Industrial Electronic Devices
INDEX:
INDEX
UPDATED DOCUMENTATION
REVISION LIST
WARNING
TRADEMARKS
SECURITY ALERT
EXAMPLE OF CONNECTION
CONNECTION SCHEME
CHARACTERISTICS
CONFIGURATION
POWER SUPPLY
FUNCTION MODES
LEDS
ETHERNET
M-BUS
M-BUS WIRELESS
USE OF COMPOSITOR SW67931
NEW CONFIGURATION / OPEN CONFIGURATION
SOFTWARE OPTIONS
SET COMMUNICATION
MQTT SET TOPIC
M-BUS
UPDATE DEVICE
SCAN & DECODE FUNCTION
TEMPLATE STRING: DEFINITION OF MQTT
PAYLOAD
MECHANICAL DIMENSIONS
ORDERING INFORMATIONS
ACCESSORIES
DISCLAIMER
OTHER REGULATIONS AND STANDARDS
WARRANTIES AND TECHNICAL SUPPORT
RETURN POLICY
ADFweb.com S.r.l.
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
Page
you need to check that the following document is:
2
2
Updated
2
Related to the product you own
2
2
To obtain the most recently updated document, note the "document code"
3
that appears at the top right-hand corner of each page of this document.
4
5
With this "Document Code" go to web page www.adfweb.com/download/
8
and search for the corresponding code on the page. Click on the proper
8
"Document Code" and download the updates.
9
10
11
REVISION LIST:
12
12
Revision
13
1.000
14
15
16
18
24
25
WARNING:
35
37
ADFweb.com reserves the right to change information in this manual about
38
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
41
42
44
TRADEMARKS:
45
45
All trademarks mentioned in this document belong to their respective
46
owners.
46
User Manual M-Bus / M-Bus Wireless / MQTT
Document code: MN67931_ENG
Date
Author
Chapter
05/12/2017
Ff
All
Revision 1.000
Page 2 of 46
Description
First release version
Advertisement
Table of Contents
Related Manuals for ADF Web M-Bus
Summary of Contents for ADF Web M-Bus
- Page 1 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 2 of 46 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is:...
-
Page 2: Security Alert
User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 3 of 46 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 3: Example Of Connection
User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 4 of 46 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com S.r.l. -
Page 4: Connection Scheme
User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 5 of 46 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67931-B2-xxx ADFweb.com S.r.l. - Page 5 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 6 of 46 Industrial Electronic Devices Figure 1b: Connection scheme for HD67931-B2-xxxMHz-0 ADFweb.com S.r.l.
- Page 6 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 7 of 46 Industrial Electronic Devices Figure 1c: Connection scheme for HD67931-B2-xxxMHz-xxx ADFweb.com S.r.l.
- Page 7 Revision 1.000 Page 8 of 46 Industrial Electronic Devices CHARACTERISTICS: The HD67931-B2-xxx is a M-Bus / M-Bus Wireless / MQTT Converter. It allows the following characteristics: Electrical isolation between Ethernet and M-Bus; Mountable on 35mm Rail DIN; Wide power supply input range: 18…35V DC;...
-
Page 8: Power Supply
HD67931-B2-xxxMHz-40, HD67931-B2-40 HD67931-B2-xxxMHz-80, HD67931-B2-80 HD67931-B2-xxxMHz-160, HD67931-B2-160 HD67931-B2-xxxMHz-250, HD67931-B2-250 * This value is with all the Slave M-Bus devices of the code (20, 40, 80, 160, 250) connected to the line (wired side) Caution: Not reverse the polarity power HD67931-B2 ADFweb.com S.r.l. -
Page 9: Function Modes
User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 10 of 46 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device;... - Page 10 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 11 of 46 Industrial Electronic Devices LEDS: The device has got two LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below.
