BandLuxe R558C Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
BandLuxe
R558C Series
LTE/HSPA+ Wi-Fi Router

Advertisement

Table of Contents
loading

Related Manuals for BandLuxe R558C Series

Summary of Contents for BandLuxe R558C Series

  • Page 1 User Manual BandLuxe R558C Series LTE/HSPA+ Wi-Fi Router...

  • Page 3: Table Of Contents

    Table of Contents Features ..........................3 Hardware Overview ......................4 Status ..........................12 Overview ........................... 13 System Log ........................14 Traffic Monitor ........................15 Mobile Internet ........................16 System ..........................18 System ..........................18 General Settings ........................18 Language and Style ......................... 19 Administration ........................
  • Page 4 Routing and Redirection Service ..................... 38 VPN Passthrough ........................38 WiFi ........................... 39 Advanced Settings ........................42 General Setup .......................... 43 Wireless Security ........................43 MAC-Filter ..........................47 Advanced Settings ........................48 WPS Settings ........................... 49 Firewall ..........................51 Single Port Forward ......................... 51 Port Range Forward .........................

  • Page 5: Features

    Package Contents R558C series LTE Home Router Power Adapter Features  R558C series LTE Home Router  Wi-Fi Protected Setup (WPS) Support  Uplink up to 50 Mbps  Downlink up to 100Mbps  Supports Wi-Fi 802.11 b/g/n ...

  • Page 6: Hardware Overview

    Package Contents Hardware Overview Connect 4G External Antennas if needed. 4G External Antenna Ports SIM Card Slot Insert SIM/USIM. Push-push type. Power Switch Switch on/off the router. Signal Strength Short press (1 second): Enable signal strength LED/WPS/Reset indication. button Press for 3 seconds (< 10 seconds): Active WPS.
  • Page 7 Package Contents (Red) No signal, SIM error, Service failure (no IP) ; Flashing when firmware is being updated Power LED Solid when power is on / Signal Strength LED Solid when WiFi is on; Flashing during WiFi data WiFi LED transmission / Signal Strength LED Flashing when WPS is in use /Signal Strength WPS LED...
  • Page 8 Installation Installation Connect the power Adapter to the Router( ) and connect it to an outlet. Insert your SIM card into the slot on the Router, making sure the SIM card orientation matches the SIM card slot, as shown in the picture.
  • Page 9 Installation Slide the power switch ( ) to ON. One of the following two methods can be chosen to link your PC with the Router.
  • Page 10 Installation Wireless Connection (for Windows) To connect your PC to the Router via WiFi, in Microsoft Windows, go to Control Panel > Network Connections. Right click on Wireless Network Connection and choose View Available Wireless Networks. Select default SSID [BR_LTE_xxxx] and enter default password (WPA key, refer to label on the Router‟s backside).
  • Page 11 Installation The router uses a web-based configuration utility. To access the configuration utility, open a browser (ex: Mozilla, Firefox, etc.) and enter the IP address (http://192.168.1.1) for the Router in your browser‟s address bar. Enter the router Username (admin) and Password (admin), and then click...
  • Page 12 Using Web-based Management Using Web-based Management This chapter will guide you on how to configure your router via the web-based utility. Login 1. Launch a web browser (e.g Mozilla Firefox). 2. In the address bar, enter http://192.168.1.1, then press Enter. 3.
  • Page 13 Using Web-based Management Mobile internet access will be enabled shortly after.

  • Page 14: Status

    Using Web-based Management Status This menu displays various status of the router. The associated submenu items are: Overview, System Log, VnStat Traffic Monitor, and Mobile Internet.

  • Page 15: Overview

    Using Web-based Management Overview The Overview submenu renders complete statistics for the router.

  • Page 16: System Log

    Using Web-based Management System Displays system information: router model name, router firmware version, modem firmware version, phone number (MDN), ICCID, MIN (MSID), PRL version, IMEI, MEID, and local time. Network Displays current network connection information of IPv4 WAN and/or IPv6 WAN: type of network assignment (e.g.

