- Page 1 100KC MULTI-FUEL & SMOKE EXEMPT WOODBURNING STOVE INSTALLATION & USER INSTRUCTIONS (TO BE LEFT WITH THE CUSTOMER) UK & Ireland...
-
Page 2: Table Of Contents
We recommend that in such a situation a second sweeping of the chimney should Page 2 100KC-I04-010317... -
Page 3: Installation Instructions
Order made and signed by the Secretary of State or Minister in the devolved administrations. The ESSE 100SE Series has been recommended as suitable for use in smoke control areas when burning dry wood logs in accordance with these instructions. Peat and other unauthorised fuels must not be burnt in this appliance in smoke control areas. -
Page 4: Chimney& Flue
The optional rear flue box attachment available from ESSE has a detachable base that allows for fallen soot to be removed (See Fig.1). - Page 5 A flue/chimney access point may also be required so that the state of the chimney can be checked and any fallen soot removed. External flue must be insulated to prevent heat loss. Fig.1 – Ideal Flue Connections (Flue box available from www.esseparts.com) Fig.2 – Chimney and Flue Performance Page 5 100KC-I04-010317...
-
Page 6: Flue Draught
Fit an air vent if the room is sealed. High flue draught symptoms: fire difficult to control, fuel will not last, stove too hot, stove damage, chimney fire. CAUSE REMEDY External wind conditions combined with Fit stabiliser cowl. chimney terminal Fit flue draught stabiliser. Page 6 100KC-I04-010317... -
Page 7: Flue Stabiliser
Fitted in the same room as the stove. The same size as the flue pipe. Fitted no closer than 700mm to the flue outlet of the appliance. DIMENSIONS & CLEARANCES Fig.3 – Stove Dimensions Page 7 100KC-I04-010317... -
Page 8: Commissioning Checklist
Smoke test completed on installed appliance? Spillage test complete? Has the use of the appliance, operation and controls been explained? Clearance to combustible materials checked? Instruction book handed to the customer? CO Alarm fitted? Signature:……………………………………………….. Print Name:………………………………………………… Page 8 100KC-I04-010317... -
Page 9: Installing The Stove
With these undone, the stove top can be removed allowing access to the cast flue collar. A rear flue box attachment is also available from ESSE that allows the stove to be installed further out of any building recess. Fig.1 shows suitable flue connections. -
Page 10: Operating Instructions
Your stove should not be used as an incinerator and only recommended fuels shall be used. Parts of the appliance, especially the external surfaces, will be hot to touch when in operation and due care will need to be taken Page 10 100KC-I04-010317... - Page 11 A flue blanking plug to blank the top flue outlet if the rear flue outlet is to be used. Always use stove Fig. 5 – Stove Controls mitts when adjusting controls and opening or closing the door. Page 11 100KC-I04-010317...
-
Page 12: Wood Burning
If the fire dies down too low, opening the primary air control for a short period will revive it. When reviving a low fire it is important to also use kindling before adding larger logs to help prevent smoke. Page 12 100KC-I04-010317... - Page 13 TYPES OF WOOD FOR FUEL For best results use well-seasoned hardwood such as Oak, Ash or Beech. Allow wood to dry out under cover in well-ventilated conditions for at least twelve months. As a rough Page 13 100KC-I04-010317...
-
Page 14: Solid Mineral Fuel Burning
Add the fuel sloping it from the front coal bar up to the back of the stove to the level of the top of the back brick. Open the primary air inlet and let the fire burn for Page 14 100KC-I04-010317... -
Page 15: Technical Information
This is normal for this type of appliance. TECHNICAL INFORMATION Normal heat output - wood 5.0kW Weight of stove 83.6kg Minimum chimney draught 10Pa Mean flue gas temperature - Wood 229°C Flue gas mass flow – Wood 3.1g/s Page 15 100KC-I04-010317... -
Page 16: Maintenance
Close the door and open the air inlets fully. This action will allow air circulation through the flue ways and help avoid corrosion and condensation. SERVICING Regular maintenance should be carried out by a competent engineer. Page 16 100KC-I04-010317... -
Page 17: Guarantee
Your ESSE is guaranteed against defects arising from faulty manufacture for 2 years when supplied by an ESSE Specialist. Upon registration of the warranty, ESSE will extend the guarantee period to 5 years from purchase. Your details must be registered with us by either returning the completed warranty card or by completing registration on-line at www.esse.com. - Page 18 Page 18 100KC-I04-010317...
- Page 19 Page 19 100KC-I04-010317...
- Page 20 ESSE Engineering Limited, Ouzledale Foundry, Long Ing, Barnoldswick, Lancashire BB18 6BJ Tel. 01282 813 235, Fax: 01282 816 876 Website and On-line Store http://www.esse.com Page 20 100KC-I04-010317...
