Summary of Contents for Mitsubishi MOTORS ECLIPSE CROSS 2018

Page 1 ECLIPSE CROSS OWNER’S MANUAL ECLIPSE CROSS - ENGLISH - OGKE19E1...
Page 2 Abbreviations used in this owner’s manual: Repairs to your vehicle: M/T: Manual transmission LHD: Left-Hand Drive Vehicles in the warranty period: All warranty repairs must be carried out by a MITSUBISHI MOTORS Au- A/T: Automatic Transmission RHD: Right-Hand Drive thorized Service Point. CVT: Continuously Variable...
Page 3 Table of contents Overview/Quick guide General information Locking and unlocking Seats and seat belts Instruments and controls Starting and driving For pleasant driving For emergencies Vehicle care Maintenance Specifications Alphabetical index Declaration of Conformity OGKE19E1...
Page 4 Instruments and controls Instruments and controls 1. Combination headlamps and dipper switch p. 5-53 Automatic High-Beam (AHB) switch* p. 5-56 Turn-signal lever p. 5-62 Front fog lamp switch* p. 5-64 Rear fog lamp switch p. 5-64 2. Shift paddles* p. 6-35 3.
Page 5 Instruments and controls 1. Combination headlamps and dipper switch p. 5-53 Automatic High-Beam (AHB) switch p. 5-56 Turn-signal lever p. 5-62 Front fog lamp switch* p. 5-64 Rear fog lamp switch p. 5-64 2. Shift paddles* p. 6-35 3. Engine switch* p. 6-15 4.
Page 6 Instruments and controls 1. Rear window demister switch p. 5-69 2. Side ventilators p. 7-02 3. Seat belt reminder p. 4-10 4. Hazard warning flasher switch p. 5-62 5. Centre ventilators p. 7-02 6. Front passenger’s airbag indicator p. 4-29 Security indicator* p.
Page 7 Instruments and controls 1. Centre ventilators p. 7-02 2. Hazard warning flasher switch p. 5-62 3. Front passenger’s airbag indicator p. 4-29 Security indicator* p. 3-22 4. Side ventilators p. 7-02 5. Air conditioning p. 7-05, 7-10 6. Rear window demister switch p. 5-69 7.
Page 8 Instruments and controls 1. Audio* p. 7-22 DISPLAY AUDIO* Smartphone Link Display Audio* MITSUBISHI Multi-Communication System (MMCS)* Multi Around Monitor* p. 6-117 [For DISPLAY AUDIO, Smartphone Link Display Audio and MITSUBISHI Multi-Communication System (MMCS), refer to the separate owner’s manual.] 2.
Page 9 Instruments and controls 1. Audio* p. 7-22 DISPLAY AUDIO* Smartphone Link Display Audio* MITSUBISHI Multi-Communication System (MMCS)* Multi Around Monitor* p. 6-117 [For DISPLAY AUDIO, Smartphone Link Display Audio and MITSUBISHI Multi-Communication System (MMCS), refer to the separate owner’s manual.] 2.
Page 10 Interior Interior 1. Electric remote-controlled outside rear-view mirrors switch p. 6-11 2. Electric window control switch p. 3-29 3. Lock switch p. 3-31 4. Central door lock switch p. 3-17 5. Adjustable seat belt anchor p. 4-11 Seat belts p. 4-08 6.
Page 11 Interior 1. Inside rear-view mirror p. 6-10 2. Sun visors p. 7-78 Vanity mirror p. 7-78 Card holder p. 7-78 3. Adjustable seat belt anchor p. 4-11 Seat belts p. 4-08 4. Seat belt plate storage p. 4-13 5. Lock switch p. 3-31 6.
Page 12 Interior 1. Supplemental restraint system (SRS) -curtain airbag* p. 4-25, 4-33 2. Assist grips p. 7-87 Coat hook p. 7-87 3. Bottle holder p. 7-85 4. Front sunroof switch* p. 3-32 5. Room lamp switch p. 7-81 6. Hands-free microphone* p. 7-57 7.
Page 13 Interior 1. Supplemental restraint system (SRS) -curtain airbag p. 4-25, 4-33 2. Bottle holder p. 7-85 3. Rear shade switch* p. 3-32 4. Assist grips p. 7-87 Coat hook p. 7-87 5. Bottle holder p. 7-85 6. Room lamp (rear) p. 7-81 7.
Page 14 Luggage area Luggage area 1. Luggage room lamp p. 7-82 2. Tether anchorages for child restraint system p. 4-22 3. Luggage floor board p. 7-88 Jack* p. 8-11 Tools* p. 8-11 Tyre repair kit* p. 8-13 4. Luggage hooks p. 7-87 5.
Page 15 Outside (Front) Outside (Front) 1. Front view camera* p. 6-117 2. Headlamp washer* p. 5-69 3. Windscreen wipers p. 5-65, 10-14 4. Sensor* [for Automatic High-Beam (AHB), Forward Collision Mitigation System (FCM) and Lane Departure Warning (LDW)] p. 5-56, 6-79, 6-101 Rain sensor p.