- Page 11 The M-Bus is a unpolarized bus. A two wire standard telephone cable (JYStY N*2*0.8 mm) is used as the transmission medium for the M-Bus. The maximum distance between a slave and the repeater is 350m; this length corresponds to a cable resistance of up 29Ω. This distance applies for the standard configuration having Baud rates between 300 and 9600 Baud, and a maximum of 250 slaves.
- Page 12 Industrial Electronic Devices M-BUS WIRELESS: The standards of M-Bus Wireless are specified in EN 13757-4. The signal is @ 169 MHz or 433 MHz or 868 MHz (in relation to the order code). The Antenna connector is a SMA Female (‘Female Outer Shell’ and ‘Female Receptacle’) so the Antenna must have a SMA Male connector.
- Page 13 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 14 of 46 Industrial Electronic Devices USE OF COMPOSITOR SW67931: To configure the Converter, use the available software that runs with Windows called SW67931. It is downloadable on the site www.adfweb.com and its operation is described in this document.
-
Page 14: New Configuration / Open Configuration
Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “M-Bus / M-Bus Wireless / MQTT - Converter” in order to configure another device in the same manner, it is necessary to maintain the folder and all its contents;... -
Page 15: Software Options
User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 16 of 46 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. - Page 16 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 17 of 46 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
-
Page 17: Set Communication
User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 18 of 46 Industrial Electronic Devices SET COMMUNICATION: By Pressing the “Set Communication” button from the main window for SW67931 (Fig. 2) the window “Set Communication” appears (Fig. 3). -
Page 18: Working Mode
Working Mode” window Mode: on MQTT side, it is possible to see the M-Bus responses in raw, without any decoding. This section is used to define the main parameters of M-Bus line. The means of the fields are: In the field “M-Bus on... - Page 19 In the field “Password” the password for the connection to the MQTT server is defined; In the field “Template String” the structure of payload for the MQTT messages with the data from M-Bus is defined. See page 38 for more info. ADFweb.com S.r.l.
- Page 20 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 21 of 46 Industrial Electronic Devices THERNET This section is used to define the general parameters of Ethernet. The means of the fields are: In the field “Ip...
-
Page 21: Dhcp Subnet
User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 22 of 46 Industrial Electronic Devices If the field “Enable DHCP” is checked, the converter acts as DHCP Server for the Clients connected. If the option is enabled, in the fields “DHCP First IP... - Page 22 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 23 of 46 Industrial Electronic Devices TLS (T RANSPORT AYER ECURITY This section is used to define the parameters of TLS protocol. The means of the...
- Page 23 Topic” button from the main window for SW67931 (Fig. 2) the window “Set MQTT Topics” appears (Fig. 4). This section is used to define the MQTT topics where the converter will publish the data from M-Bus. Figure 3k: “Set MQTT Topics” window The means of the fields are: In the field “Topic”...
- Page 24 Industrial Electronic Devices M-BUS By Pressing the “M-Bus” button from the main window for SW67931 (Fig. 2) the window “M-Bus Network” appears (Fig. 5). In the section “Nodes” it is possible to create the nodes of M-Bus line: In the field “Description” it is possible to write a short description of the node.
- Page 25 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 26 of 46 Industrial Electronic Devices ECTION ODES US NODES In the field “Manufacturer ID” it is necessary to define the Manufacturer ID of the wM-Bus node.
- Page 26 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 27 of 46 Industrial Electronic Devices ECTION ARIABLES Selecting the desired node it is possible to add a variable. In order to create a new variable it is necessary to fill these items: To use the created variable the field “Enable...
- Page 27 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 28 of 46 Industrial Electronic Devices In the field “Topic” the MQTT topic to link to the variable is defined. In the field “Post Operation” it is possible to define an operation on the data read before mapping it in the topic.
- Page 28 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 29 of 46 Industrial Electronic Devices SECTION VARIABLES (BY POSITION): Selecting the desired node it is possible to add a variable. In order to create a new variable it is necessary to fill these items: To use the created variable the field “Enable...