  • Page 17: Traffic Monitor

    Using Web-based Management Traffic Monitor Statistics Rest Traffic Flow: Click to discard previous network history log and start a new.

  • Page 18: Mobile Internet

    Using Web-based Management Mobile Internet The Mobile Internet submenu displays mobile internet statistics. Signal Quality Displays signal strength of current mobile internet connection in dBm. UICC/SIM Status Displays current SIM card status: a) Read SIM Fail – No valid SIM card is inserted b) PIN Disable(Verified) –...
  • Page 19 Using Web-based Management Registered Network a) Network Name – name of your mobile internet service provider b) Network Technology – mobile internet communication signal type. Ex: WCDMA (3G) and LTE (4G). c) Home/Roaming – displays current network roaming status: Home indicates mobile internet connection to the home location where the SIM card service is registered.

  • Page 20: System

    Using Web-based Management System This menu is for system information and configurations. System System Properties Click either the “General Settings” or “Language and Style” tab to configure their respective settings. General Settings Local Time – Displays current local time. To synchronize local time with the browser, click Hostname –...

  • Page 21: Language And Style

    Using Web-based Management Language and Style Language – Sets the desired display language and style of the router. Click and select the desired display language and style. Time Synchronization Enable NTP client: Click the checkbox to enable/disable. With this option enabled, two more options will appear–...

  • Page 22: Administration

    Using Web-based Management Administration Router Password Login password of the router can be changed here. Enter the new password in the „Password‟ field, and enter the same password once again in the „Confirmation‟ field. Remote Access This field specifies whether or not to allow remote access of this router. After changing password and/or specifying remote access, click .

  • Page 23: Backup / Flash Firmware

    Using Web-based Management Backup / Flash Firmware Backup / Restore Download backup Here you can backup all current settings of the router to a TAR archive file on your computer or mobile device. Just click . A dialog window will prompt you to open or save the archive file.

  • Page 24: Reset To Defaults

    Using Web-based Management are using, the TAR file may be saved in the system download folder or a location of your choice. Reset to defaults Here you can restore the router to its original factory settings. Just click , and a dialog message will appear to indicate the factory reset process.

  • Page 25: Reboot

    Using Web-based Management Flash new ipkg package This option allows you to upgrade this router with the updated IPKG package. Just click to find and select the IPKG package file, and then click „Open‟. Confirm that the IPKG package filename appears beside the button and click .
  • Page 26 Using Web-based Management Click „Perform reboot‟ to restart the router.

  • Page 27: Services

    Using Web-based Management Services Dynamic DNS The Services menu hosts configuration options for DDNS (Dynamic Domain Name Service), which is a system that allows the domain name data held in a name server to be updated in real time. It allows an Internet domain name to be assigned to a computer with a varying (dynamic) IP address.

  • Page 28: Network

    Using Web-based Management Network Interfaces The Interfaces submenu allows interface configurations of different networks connected to this router. The configuration items are the same for each network with different default settings. Interface Overview Here you can see the brief network status summary for LAN (local area network) and WAN (wide area network).

  • Page 29: Network Settings

    Using Web-based Management WWAN Setting Network Settings Roaming Enables or disables current roaming setting. Connection: APN Update: Displays the current APN (Access Point Name) version. To get the latest version of APN, click „Auto‟ – Uses automatic APN profile settings for APN: network;...

  • Page 30: Auto Apn Information

    Using Web-based Management Settings for network. This item appears when APN is set to „Manual‟. Profile Selection: Auto APN Information This section displays automatic APN information. APN Profile Settings For Advanced Users This section allows you to establish your own APN profile settings. To establish a new APN profile, type in a new APN profile name in the text box and click Enter the APN, username, and password.

