Start Here
Quickstart Guide - AyrMesh
Check Contents of the box:
1. Hub2x2
C
2. Antennae (2)
3. Power Supply
4. Power Cord
5. (2) Ethernet Cables (1
shorter, 1 longer)
6. (2) Zip Ties (not shown)
7. (2) Screws (not shown)
1
3
4
2
5
Turn over for shorter instructions
®
Hub2x2C
Remove the door, write down the MAC address
of your Hub, write it here, and keep it with these
directions in a safe place:
MAC Address
If you don't have an account on AyrMesh.com,
create one now using a device connected to your
network (not a cellphone unless it's connected to
your router via WiFi):
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AYRSTONE AyrMesh
Summary of Contents for AYRSTONE AyrMesh
- Page 1 6. (2) Zip Ties (not shown) 7. (2) Screws (not shown) MAC Address If you don't have an account on AyrMesh.com, create one now using a device connected to your network (not a cellphone unless it's connected to your router via WiFi):...
- Page 2 Assemble the Hub and connect to router Plug an Ethernet cable into either port on Screw the antennae the Hub - slide in until it clicks in place: gently onto the threads on the Hub - nger-tight (no tools): DO NOT FORCE CONNECTORS IN OR OUT OF PORTS! Use another Ethernet cable to connect...
- Page 3 If it hasn't it's on its side). When the Hub has checked in to shown up after 5 minutes, try adding it manually AyrMesh.com, just the top signal light will be on. with the MAC address: Hub checking in...
- Page 4 Enter the passkey (default: your network! Ayrmesh ) Changes on AyrMesh.com may take up to half an hour to take e ect on your network - the Hubs wait before changing to make sure all the devices in the network receive the new con guration.
- Page 5 SIGNAL LIGHTS CONTINUE TO "CHASE" AND/OR HUB DOES NOT CHECK IN • TO AYRMESH.COM - If Hub does not appear in your account, enter the MAC address into your account on AyrMesh.com by hand. - Gateway Hub - check the cables between the Hub and the power supply and the power supply and the router - replace with known-good short Ethernet cables.
- Page 6 GET READY: Write down the MAC address of the Hub in the box below and put it someplace safe. If you haven't already, create an account on AyrMesh.com from a computer connected to the same router that the Hub will be connected to. This ensures you won't have to enter the Hub's MAC address manually.
Need help?
Do you have a question about the AyrMesh and is the answer not in the manual?
Questions and answers
My Unit, model Ayrmesh Hub2x2C, although connected correctly -router, power, everything has been checked, stopped working...no lights at all.
The AYRSTONE AyrMesh Hub2x2C may not be powering on and showing no lights because:
1. The power supply light is not on steady. This could indicate the power cable is not fully plugged into the power supply or wall plug.
2. The wall plug may not be providing power.
3. The power supply itself may be faulty and not lighting up.
To troubleshoot, ensure all cables are fully connected and try using a known-good short Ethernet cable. If the power supply still does not light up, contact Ayrstone support.
This answer is automatically generated
Ayrmesh stopped working. No signal from it. I haven’t climbed up on the roof yet, but from the ground, in the daylight, with binoculars, I see no green lights. Checked all connections on the ground. Can the power box go bad? Any thoughts besides going up on the roof and checking that connection? Thanks.
lost 2.5 cant hook up cameras all was working fine and then they went off line iphone wifi works great
