- Page 1 Service Guide Specification 담 당 관 리 자 Model Description L1553S-SFQ/BFQ MODEL BRAND Part No. MFL30290837 FLATRON L1553S-SF/BF SUFFIX Product Name Printing Specification 1. Trim Size (Format) : 215mm x 280 mm 2. Printing Colors • Cover : LG COLORS •...
- Page 2 Pagination sheet Pagination sheet P/NO.MFL30290837 Total pages :28pages Front cover English English English English English Cover Inside blank …. ….. English English English English English Rear cover Rear Inside Cover ….
- Page 3 Website:http://biz.LGservice.com E-mail:http://www.LGEservice.com/techsup.html COLOR MONITOR SERVICE MANUAL CHASSIS NO. : CL-82 MODEL: L1553S(L1553S-SFQ.ACN*QP N ) L1553S(L1553S-BFQ.ACN*QP N ) ) **Same model for Service CAUTION BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. *To apply the MSTAR Chip.
-
Page 4: Table Of Contents
CONTENTS SPECIFICATIONS ........... 2 SERVICE OSD ............13 PRECAUTIONS ............3 TROUBLESHOOTING GUIDE ......14 TIMING CHART ............7 WIRING DIAGRAM ..........18 DISASSEMBLY ............8 EXPLODED VIEW...........19 BLOCK DIAGRAM ........... 9 REPLACEMENT PARTS LIST .......21 DESCRIPTION OF BLOCK DIAGRAM....10 SCHEMATIC DIAGRAM ......... -
Page 5: Precautions
PRECAUTION WARNING WARNING FOR THE SAFETY-RELATED COMPONENT. BE CAREFUL ELECTRIC SHOCK ! • There are some special components used in LCD monitor that are important for safety. These parts are • If you want to replace with the new backlight (CCFL) or marked on the schematic diagram and the inverter circuit, must disconnect the AC adapter... - Page 6 SERVICING PRECAUTIONS CAUTION: Before servicing receivers covered by this 9. Use with this receiver only the test fixtures specified in service manual and its supplements and addenda, read this service manual. and follow the SAFETY PRECAUTIONS on page 3 of this CAUTION: Do not connect the test fixture ground strap publication.
- Page 7 General Soldering Guidelines Replacement 1. Use a grounded-tip, low-wattage soldering iron and 1. Carefully insert the replacement IC in the circuit board. appropriate tip size and shape that will maintain tip 2. Carefully bend each IC lead against the circuit foil pad and solder it.
- Page 8 Circuit Board Foil Repair At Other Connections Excessive heat applied to the copper foil of any printed Use the following technique to repair the defective copper circuit board will weaken the adhesive that bonds the foil pattern at connections other than IC Pins. This technique to the circuit board causing the foil to separate from or involves the installation of a jumper wire on the "lift-off"...
-
Page 9: Timing Chart
TIMING CHART VIDEO SYNC << Dot Clock (MHz), Horizontal Frequency (kHz), Vertical Frequency (Hz), Horizontal etc... (µs), Vertical etc... (ms) >> Total Video Sync Front Blanking Sync MODE H / V Frequency Period Active Duration Porch Time Resolution Polarity Clock ( E ) Time ( A ) ( D ) -
Page 10: Disassembly
DISASSEMBLY-Set Disassembly Like a picture. # 2-1 # 2-2 1. Pull the front cover upward. 2. Then, let the all latches are separated.(#3-1~3-2) 3. Put the front face down. Disassemble back cover. - 8 -... - Page 11 DISASSEMBLY-Stand 1. In assembly state, Twist Stand Body to 2. Pull Stand and Separate Stand from Right side. Monitor set. # 3-1 # 3-2 3. Push the four latches on the bottom to the outside and Separate Stand Body & Base. (Reference the #3-2) - 9 -...
-
Page 12: Block Diagram
BLOCK DIAGRAM - 9 -... -
Page 13: Description Of Block Diagram
DESCRIPTION OF BLOCK DIAGRAM 1. Video Controller Part. This part amplifies the level of video signal for the digital conversion and converts from the analog video signal to the digital video signal using a pixel clock. The pixel clock for each mode is generated by the PLL. The range of the pixel clock is from 25MHz to 78.75MHz. -
Page 14: Adjustment
ADJUSTMENT Windows EDID V1.0 User Manual 2. EDID Read & Write 1) Run WinEDID.exe Operating System: MS Windows 98, 2000, XP Port Setup: Windows 98 => Don’t need setup Windows 2000, XP => Need to Port Setup. This program is available to LCD Monitor only. 1. -
Page 15: Service Osd
SERVICE OSD 1) Turn off the power switch at the front side of the display. 2) Wait for about 5 seconds and press MENU, POWER switch with 1 second interval. 3) The SVC OSD menu contains additional menus that the User OSD menu as described below. a) Auto Color : W/B balance and Automatically sets the gain and offset value. -
Page 16: Troubleshooting Guide
TROUBLESHOOTING GUIDE 1. NO POWER NO POWER (POWER INDICATOR OFF) CHECK ADAPTER LED IS IT GREEN? CHECK ADAPTER OUTPUT VOLTAGE(12V)? CHECK CHECK 3.3 LINE U801 PIN1 VOLTAGE (OPEN CHECK) (3.3V) ? NO PROBLEM CHECK U803 PIN3(1.8V) IS U201 PIN90 (3.3V) CHECK 3.3V LINE VOLTAGE ? CHECK U201 PIN 96... - Page 17 2. NO RASTER (OSD IS NOT DISPLAYED) – LIPS NO RASTER (OSD IS NOT DISPLAYED) CHECK ADAPTER AND U701 12 LINE PIN13 12V? CHECK MICOM INV U701 PIN2 ON/OFF PORT. OVER THAN 1.5V? 1. CONFIRM BRIGHTNESS OSD CONTRL STATE. U701 PIN8 2.