  • Page 31: Scenario 1: No Mobile Internet Service

    Using Web-based Management UICC/SIM PIN Management This submenu features configurable items that are dependent on the router‟s mobile internet status, as detailed below. Scenario 1: No mobile internet service Without a valid SIM card inserted into the router, the Verify dialog will show the following SIM card status: Here the Verify dialog shows SIM status as “Read SIM Fail”, meaning that no valid SIM card is inserted.

  • Page 32: Scenario 3: Mobile Internet Service Enabled

    Using Web-based Management Here the Verify dialog shows the SIM status as “No Verified/Retries:3”, meaning that a valid SIM card is inserted with PIN code verification pending. Enter your SIM card verification code in the text box of “PIN Code verify:”, and then click .
  • Page 33 Using Web-based Management Setting SIM Status: Shows current SIM card status. “PIN Enable” means that the SIM card is enabled for mobile internet access. “PIN Disable(Verified/Retries:#)” means that the SIM card is enabled for mobile internet access without requiring PIN code verification. Note that if PIN protection is re-enabled, # is the number of allowed PIN verifications remaining before SIM lock occurs.

  • Page 34: Scenario 1: Sim Lock Absent

    Using Web-based Management New PIN code Enter the same new PIN code again for PIN code confirm: confirmation. after making changes in „Setting‟ and/or “Change PIN”. Click SIM Management Here you can see the current SIM lock status. Scenario 1: SIM lock absent “SIM no lock”...
  • Page 35 Using Web-based Management Preferred Network Here you can select the preferred mobile network type by clicking making a choice from the drop-down list. The default choice is Auto. Other available choice examples are LTE (4G) and WCDMA (3G).

  • Page 36: Router

    Using Web-based Management Router Router Settings Router IP Local IP Address: The default local IP address of this router is 192.168.1.1. If this address conflicts with another local network device, you can enter another local IP address here. Subnet Mask: Displays current Subnet Mask Device Name: The current device name is displayed in gray color.

  • Page 37: Dhcp Service

    Using Web-based Management DHCP Service DHCP Server: Enables or disables the DHCP Server feature. Start IP Address: Specifies the starting number of the last 3 digits of assigned client IP address. For example, the default value of 100 means that the first assigned client IP address will be 192.168.1.100;...

  • Page 38: Active Dhcp Leases

    Using Web-based Management Active DHCP Leases This section displays active DHCP lease information for each client: Hostname, IPv4 address, MAC address, and Lease time remaining. Static Leases This option allows fixed IP address and symbolic hostname assignments for DHCP clients. To add a static lease, first click Enter the desired hostname.

  • Page 39: Static Routing

    Using Web-based Management Click after making any changes. Advanced Routing settings Static Routing This option allows fixed network routing path assignment (as opposed to the initial adaptive routing). To add a static network routing path, click . To remove any unwanted static network routing path, click the corresponding button.

  • Page 40: Routing And Redirection Service

    Using Web-based Management „wan‟ (wide area network). Target: Enter the target host IP or network address here. IPv4-Netmask: Displays the IPv4-Netmask address (the default is 255.255.255.255). A custom IPv4-Netmask can also be specified here. IPv4-Gateway: If needed, a custom IPv4-Gateway address can be specified here.

  • Page 41: Wifi

    Using Web-based Management IPSec IP Security (IPSec) provides authentication and Passthrough: encryption. Since it is mainly a Layer 3 technology, it can secure all data on the network. To allow IPSec tunnels to pass through the Router, click „Enabled‟. Point-to-Point Tunneling Protocol (PPTP) allows you PPTP to establish a connection to an enterprise network.
  • Page 42 Using Web-based Management SSID and Password Example: MAC Address Corresponding SSID Default Password 0026FA0B314A BR_LTE_314A 03010410 Each tab has identical sets of configuration categories: Device Configuration and Interface Configuration. Please click after making any changes in this submenu. Device Configuration General Setup Wireless WiFi connection of the associated SSID is enabled.
  • Page 43 Using Web-based Management enabled* To disable WiFi connection of this SSID, click Wireless WiFi connection of the associated SSID is disabled. network is To enable WiFi connection of this SSID, click disabled* * Note: The associated SSID is displayed either in the selected submenu tab under WiFi or in the WiFi category item Interface Configuration ...

