-KNX-BIP-B2 User Manual

Bacnet master / knx - converter

Advertisement

Quick Links

Industrial Electronic Devices
User Manual
Revision 1.100
English
BACnet Master / KNX - Converter
(Order Code: HD67801-KNX-BIP-B2, HD67801-KNX-BMSTP-B2)
for Website information:
www.adfweb.com?Product=HD67801
for Price information:
www.adfweb.com?Price=HD67801-KNX-BIP-B2
www.adfweb.com?Price=HD67801-KNX-BMSTP-B2
Benefits and Main Features:
Very easy to configure
Electrical isolation
Temperature range: -40°C/85°C (-40°F/185°F)
User Manual
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual BACnet Master / KNX
Document code: MN67801_ENG
For others KNX products, see also the following links:
Converter KNX to
www.adfweb.com?Product=HD67628
www.adfweb.com?Product=HD67746
www.adfweb.com?Product=HD67773
www.adfweb.com?Product=HD67802
www.adfweb.com?Product=HD67803
www.adfweb.com?Product=HD67804
www.adfweb.com?Product=HD67806
www.adfweb.com?Product=HD67807
www.adfweb.com?Product=HD67808
www.adfweb.com?Product=HD67809
www.adfweb.com?Product=HD67810
www.adfweb.com?Product=HD67811
www.adfweb.com?Product=HD67812
www.adfweb.com?Product=HD67813
www.adfweb.com?Product=HD67814
www.adfweb.com?Product=HD67815
www.adfweb.com?Product=HD67818
www.adfweb.com?Product=HD67820
www.adfweb.com?Product=HD67821
www.adfweb.com?Product=HD67825
www.adfweb.com?Product=HD67830
www.adfweb.com?Product=HD67947
www.adfweb.com?Product=HD67B18
www.adfweb.com?Product=HD67B41
www.adfweb.com?Product=HD67B79
www.adfweb.com?Product=HD67C67
www.adfweb.com?Product=HD67D27
www.adfweb.com?Product=HD67F27
Do you have an your customer protocol?
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
Revision 1.100
Pagina 1 di 31
(S7comm)
(IEC 61850 Server)
(IEC 61850 Client)
(BACnet Slave)
(CAN)
(CANopen)
(EtherNet/IP Master)
(EtherNet/IP)
(DeviceNet Master)
(DeviceNet Slave)
(J1939)
(M-Bus Master)
(Modbus Master)
(Modbus Slave)
(Modbus TCP Master)
(Modbus TCP Slave)
(PROFINET)
(SNMP)
(DMX)
(Ethernet)
(NMEA 2000)
(MQTT)
(OPC UA Client)
(OPC UA Server)
(PROFINET Master)
(EnOcean)
(LoRaWAN)
(LoRaWAN Gateway)
Phone +39.0438.30.91.31

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD67801-KNX-BIP-B2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ADF Web HD67801-KNX-BIP-B2

  • Page 1 Pagina 1 di 31 Industrial Electronic Devices User Manual Revision 1.100 English BACnet Master / KNX - Converter For others KNX products, see also the following links: (Order Code: HD67801-KNX-BIP-B2, HD67801-KNX-BMSTP-B2) Converter KNX to www.adfweb.com?Product=HD67628 (S7comm) for Website information: www.adfweb.com?Product=HD67746 (IEC 61850 Server) www.adfweb.com?Product=HD67801...
  • Page 2: Table Of Contents

    User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 2 di 31 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated...
  • Page 3: Security Alert

    User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 3 di 31 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application.
  • Page 4: Example Of Connection

    User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 4 di 31 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
  • Page 5: Connection Scheme

    User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 5 di 31 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67801-KNX-BIP-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
  • Page 6 User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 6 di 31 Industrial Electronic Devices Figure 1b: Connection scheme for HD67801-KNX-BMSTP-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
  • Page 7: Characteristics

    User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 7 di 31 Industrial Electronic Devices CHARACTERISTICS: The HD67801 is a BACnet Master / KNX Converter. It has the following characteristics: Up to 1440 bytes in reading and 1440 bytes in writing; Triple isolation between KNX - Power Supply, KNX –...
  • Page 8: Power Supply

    The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device Consumption [W/VA] HD67801-KNX-BIP-B2 HD67801-KNX-BMSTP-B2 Caution: Not reverse the polarity power HD67801-KNX-BIP-B2 HD67801-KNX-BMSTP-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com...
  • Page 9: Function Modes

    User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 9 di 31 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip1 of Dip-Switch A’...
  • Page 10: Leds

    User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 10 di 31 Industrial Electronic Devices LEDS: The device has got six LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode ON: Device powered...
  • Page 11: Rs485

