ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows
the
degree
assembling a specific product (with 1 being easy
and 5 being difficult). For some products, two
persons are recommended.
EASY
Assembly Instructions
CM7386Q/F
of
effort
needed
DIFFICULT
Tools Required For Assembly:
in
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 5
(Included)
(Not Included)
Rev: 16-11-23
Advertisement
Table of Contents
Related Manuals for Furniture of America CM7386Q/F
Summary of Contents for Furniture of America CM7386Q/F
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7386Q/F Tools Required For Assembly: ASSEMBLY RATING The Assembly Rating is a 5-point system that shows degree effort needed Allen Wrench assembling a specific product (with 1 being easy (Included) and 5 being difficult). For some products, two Phillips Screwdriver persons are recommended.
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #A x 6pcs #1 x 1pc Bolt Ø1/4" x 1-3/8" Headboard #B x 6pcs #2 x 2pcs Lock washer Ø1/4"...
- Page 4 Prepare 6 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align headboard legs (#2R/L) to the holes of the headboard (#1). Secure with bolts (#A). #A x 6pcs #B x 6pcs #C x 6pcs Hook the side rails (#4) to the latch of the headboard (#1) and footboard (#3).
- Page 5 Attach 4 support legs (#7) to center rail (#6). Adjust floor protector according to ground level. Align slats (#5) to the side rails (#4) and center rail (#6), then secure with screws (#E). #E x 12pcs ASSEMBLY IS COMPLETED Page 5 of 5...