  • Page 44: Advanced Settings

    Using Web-based Management 2.4GHz frequency range for communications). Alternatively, you can select „auto‟ to let the system select the channel automatically, or you can select “-- custom --” and enter your own channel specification in the text box. Advanced Settings Mode Specifies the IEEE wireless standard for WiFi communication.

  • Page 45: General Setup

    Using Web-based Management Interface Configuration General Setup SSID Service Set Identification To change the SSID, click the text box and enter the new SSID (up to 32 alphanumeric characters) Mode Wireless operating mode of this router. Wireless Access Point Hide SSID Enable this option to make wireless network of this SSID unavailable to nearby WiFi clients.
  • Page 46 Using Web-based Management The encryption options are: 1. No Encryption Data transmitted over wireless networks can be seen by others. 2. WEP Open System Wired Equivalent Privacy encryption with Open System authentication Key: Enter a password for accessing this SSID‟s wireless network. 3.
  • Page 47 Using Web-based Management Force TKIP and CCMP (AES) – Use TKIP and CCMP (AES) encryption protocols together Enter a password for accessing this SSID‟s wireless network. Key: 4. WPA2-PSK “WiFi Protected Access II – Pre-Shared Key” encryption Cipher: Specifies the desired encryption protocol by clicking selecting an option from the drop-down list: auto –...
  • Page 48 Using Web-based Management selecting an option from the drop-down list: auto – (Default setting) the system automatically chooses the optimal encryption protocol Force CCMP (AES) – Use CCMP (AES) encryption exclusively (stronger than TKIP) Force TKIP – Use TKIP encryption exclusively Force TKIP and CCMP (AES) –...

  • Page 49: Mac-Filter

    Using Web-based Management authentication port (the default port number is 1812). Radius-Authentication-Secret: Enter the desired RADIUS secret password. 7. WPA2-EAP “WiFi Protected Access II – Extensible Authentication Protocol” encryption Cipher: Specifies the desired encryption protocol by clicking selecting an option from the drop-down list: auto –...

  • Page 50: Advanced Settings

    Using Web-based Management This tab item allows you to selectively allow or block clients from network access. Click and select an option from the drop-down list: 1. Disable – The MAC address filter is disabled (default option). 2. White list* – Click and select a desired MAC address from the drop-down list, or select “-- custom --"...

  • Page 51: Wps Settings

    Using Web-based Management default setting of WMM Mode is Disabled. WPS Settings WiFi Protected Setup Settings This tab item appears when „Encryption‟ in “Wireless Security” is set to one of the following: WPA-PSK, WPA2-PSK, or WPA-PSK/WPA2-PSK Mixed Mode. WPS: To enable the WPS button for quick WiFi connection setup, click „Enabled‟, and 2 additional items will appear: Mode and Start.
  • Page 52 Using Web-based Management must match the PIN of the router client. If the PIN entered is invalid, the text color will become red with on the right. Whenever the PIN entered becomes valid, the text color will be black without on the right.

  • Page 53: Firewall

    Using Web-based Management Firewall Single Port Forward Single Port Forward Port Forwarding allows you to set up public services on your network, such as web servers, ftp servers, e-mail servers, and other specialized Internet applications. To forward a single port: 1.
  • Page 54 Using Web-based Management number in the same text box. 6. Click . The port forwarding rule you have just entered will be added to the Port Forwards list. In the status area, the message Unapplied Change may appear next to “Operator Name”...

  • Page 55: Port Range Forward

    Using Web-based Management Numerical and text values shown in the illustrative examples are for Note: demonstration purposes only and are not for actual operation. Port Range Forward Port Range Forward Port Range Forward allows you to set up public services on your network, such as web servers, ftp servers, e-mail servers, and other specialized Internet applications.
  • Page 56 Using Web-based Management 1. Name: Enter an application name for this port range forwarding rule. and select a protocol from the drop down list – 2. Protocol: Click TCP+UDP (default), TCP, UDP, or Other… 3. Port Range Forward: Specify the range of port forwarding by entering the Start Port number and the End Port number.

