GUARANTEE
Conditions of Guarantee
Your ESSE stove is guaranteed against defects arising from faulty manufacture for one year
subject to the following express conditions. Failure to comply with these conditions will invalidate
the guarantee.
•
Your ESSE dealer or a suitably qualified engineer must install the stove. Upon
installation the receipt must be kept as proof of purchase.
•
The guarantee is one year from date of purchase.
•
The guarantee does not cover parts deemed to be replaceable in the normal usage of
the stove. These parts are: glass panels, rope seals, glass seals, bottom grate, ashpan,
firebricks, baffle plate.
How to Proceed with a Complaint
If you have cause for dissatisfaction with your stove, you should first contact your ESSE dealer,
who will bring your concerns to our attention, We will assess the nature of the complaint and
either send replacements parts for your dealer to fit, or nominate a regional engineer to inspect
the appliance and carry out any remedial work that may be necessary. If the fault is not actually
due to faulty manufacture but some other cause i.e. misuse, failure to install correctly, or failure
to service at regular intervals, a charge will be made to cover the cost of the visit and any new
st
parts required. In the 1
year ESSE will only deal with the dealer direct.
Spare Parts
Only genuine ESSE spare parts are recommended, Parts that may need occasional replacement
are:
Fire bricks
Ashpan
Fire grate
Fire bricks
Mitt
Baffle
ESSE Engineering Limited, Ouzledale Foundry, Long Ing, Barnoldswick, Lancashire, BB18 6BN
Tel: 01282 813 235, Fax: 01282 816 876, e-mail: enquiries@esse.com
Website: http://www.esse.com, On-line store: http://www.esseparts.com
12
03/10
SMOKE EXEMPT WOODBURNING STOVE
INSTALLATION & USER INSTRUCTIONS
GB IE
100SE
(TO BE LEFT WITH THE CUSTOMER)
UK & Ireland
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Esse 100SE
Summary of Contents for Esse 100SE
- Page 1 SMOKE EXEMPT WOODBURNING STOVE How to Proceed with a Complaint If you have cause for dissatisfaction with your stove, you should first contact your ESSE dealer, who will bring your concerns to our attention, We will assess the nature of the complaint and either send replacements parts for your dealer to fit, or nominate a regional engineer to inspect the appliance and carry out any remedial work that may be necessary.
- Page 2 • Should it be likely that children, aged or infirm people approach the fire, then a fireguard the flue gases. The optional rear flue box attachment available from ESSE has a should be fitted.
- Page 3 Fig. 1 – Ideal Flue Connections. FLUE DRAUGHT The chimney can be checked, before the stove is installed, with a smoke match. If the chimney doesn’t pull the smoke it may suggest the chimney needs attention (see the Flue Diagnosis Table, below).
- Page 4 – see Fig.4. A rear flue box attachment is also available Fig. 3 – Stove Dimensions from ESSE that allows the stove to be installed further out of any building recess. Fig.1 shows suitable flue connections.
- Page 5 Fig. 5 – Using the Stove Mitt primary air control using the stove mitt as shown in Fig.5. The burning rate of the stove can now be regulated by the rate at which fuel is added and by adjusting the air wash control. With the above in mind it is plain to see that the stove should ideally be run with the primary air inlet closed and the air wash control open whenever possible.
- Page 6 Extended Burning MAINTENANCE Loading a large amount of wood into the stove all at once will reduce the temperature inside the Cleaning the Stove stove. If the temperature is too low, the gases given off from the wood will be too low to combust The stove should only be cleaned when it is cold.