- Page 29 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 30 of 46 Industrial Electronic Devices Example: 0x68 - Start Byte 0xBD - L Fied 0xBD - L Field 0x68 - Start Byte 0x08 - C Field...
- Page 30 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 31 of 46 Industrial Electronic Devices ASTE AND ELETE TEMS By pressing the right button of the mouse over an item (Variable or Node) it is possible to Copy, Paste and Delete.
- Page 31 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 32 of 46 Industrial Electronic Devices Possible choices for the fields used to create a variable: Type of Data: Function Field: |_Energy (Wh) |_Instantaneous Value |_Energy (J)
- Page 32 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 33 of 46 Industrial Electronic Devices VIFE: |_ Not Selected |_ Period of tariff months(s) |_ Credit of the nominal local legal currency units |_ Period of tariff year(s)
- Page 33 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 34 of 46 Industrial Electronic Devices |_ per second |_ Duration of limit exceed |_ per minute |_ Duration of first/last |_ per hour |_ Date(/time) of first/last begin/end...
-
Page 34: Update Device
User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 35 of 46 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. This by using the Ethernet port. - Page 35 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 36 of 46 Industrial Electronic Devices Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67931 device.
- Page 36 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 37 of 46 Industrial Electronic Devices SCAN & DECODE FUNCTION: “SCAN & DECODE” functions are integrated in the configurator software SW67931. It is possible to access to these functions by simple click on the “...
- Page 37 It is possible to have a simple text format or a JSON format. The definition of the template can be done using Key words, used to link a specific information of the M-Bus node/variables. The key words used and their meanings are:...
- Page 38 Document code: MN67931_ENG Revision 1.000 Page 39 of 46 Industrial Electronic Devices Example We have a project for a M-Bus node with this parameters: Primary Address: 1 Secondary Address: 12345678 Description: Energy meter Variables: Var.1: Type: Energy (Wh), Dimension: 32 bit, Value: 300000, Scale factor: 1 Var.2: Type: Power (W), Dimension: 24 bit, Value: 2567, Scale Factor: 10^3...
- Page 39 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 40 of 46 Industrial Electronic Devices It is also possible to define the template as JSON format, like this: "description": "$DESC$", "primary address": "$PRIMARY$", "secondary address": "$SECONDARY$", "measure unit 1": "$UNIT1$",...
-
Page 40: Mechanical Dimensions
User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 41 of 46 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 8: Mechanical dimensions scheme for HD67931-B2-xxxMHz-xxx ADFweb.com S.r.l. -
Page 41: Ordering Informations
Maximum number of slaves supported 0: M-Bus port (wired) not present 20: up to 20 standard slaves (1.5mA consumption) connected to M-Bus 40: up to 40 standard slaves (1.5mA consumption) connected to M-Bus 80: up to 80 standard slaves (1.5mA consumption) connected to M-Bus 160: up to 160 standard slaves (1.5mA consumption) connected to M-Bus... - Page 42 Revision 1.000 Page 43 of 46 Industrial Electronic Devices Order Code: HD67931-B2-20 M-Bus / MQTT – Converter (up to 20 M-Bus slaves) Order Code: HD67931-B2-40 M-Bus / MQTT – Converter (up to 40 M-Bus slaves) Order Code: HD67931-B2-80 M-Bus / MQTT – Converter (up to 80 M-Bus slaves) Order Code: HD67931-B2-160 M-Bus / MQTT –...
- Page 43 (up to 250 M-Bus slaves - wM-Bus @ 868MHz) ACCESSORIES: Order Code: APW020 Power Supply for M-Bus Master device that supports up to 20 Slaves Order Code: APW040 Power Supply for M-Bus Master device that supports up to 40 Slaves...
- Page 44 User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 45 of 46 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal.
-
Page 45: Warranties And Technical Support
User Manual M-Bus / M-Bus Wireless / MQTT Document code: MN67931_ENG Revision 1.000 Page 46 of 46 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com.