  • Page 57: Port Trigger

    Using Web-based Management Numerical and text values shown in the illustrative examples are for Note: demonstration purposes only and are not for actual operation. Port Trigger Port Trigger Port Triggering allows the Router to watch outgoing data for specific port numbers.
  • Page 58 Using Web-based Management 1. Name: enter an application name for this port triggering rule. and select a protocol from the drop down list – 2. Protocol: click TCP+UDP (default), TCP, UDP, or Other… 3. Triggered Range: enter the Start Port and End Port for the triggered port number range of the Internet application (please check its documentation for the port number(s) needed).

  • Page 59: Security Filter

    Using Web-based Management any changes, click . Finally click to exit this configuration page. Numerical and text values shown in the illustrative examples are for Note: demonstration purposes only and are not for actual operation. Security Filter...
  • Page 60 Using Web-based Management Here you can make Firewall, Internet Filter, and Web Filters adjustments for network security. Firewall SPI Firewall Enable or Disable Stateful Packet Inspection (SPI) Protection: feature of the firewall. The default setting is „Enable‟. Internet Filter Filter Anonymous This filter blocks anonymous internet requests from Internet Requests: outside network.
  • Page 61 Using Web-based Management risk of not having access to Internet sites created using this programming language. ActiveX: ActiveX is a programming language for websites. Select this option to disable ActiveX. If you disable ActiveX, you run the risk of not having access to Internet sites created using this programming language.

  • Page 62: Network Filtering

    Using Web-based Management Network Filtering Network Filtering Network Filtering allows the Router to discard data from certain IP addresses. To add a new IP filtering rule: 1. Name: Enter an application name for this IP filtering rule. and select a protocol from the drop down list – 2.
  • Page 63 Using Web-based Management 5. Click . The Network filtering rule you have just entered will be added to the IP Filtering list. In the status area, the message Unapplied Change may appear next to “Operator Name” to indicate configuration changes stored in the router. 6.

  • Page 64: Upnp

    Using Web-based Management Numerical and text values shown in the illustrative examples are for Note: demonstration purposes only and are not for actual operation. Port Range Forward UPNP Universal Plug and Play – Allows wired and wireless network devices to discover each other and establish network services.

  • Page 65: Advanced

    Using Web-based Management Advanced Diagnostics This menu contains tools for effective network analysis and troubleshooting. Network Utilities Ping This feature allows you to check the status of a connection. 1. In the text box next to , enter the IP address or URL that you want to ping, and then select its corresponding internet protocol by clicking either the IPv4 or IPv6 radial button.

  • Page 66: Traceroute

    Using Web-based Management to begin the connection status check. „Ping‟ messages will 4. Click appear below. Traceroute This feature allows you to check the performance of a connection. 1. In the text box next to , enter the IP address or URL that you want to trace route, and then click to start the performance text.

  • Page 67: New Sms

    Using Web-based Management Short Message Service – Allows mobile phones and network devices to exchange short text messages. New SMS Here you can write and send a new SMS message. Enter the recipient‟s phone number in the field Phone number. Enter message texts in the field Contents. To erase written contents and start over again, click .
  • Page 68 Using Web-based Management...

  • Page 69: Inbox

    Using Web-based Management Inbox Here you can receive and read incoming SMS messages. To get messages from the server, click . To remove unwanted messages, select messages to delete and click...

  • Page 70: Outbox

    Using Web-based Management Outbox Here you can see SMS messages that have been sent out. To forward a particular SMS message, check only the message of interest without checking others.

