BRD02 Traffic Detector
Installation and Wiring
Menu selection
©
2021 QG V2 BRD02
Setting instruction:
1. Press and hold the button for 3 seconds.
2. Wait till all 3 LED light starts to blink.
3. The red light will be blinking from left to right.
4. Let go the button when the blinking LED is the menu you
want. (Look at Table 1)
5. The LED will turn green once in the setting.
6. Adjust setting by using the button.
7. After done, press and hold the button until all red LED
flash then let go the button, it will automatically save and
exits the menu.
*(Note: After setting, it must be saved; otherwise the setting
will not change and the detector will automatically exit the
menu setting after 10 seconds)
QUICK GUIDE
05 Oct 2021, V2
1
Advertisement
Related Manuals for MAG BRD02
Summary of Contents for MAG BRD02
- Page 1 *(Note: After setting, it must be saved; otherwise the setting will not change and the detector will automatically exit the menu setting after 10 seconds) © 2021 QG V2 BRD02...
- Page 2 * Make sure to use low noise power supply. Setting instruction: 1. Before start update background make sure there is nothing in *Only install the BRD02 on flat surface and do not front of the radar detector distance.(Default distance 2.5 install it in front uneven road surface.
