CCTR-622G 2G/3G(WCDMA) Tracker User Manual
Welcome to use this personal tracker. This product is with GSM/WCDMA module, that has many new and
unique functions, such as super power saving technology, real time uploading current location to server, check
current location by SMS or app on mobile phone or website etc. It contains high capacity rechargeable polymer
battery (1000mAH), standby time can reach 5 days. It can work without platform, just send SMS to check current
location, also it can upload location to sever by user setting time interval, and user can check current location &
playback history tracking on mobile app or PC web visiting.
The tracking website: www.999gps.net, the account user name is the last 7 numbers of the tracker ID, the
password is same with user name or 123456. For example, the ID is 622201501688001, then the primary account is
1688001, password is 1688001 or 123456.
Using the unique username and password, user can check the history track max to 6-12 months, the real time
location. It is suit for personal user or fleet user, and it can locate object by visiting website with mobile phone or PC,
Android App or iOS iPhone App on mobile phone, sending sms to get location Google map link etc.
Scan the following QR code or click the following link can download or read online the manual in Word or Pdf
format.
Word Version:
http://www.999gps.org/en/CCTR-622G-GPStracker-en-V2.doc
Pdf Version:
http://www.999gps.org/en/CCTR-622G-GPStracker-en-V2.pdf
QR-Manual Download (Word)
iPhone App Download
QR-Manual Download (Pdf)
Android App Download
1
-
-
Advertisement
Table of Contents
Related Manuals for Response CCTR-622G
Summary of Contents for Response CCTR-622G
- Page 1 CCTR-622G 2G/3G(WCDMA) Tracker User Manual Welcome to use this personal tracker. This product is with GSM/WCDMA module, that has many new and unique functions, such as super power saving technology, real time uploading current location to server, check current location by SMS or app on mobile phone or website etc. It contains high capacity rechargeable polymer battery (1000mAH), standby time can reach 5 days.
-
Page 2: Packing List
Packing list: GPS tracker, USB Charging Wire, Home AC charger (Optional), Car Adapter (Optional). USB Charging Wire Optional Accessory Car Adapter (Optional) USA AC Adapter (Optional) Europe AC Adapter (Optional) Function Specification: 5 independent in/out Geo-fence alarm can be set; ... - Page 3 internet data service, in which the SIM card phone number is the very tracker number and all the operation for the tracker is to this number, such as locating immediately, add & delete preset number, change password, enable over speed alarm, enable move alarm etc. Note: 1.
- Page 4 simultaneity, then power on. After the GREEN led flashes 5 Before power on, press the button B and C seconds, release the button, then the unit will re-power on, and reset to factory. 6. Antenna The Antenna is built in the tracker.Pleas leave the tracker away from big metal, this will reduce the GSMWCDMA or GPS signal.
- Page 5 confirm the APN & GPRS is right, please refer the following Senior Operation & Setting 6 to set APN & GPRS username and password. 10. Different working mode make the big different battery time, the battery can be from 1 days to 5 days. In the following content, all the SMS content is mark by “”, and this “”...
- Page 6 4. LBS Located (GSM network Cell ID Locate): When the tracker is triggered to locate, the tracker will reply SMS with CELL ID location to user, and the precision is about 50-500m, according to the around mobile phone base station density. The location SMS is like below, click the link the map is same with the above 2.
- Page 7 2. Delete Authorized Phone Number by SMS Send SMS “DELETEPHONE*123456*A” to the tracker number, “DELETEPHONE” is command; “123456” is password; “A” is authorized phone number location, there are 3 locations “A” and “B” and “C”; if the delete operation is success, the tracker will send back the information ”Delete Authorized Phone OK”. 3.
- Page 8 back information “Wrong Password”. 7. Enable And Disable Overspeed Alarm (No Platform Necessary) Send SMS “OVERSPEEDALARMON*123456*SSS” to the tracker number, “OVERSPEEDALARMON” is command, “123456” is password, “SSS” is the setting alarm speed, unit is km/hour. The tracker will send back the information “Set Overspeed Alarm On :SSS km/h”...
- Page 9 If the operation successes, a SMS would be back,”set fence (Geo-Name) alarm off”. 9. Check Alarm Setting Send SMS “ALARM*123456” to the tracker number, “ALARM” is command, “123456” is password, the tracker will send back the information of the alarm setting, for example: Fence:OFF(100km/h),Over speed alarm:OFF, Alarm calling:ON, Alarm SMS:ON 10.
- Page 10 “123456” is password, “13987654321” is the number that the tracker need to call back, if no phone number the tracker will call back to the command sender. After receive the command, the tracker will call the number in the command or call back the command sender, after the calling is connected, user can hear the sound around the tracker, but the tracker can not hear anything, it is different with talking, hang up the calling the listen command will stop.
-
Page 11: Platform Operation
CMNET :Current APN User :GPRS User Name Password :GPRS Password 460,00,255,1,9376,3613,07 :GSM Base Station Information "MCC,MNC,TA,NUM,LAC, CID,RXLEV ,LAC2,CID2,RXLEV2..." :Built in Battery Power 17. Re-power On & Reset Tracker Send SMS “RESET*123456” to the tracker number, “RESET” is a command, “123456” is password. The tracker will send back information “Reset Tracker and cancel all alarm setting”, then the tracker will power off and then power on automatically, and this command will not cancel user setting. -
Page 12: Troubleshooting
The tracking data on our server will keep 6-12 months, the old data will be deleted. After power on the tracker, call the tracker, no response, and no ring, please confirm the SIM card has been installed properly, and the SIM card has enough charge, and the mobile phone can work well in that place. -
Page 13: Specification
User Mobile Phone Tracker SIM card Date Year month Model CCTR-622G ID Number Distributor Notes: The explanation of this manual is belonged to our company, some small changes may not notice customer, if you have any problem please contact us, thanks !