  • Page 71: Draft

    Using Web-based Management Click An additional configuration item Forward SMS will appear on top of the configuration item Outbox. If necessary, modify the recipient‟s phone number in the field Phone number or modify message texts in the field Contents. To cancel message forwarding, click .
  • Page 72 Using Web-based Management Here you can review and send out SMS messages drafts that have been previously saved. To send a particular SMS draft message, check only the message of interest without checking others. Click...
  • Page 73 Using Web-based Management An additional configuration item Edit SMS will appear on top of the configuration item Draft. If necessary, modify the recipient‟s phone number in the field Phone number or modify message texts in the field Contents. To cancel sending out the SMS draft message, click .

  • Page 74: Setting

    Using Web-based Management Setting Here you can configure settings for service center and SMS backup. Setting Enter the service center phone number in the field Service Center Address and click . To clear current phone number and enter a new one, click Backup...
  • Page 75 Using Web-based Management To backup SMS messages to your local computer, click in the field Backup SMS to client. Choose Save File, click OK, and follow directions on the screen to save SMS messages on your local computer as a packed ZIP file. To recover SMS messages from your local computer, click Browse in the field Recover SMS from client and select the ZIP file that you have saved previously, and then click...

  • Page 76: Help

    Using Web-based Management Help Click the appropriate download link to download the latest Quick Start Guide or User Manual of this product. Logout Exits the web configuration interface and re-directs to login prompt. After a period of inactivity, automatic logout will occur. After clicking Note: any menu item, the login prompt will appear as re-login is needed to continue using the web configuration interface.
  • Page 77 Appendix A: FAQ Appendix A: FAQ Q: What should I know and how long does it take when I upgrade the firmware of router or modem? A: 1. While upgrading the firmware requires some time to finish. During that, MUST NOT turn off the power or interrupt the progress.
  • Page 78 Appendix A: FAQ Q: Why can't I link on the GUI? A: If you have changed your WiFi security, SSID, Local IP address, you have to repair your network to get a new IP that you can link the GUI. If you are a WiFi user, click Network Connections and right click on Wireless Network Connection, click Repair.
  • Page 79 Appendix A: FAQ 1. If you are a WiFi user, please click Network and Sharing Center > Manage network connections > Wireless Network Connection > Diagnose. 2. Please click Reset the network adapter “Wireless Network Connection” and it will began to repair. 3.
  • Page 80 Appendix A: FAQ “Wireless If you want to configure WiFi Security please click the Security” tab under “Interface Configuration”. There are seven wireless security encryption options supported by the Router: WEP Open System, WEP Shared Key, WPA-PSK, WPA2-PSK, WPA-PSK/WPA2-PSK Mixed Mode, WPA-EAP, and WPA2-EAP. Q: How can I have a long-time link? A: Click the menu tabs Network ...
  • Page 81 Appendix A: FAQ #12to#14 3 bars -90 dBm to -83 dBm -103 dBm to -95 dBm (just below) (just below) #12to#15 4 bars -83 dBm to -76 dBm -95 dBm to -87 dBm (just below) (just below) #12to#16 5 bars -76 dBm or stronger -87 dBm or stronger 2.
  • Page 82 Appendix A: FAQ Q: Why can‟t I use VPN via Router? A: You may check your office IP settings, the IP settings must not conflict with each other. Q: How do I configure the settings when I use xDSL to link the router? A: 1.
  • Page 83 Appendix A: FAQ Q: My PIN code is enabled and where can I input the PIN code to use my Router? A: Click the menu tabs Network  Mobile Internet  U/SIM PIN Management; enter your PIN Code and click Q: Why does my U/SIM status display “PIN Disable”? A: Check that the SIM card (which is properly activated by your mobile internet service provider) is...
  • Page 84 Appendix A: FAQ saved TAR file; and then click Q: How do I use the Reset button on the router? A: 1. Short press the Reset button to restart the router. 2. Long press the Reset for more than 10 sec to reset the router to factory default settings.
  • Page 85 Appendix B: Specifications Appendix B: Specifications Note: Specifications are subject to change without notice. Physical WLAN 802.11 b/g/n (2x2 MIMO) Cellular modem Embedded, LTE FDD/DC-HSPA+/HSPA+/HSPA/WCDMA Dimensions 143.6 x 73.3 x 143 (LxWxH, mm) Weight (g) Interface Power On/Off Switch RJ45 Ports Four LAN ports, each with LED indicator.
  • Page 86 Appendix B: Specifications WLAN 802.11 b/g/n, 2x2 MIMO Antenna Cellular embedded main antenna Cellular embedded Yes, supporting LTE bands diversity antenna Cellular external main antenna port Cellular external diversity antenna port WiFi antenna Embedded Router Features Routing Static Routing, Dynamic Routing (RIP) Multiple VPN pass-through (IPSec, PPTP, L2TP), Internet Access Security Policy (Parental control), Stateless and SPI Firewall...
  • Page 87 Appendix B: Specifications 802.11b data 1/2/5.5/11 Mbps rate 802.11g data Up to 54 Mbps rate 802.11n data Up to 300 Mbps rate 802.11e QoS WMM (WiFi Multimedia), No ACK WPA2/WPA/AES/TKIP, WPA/WPA2 PSK mode, None/64/128 bits Security Types WEP Encryption, open system authentication. Device Unique Default Such unique key is linked to MAC address of the device.
  • Page 88 Appendix B: Specifications Support Connection Network name, Signal strength, Roaming indication, Radio Status in Web technology, Connection status, Connection time, Total downlink/uplink byte Connection on demand, Connection when available, Auto Connection APN matching with USIM , APN database update through management browser-based GUI, PIN management, Preferred radio NW type selection, Auto/Manual network selection.
  • Page 89 Appendix B: Specifications Certification RoHS...