- Page 18 3. NO RASTER (OSD IS NOT DISPLAYED) – Mstar NO RASTER (OSD IS NOT DISPLAYED) U201 CHECK U801 PIN 16, 75 3.3V? U201 1. CHECK PIN122, 123 PIN96, 97 SOLDERING CONDITION OSCILLATE AS 2. CHECK X201 14.31MHZ? 3. TROUBLE IN U201 U201 CHECK CONNECTION PIN27 IS 48KHz H-SYNC?
- Page 19 4. TROUBLE IN DPM TROUBLE IN DPM CHECK PC CHECK PC IS NOT GOING R442, R443 INTO DPM OFF MODE CHECK U201 PIN 27,28 CHECK H/V SYNC LINE SYNC PULSE ? TROUBLE IN U201 Waveforms 3 R217, R781 V-Sync R216, R778 H-Sync - 16 -...
-
Page 20: Exploded View
EXPLODED VIEW - 23 -... - Page 21 ACQ30329110 CLAA150XP01 DRIVER 15.0INCH 1024X768 250CD COLOR 80% - 500VS1 - CHUNGHWA PICTURE TUBES, LTD. 6304FCP005A LM150X08-TLA1 DRIVER 15.0INCH 1024X768 250CD COLOR 60% 4/3 550 VS 1 8MS, LVDS, P4 FACTORY OF LM150X08-TL03(P5) LG PHILIPS LCD . EAJ32168001 33139L7032P L1752S-BFQ.KXRDQPT BRAND NT CKD LM57A TSUM16AWL 14LANGUAGE ACQ30329002 L1552S A 15"...
-
Page 22: Replacement Parts List
REPLACEMENT PARTS LIST CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS, READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL. * NOTE : S SAFETY Mark AL ALTERNATIVE PARTS MODEL :L1553S DATE:2007.02.12 MODEL :L1553S DATE:2007.02.12 PART NO. DESCRIPTION/SPECIFICATON LOC NO PART NO. DESCRIPTION/SPECIFICATON LOC NO C A P A C I T O R S... - Page 23 MODEL :L1553S DATE:2007.01.12 MODEL :L1553S DATE:2007.02.12 PART NO. DESCRIPTION/SPECIFICATON PART NO. DESCRIPTION/SPECIFICATON LOC NO LOC NO C 7 1 0 0 C K 1 0 4 C K 5 6 A 0603B104K500CT 100nF 10% 50V X7R - 150MW SOT23 R/TP 3P 2 KEC AMERICA 55TO+125C 1608 TP PILKOR C O R P O R A T I O N E L E C T R O N I C S...
- Page 24 MODEL :L1553S DATE:2007.02.12 MODEL :L1553S DATE:2007.02.12 PART NO. DESCRIPTION/SPECIFICATON PART NO. DESCRIPTION/SPECIFICATON LOC NO LOC NO R 2 3 4 0 R J 2 0 0 1 D 6 7 7 MCR03EZPJ202 2KOHM 5% 1/10W 1608 R/TP ROHM R/TP ROHM R 7 1 2 0 R J 2 0 0 1 D 6 7 7 MCR03EZPJ202 2KOHM 5% 1/10W 1608...
- Page 25 MODEL :L1553S DATE:2007.02.12 MODEL :L1553S DATE:2007.02.12 PART NO. DESCRIPTION/SPECIFICATON LOC NO PART NO. DESCRIPTION/SPECIFICATON LOC NO 160GF TP S W 4 6 6 0 0 R 0 0 0 1 3 2 JTP1230B 1C1P 12VDC 0.05A VERTICAL Q 2 0 1 0 T R 3 9 0 4 0 9 A E KST3904 NPN 6V 60V 40V 200MA 50NA 160GF TP...
-
Page 26: Schematic Diagram
SCHEMATIC DIAGRAM 1. MAIN BOARD - 31 -... - Page 27 2. D-SUB/KEY BOARD/DC-DC - 32 -...
- Page 28 3. INVERTER - 33 -...
- Page 29 Feb. 2007 P/NO : MFL30290837 Printed in China...
