Summary of Contents for Response LA9015
-
Page 2: Quick Guide
App name: For example: ResponseGPS Serial number: CC2014012345678 Username: 2345678 Password: 2345678 7.Free Response GPS app is available on iTunes and www.responsegps.com tracking platform to easily view the current tracking location on your iOS or Android smart phone or tablet. -
Page 3: Product Picture
Product Picture Solar Panel LED Indicator SOS Button Charging Point Specification Portable design, no installation charge Solar panel can extend battery using time Extra big rechargeable battery (4000 mAH) Extra power magnetic pin & water-proof design Auto download & configuration setting for APN & GPRS Upload &... - Page 4 2.Install SIM card Pulling out the long narrow rubber stopple beside the tracker, you can see the SIM card socket, beside which, press the yellow switch button with a tool and then the holder will come out. Pull it out and put the SIM card in the holder and then push the holder into the tracker (Pay attention to that the SIM card metal contact pin cannot face down to the holder), and push the long narrow rubber stopple into the tracker to cover the SIM card socket.
- Page 5 3.LED flash indicator GREEN LED Flash once: GSM & GPS working well GREEN LED Flash twice: GSM working well and no GPS signal GREEN LED Flash three times: GSM & GPS working well but battery low GREEN LED Flash four times: GSM working well,battery low and no GPS signal GREEN LED ON continuously: GSM searching network GREEN LED OFF continuously: Power off GREEN LED Flash fast: incoming a call or sending SMS...
- Page 6 5.Low Battery Alarm: When the tracker battery voltage is low,the GREEN LED of the tracker will flash 3 or 4 times,and then the tracker will send battery low information SMS to the preset phone. Low power Battery: 8% 6.Back to default set (Factory configuration) Send the SMS command to the tracker can reset to the factory configuration.
- Page 7 Simply Using Step 1. First to buy a 2G GSM phone SIM card and enable GPRS service, order a data package 20-30M (Normally tracker will use 20M data every month), install in the tracker, please refer Before Using 2. 2. Press any SOS button till the Green LED on continuously, the tracker is powered on;...
- Page 8 If the tracker has set the authorized phone number, then only authorized number calling the tracker can trigger the tracker locate and reply SMS,other phone number calling has no response. The SMS information sample is as follow: https://maps.google.com/maps?q=22.67680N,114.15188E...
- Page 9 3. Send an SMS trigger reply Google map link SMS (Platform is not necessary): Send SMS LINKLOCATE*123456 to the tracker also can trigger the tracker locate & reply Google map link SMS, LINKLOCATE is a command, 123456 is password; if the password is not right, the operation is fault, the tracker will send back information "...
- Page 10 5. Cell ID Locate When user trigger tracker reply location by SMS, if the tracker is in the place where there is no GPS signal, such as underground park, indoor room, the tracker will reply SMS with CELL ID location to user, and the precision is about 50-500m, according to the around mobile phone base station density.
- Page 11 Check tracker password Send SMS CHECKPASSWORD to the tracker, CHECKPASSWORD is a command, if the operation is success, the tracker will send back the information Password 888888 ; 888888 is an example. Note: Only The authorized phone can check the password. 3.
- Page 12 Note: In the mode 3, if you need change the set or operate other function, you can send the SMS command and wait for response, the tracker will receive SMS and operate the command when the tracker weak up after the setting interval time.
- Page 13 6. Set the upload time interval In the GSM work mode 1, the GPS location information upload time can be set from 30 to 999 seconds. Send SMS "INTERVAL*123456*yyy" to tracker, INTERVAL is a command, 123456 is password, is the interval time from 30 to 999, unit is second.
- Page 14 Note: This command is usually used to check the tracker current status & configuration, if the tracker cannot work well, this command can check what the problem is. 9. Re-power On & Reset Tracker Send SMS "RESET*123456" to tracker, "RESET" is a command, "123456" is password.
- Page 15 12. Enable And Disable Shock Alarm Send SMS SHOCKALARMON*123456 SHOCKALARMOFF*123 to the tracker, SHOCKALARMON SHOCKALARMOFF is a command, 123456 is password, the tracker will send back the information Set Shock Alarm On Set Shock Alarm Off to indicate the operation is success, if the password is not right, the operation is fault, the tracker will send back information Wrong Password .
- Page 16 greater than 1000 meters, the alarm will trigger and the tracker will send alarm and location information by SMS to the preset phone, and also send the alarm information to the website server. If the change are not canceled, every authorized phone would receive max 3 alarm SMS per hour.
-
Page 17: Platform Operation
Platform Operation The platform operation please refer the platform operation guide, scan the following QR code or click the website link to download the platform manual, visit website www.responsegps.com www.999gps.net and click the Manual icon also can download the platform manual. Platform User Guide Platform User Guide Word Version... -
Page 18: Troubleshooting
Notes: 1. This tracker use 2G GSM network, and it upload tracking only through 2G GPRS, it cannot work in CDMA network or 3G (WCDMA or CDMA2000) network, Some 3G card can work in 2G GSM network, then this kind of 3G SIM card can be used in this tracker, please call mobile phone company to confirm the SIM card support 2G GSM network or not. -
Page 19: Specifications
4. If the tracker cannot send back information by SMS, please confirm the SIM card has ID caller display function and SMS service function, and please read the SMS information of the tracker sending back, and check the instruction & password is right or not. 5.