  • Page 90: Europe - Eu Declaration Of Conformity

    Appendix C: Important Safety Information and Glossary Appendix C: Important Safety Information and Glossary Europe – EU Declaration of Conformity European Union Notice Products with CE marking comply with the R&TTE Directive (99/5/EC), the EMC Directive (2004/108/EC), and the Low Voltage Directive (2006/95/EC) issued by the Commission of the European Community.
  • Page 91 Appendix C: Important Safety Information and Glossary directive (1995/5/EC). ETSI EN 301 489-1 Electromagnetic compatibility and Radio spectrum Matters (ERM); Electromagnetic Compatibility (EMC) standard for radio equipment and services; Part 1: Common technical requirements. ETSI EN 301 489-7 Electromagnetic compatibility and Radio spectrum Matters (ERM); Electromagnetic Compatibility (EMC) standard for radio equipment and services;...

  • Page 92: Federal Communication Commission Interference Statement

    Appendix C: Important Safety Information and Glossary Federal Communication Commission Interference Statement 15.21 You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user‟s authority to operate the equipment. 15.105(b) Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
  • Page 93 Appendix C: Important Safety Information and Glossary Federal Communications Commission for an uncontrolled environment. This equipment should operate with minimum distance 20 cm between the radiator & your body.

  • Page 94: Glossary

    Appendix C: Important Safety Information and Glossary Glossary 2G: Second-generation mobile networking technology. Represents a switchover from analog to digital; most 2G networks use GSM. 3G: Third-generation mobile networking technology that enables simultaneous transfer of voice and non-voice data; most 3G networks use WCDMA. 3.5G: A more recent standard of mobile networking technology;...
  • Page 95 Appendix C: Important Safety Information and Glossary bandwidth intensive data at up to 7.2Mbps; typically associated with 3.5G. HSUPA (High Speed Uplink Packet Access): Advanced WCDMA that delivers uplink bandwidth intensive data at up to 5.76Mbps; typically associated with 3.75G. HSPA+ (High Speed Packet Access +): This is also known as HSPA Evolved, is the next step and is more focused on delivering data services enabling speeds of up to 42Mbps in the downlink and 11Mbps in the uplink.