    User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 11 di 31 Industrial Electronic Devices RS485: For terminate the RS485 line with a 220Ω resistor it is necessary to put ON dip 1, like in figure. The maximum length of the cable should be 1200m (4000 feet). Here some codes of cables: Belden: p/n 8132 - 2x 28AWG stranded twisted pairs conductor + foil shield + braid shield;...
  • Page 12: Knx

    User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 12 di 31 Industrial Electronic Devices KNX: KNX is the standard that allows the automated and decentralized management of the technologic plans of a big typology of structures: commercial buildings, factories, houses, public locals, schools and so on. KNX can be used in all the applications and functions for the building automations: from lighting to control dampers, to the security, to the heating monitoring, to the conditioning, to the hydric control and alarms, to energy management and so on.
  • Page 13: Ethernet

    Industrial Electronic Devices ETHERNET: The Ethernet port is used for the BACnet/IP communication (HD67801-KNX-BIP-B2) and for programming the device. The Ethernet connection must be made using Connector2/3 of HD67801-KNX-xxx-B2 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC is recommended the use of a cross cable.
  • Page 14: Use Of Compositor Sw67801

    User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 14 di 31 Industrial Electronic Devices USE OF COMPOSITOR SW67801: To configure the Converter, use the available software that runs with Windows called SW67801. It is downloadable on the site www.adfweb.com and its operation is described in this document.
  • Page 15: New Project / Open Project

    User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 15 di 31 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “BACnet Master / KNX - Converter”...
  • Page 16: Software Options

    User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 16 di 31 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.
  • Page 17 User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 17 di 31 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
  • Page 18: Set Communication

    User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 18 di 31 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, KNX and BACnet. By Pressing the “Set Communication” button from the main window for SW67801 (Fig. 2) the window “Set Communication”...
  • Page 19 User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 19 di 31 Industrial Electronic Devices If selected “BACnet MS/TP” the means of the fields for “BACnet” are: In the field “Baudrate” it is possible to select the baudrate of the BACnet line (1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200);...
  • Page 20: Knx Access

    User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 20 di 31 Industrial Electronic Devices KNX ACCESS: By pressing the “KNX Access” button from the main window for SW67801 (Fig. 2) the “KNX Access” window appears (Fig. 4). Figure 4: “KNX Set Access”...
  • Page 21 User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 21 di 31 Industrial Electronic Devices In the field “Priority” the Priority of the KNX message is defined. You can choose between the following: System (Highest); Urgent; Normal; Low (Lowest).
  • Page 22: Set Bacnet Access

    User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 22 di 31 Industrial Electronic Devices SET BACNET ACCESS: By Pressing the “Set BACnet Access ” button from the main window of SW67801 (Fig. 2), the window “Set BACnet Access” appears (Fig. Figure 5a: “BACnet Set Access ...
  • Page 23 User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 23 di 31 Industrial Electronic Devices In the field “D Add” the address of the endpoint is defined. If “D Len” is ‘1’ it is possible to insert a number from 1 to 255; if “D Len” is ‘2’...
  • Page 24 User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 24 di 31 Industrial Electronic Devices Figure 5b: “BACnet Set Access  BACnet Write” window The means of the fields in the window (Write) are the follows: If the field “Enable” is checked, the BACnet request is enabled; In the field “IP Address”...
  • Page 25 User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 25 di 31 Industrial Electronic Devices In the field “D Adr” the address of the endpoint is defined. If “D Len” is ‘1’ it is possible to insert a number from 1 to 255; if “D Len” is ‘2’...
  • Page 26: Update Device

    User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 26 di 31 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. This by using the Ethernet port. If you don’t know the actual IP address of the device you have to use this procedure: Turn OFF the Device;...
  • Page 27 User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 27 di 31 Industrial Electronic Devices Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67801 device. Warning: If Fig.
  • Page 28: Mechanical Dimensions

    Document code: MN67801_ENG Revision 1.100 Pagina 28 di 31 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 10a: Mechanical dimensions scheme for HD67801-KNX-BIP-B2 Figure 10b: Mechanical dimensions scheme for HD67801-KNX-BMSTP-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
  • Page 29: Ordering Informations

    B: 4M, 35mm DIN Rail mounting BACnet Type BIP: BACnet/IP BMSTP: BACnet MS/TP Device Family HD67801-KNX: BACnet Master / KNX - Converter Order Code: HD67801-KNX-BIP-B2 BACnet/IP Master / KNX – Converter Order Code: HD67801-KNX-BMSTP-B2 BACnet MS/TP Master / KNX – Converter ACCESSORIES: Order Code: AC34001 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz –...
  • Page 30: Disclaimer

    User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 30 di 31 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
  • Page 31: Warranties And Technical Support

    User Manual BACnet Master / KNX Document code: MN67801_ENG Revision 1.100 Pagina 31 di 31 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.

This manual is also suitable for:

Hd67801-knx-bmstp-b2
