- Page 1 FCC ID : BEJL15NY APPENDIX F : USER’S MANUAL...
- Page 2 User’s Guide L1510P ake sure to read the Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for furture reference. ee the label attached on the back cover and quote this information to your dealer when you require service.
-
Page 3: Canadian Doc Notice
Regulatory Information FCC Compliance Statement CE Conformity Notice (for Europe) This equipment has been tested and found to comply within Products with the “ C E ” Marking comply with the EMC the limits of a Class B digital device pursuant to Part 15 of Directive(89/336/EEC) and LOW VOLTAGE Directive the FCC Rules. - Page 4 Regulatory Information cont. scheme, which provides for international environmental Lead can be found in picture tubes, display screens, solder, labelling of personal computers. The labelling scheme was and capacitors. Lead damages the nervous system and in developed as a joint effort by the TCO (The Swedish higher doses causes lead poisoning.
- Page 5 Regulatory Information cont. TCO99 The energy requirements include a demand that the computer and/or display, after a certain period of inactivity, shall reduce its power consumption to a lower level in one or more stages. The length of time to reactivate the computer shall be reasonable for Congratulations! the user.
- Page 6 (U.S.A only) is a set of power-saving guidelines NERGY issued by the U.S. Environmental Protection Agency(EPA). As an ENERGY STAR Partner LG Electronics U.S.A.,Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency. EPA POLLUTION PREVENTER...
-
Page 7: Important Precautions
Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential eletrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing. - Page 8 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
-
Page 9: Connecting The Display
Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Positioning your display Remove the tape. <Image 2> <Image 1> Do not remove the tape Put the set as the with the set up side picture below... -
Page 10: Using The Computer
Connecting the Display Using the Computer Connect the signal cable. When attached, tighten the thumbscrews to secure the connection. Connect the power cord into a proper power outlet that is easily accessible and close to the display. NOTE This is a simplified representation of the rear view. This rear view represents a general model;... -
Page 11: Control Panel Functions
Control Panel Functions Front Panel Controls Control Function Use this button to turn the display on or off. Power Button This Indicator lights up green when the display Power (DPMS) operates normally. If the display is in DPM (Energy Indicator Saving) mode, this indicator color changes to amber. - Page 12 Control Panel Functions Control Direct Access Function This feature lets you easily select the best desired image condition optimized to the environment NIGHT (ambient illumination, image types etc). • DAY : Bright ambient illumination • NIGHT : Dark ambient illumination •...
-
Page 13: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The following section is an outline of the available adjustments and selections you can make using the OSD. -
Page 14: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub menu Reference To adjust the brightness, PICTURE BRIGHTNESS contrast and gamma of the CONTRAST screen GAMMA COLOR PRESET 6500K To customize the color of the screen... - Page 15 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. NOTE OSD (On Screen Display) menu languages on the monitor may differ from the manual.
- Page 16 On Screen Display(OSD) Selection and Adjustment To improve the clarity and stability of the screen OSD Adjust Description CLOCK To minimize any vertical bars or T R A C K I N G stripes visible on the screen background.The horizontal screen size will also change.
-
Page 17: Troubleshooting
Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the Check and see if the power cord is connected display connected? properly to the power outlet. Is the power indicator Press the Power button. -
Page 18: Display Image Is Incorrect
Troubleshooting Display image is incorrect Display Position is Press the AUTO/SELECT button to incorrect. automatically adjust your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display. Check Control Panel -->... -
Page 19: Have You Installed The Display Driver
Troubleshooting Have you installed the display driver? Have you installed the Be sure to install the display driver from the display driver? display driver CD (or diskette) that comes with your display. Or, you can also download the driver from our web site: http://www.lge.com. Do you see an Make sure to check if the video card supports "Unrecognized monitor,... -
Page 20: Specifications
Specifications Display 15 inches (38.1cm) Flat Panel Active matrix-TFT LCD Anti-Glare coating 15 inches viewable 0.297mm pixel pitch Sync Input Horizontal Freq. 30 - 63kHz (Automatic) Vertical Freq. 56 - 75Hz (Automatic) Input Form Separate TTL, Positive/Negative SOG (Sync On Green) Digital Signal Input 15 pin D-Sub connector... -
Page 21: Preset Modes (Resolution)
Specifications Preset Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.468 640 x 350 31.468 720 x 400 31.469 640 x 480 VESA 35.000 640 x 480 66.67 37.861 VESA 640 x 480 72.8 37.500 VESA 640 x 480 VESA 35.156 800 x 600... - Page 22 Specifications VESA wall mounting Connected to another object (stand type and wall-mounted type. This monitor accepts a VESA-compliant mounting interface pad.- optional) For further information, refer to the VESA Wall Mounting Instruction Guide. Kensington Security Slot- optional Connected to a locking cable that can be purchased separately at most computer stores...
-
Page 23: Signal Connector Pin Assignment
Specifications Signal Connector Pin Assignment DVI-D Connector Signal(DVI-D) Signal(DVI-D) T. M. D. S. Data2- Hot Plug Detect T. M. D. S. Data2+ T. M. D. S. Data0- T. M. D. S. Data2/4 Shield T. M. D. S. Data0+ T. M. D. S. Data4- T. -
Page 24: Usb Connection
Making use of USB (Universal Serial Bus) - Optional USB (Universal Serial Bus) is an innovation in connecting your different desktop peripherals conveniently to your computer. By using the USB, you will be able to connect your mouse, keyboard, and other peripherals to your display instead of having to connect them to your computer. -
Page 25: Usb Specifications
Making use of USB (Universal Serial Bus) - Optional USB Specifications Rev. 1.1 complied BUS-powered hub USB standard 100mA for each (MAX) Downstream power supply 12 Mbps (full), 1.5 Mbps (low) Communication speed USB port 1 Upstream port 2 Downstream ports IMPORTANT: These USB connectors are not designed for use with high-power USB devices such as a video camera, scanner, etc. - Page 26 Digitally yours...