Page 16 Outside (Rear) Outside (Rear) 1. Antenna 2. Keyless entry system p. 3-04 Keyless operation system* p. 3-08 Locking and unlocking the doors p. 3-09 3. Tyre pressure monitoring system (TPMS)* p. 6-105 Changing tyres p. 8-19 Tyre p. 10-10 Tyre inflation pressures p. 10-10 Tyre rotation p.
Page 17 Quick guide Keyless operation system* Quick guide When you are carrying the keyless operation Locking and unlocking the key and within the operating range, if you doors and tailgate press the driver’s or front passenger’s door lock/unlock switch (A), or the tailgate lock switch (B) (when locking) and the tailgate Keyless entry system open switch (C) (when unlocking), the doors...
Page 18 Quick guide 1-Combination headlamps Around the driver’s seat Headlamps and other lamps go Rotate the switch to turn on the lamps. Refer to “Combination headlamps and dipper switch” on page 5-53. 1-Turn-signal lever The turn-signal lamps flash when the lever is operated With the ignition switch or the operation mode is in ON, head-...
Page 19 Quick guide 3-Engine switch* 4-Wiper and washer switch 3. Securely lock the steering wheel by pull- ing the lever fully upward. If you are carrying the keyless operation key, you can start the engine. If you press the en- gine switch without depressing the brake pedal (CVT) or the clutch pedal (M/T), you can change the operation mode in the order of OFF, ACC, ON, OFF.
Page 20 Quick guide 5-Outside rear-view mirrors 7-Fuel tank filler door release Refer to “Outside rear-view mirrors” on lever page 6-11. To adjust the mirror position Open the fuel tank filler door. 6-Electric window control The fuel tank filler is located on the rear left Press the switch down for opening the win- side of your vehicle.
Page 21 Quick guide mark display screen ® p. 5-06 “R” REVERSE 2- Information screen ® p. 5-04 This position is to back up. Interrupt display screen ® p. 5-06 3- Door ajar warning display screen “N” NEUTRAL ® p. 5-07 At this position the transmission is disengag- 4- Odometer ®...
Page 22 Quick guide 4- Navigation information display screen* Refer to “S-AWC (Super-All Wheel Con- S-AWC con- Function trol)” on page 6-39. trol mode Refer to “Head Up Display (HUD)” on This mode is chiefly suita- page 5-48. ble for the snow road. SNOW S-AWC (Super-All Wheel Con- Stability improves on a...
Page 23: Table Of Contents
General information Fuel selection..................2-02 Filling the fuel tank................2-03 Telematics Control Unit (TCU)*............2-04 Installation of accessories..............2-10 Modification/alterations to the electrical or fuel systems....2-11 Genuine parts..................2-11 Safety and disposal information for used engine oil......2-11 Disposal information for used batteries..........2-12 Event Data Recording.................
Page 24: Fuel Selection
If the check engine warning lamp flashes, type petrol (containing 10 % ethanol) con- have the system checked as soon as possible forming to European standards EN 228. at a MITSUBISHI MOTORS Authorized NOTE Service Point. CAUTION The vehicles have the knock control system...
Page 25: Filling The Fuel Tank
If the tank cap must be replaced, use only a MITSUBISHI MOTORS genuine part. General information 2-03 OGKE19E1...
Page 26: Telematics Control Unit (Tcu)
TCU. side assistance. For details including system limitations, contact a MITSUBISHI MOTORS Author- CAUTION ized Service Point. After you sign a user service agreement for Do not tilt the gun. the TCU, you will be able to use the telemat- ics features on the smartphone app and call 5.
Page 27 Telematics Control Unit (TCU)* A- Indication lamp (red/green) WARNING NOTE B- Cover In a country or area where no emergency This system transmits a notification to an C- SOS switch call centre is available for the TCU, or emergency call centre, but it does not direct- D- Information switch where radio waves for the emergency call ly arrange for an emergency vehicle or road...
Page 28 Telematics Control Unit (TCU)* gency call centre operator. Once connec- 3. The green indication lamp blinks and the WARNING ted, information about your vehicle, its system calls the emergency call centre. If the indication lamps (A) do not illumi- location, and its condition will be sent to nate after setting the operation mode to the operator;...
Page 29 6. The emergency call centre arranges for a problem, etc., we recommend you to the phone call with the operator of the dispatch of the emergency vehicle as re- consult a MITSUBISHI MOTORS Au- emergency call centre. quired. thorized Service Point.
Page 30 If the green lamp does not extinguish even after the call ends, have the system inspected at a MITSUBISHI MOTORS Authorized Service Point. When the SOS emergency Illumi- Extin- The SOS emergency assistance/Infor-...
Page 31 Telematics Control Unit (TCU)* Remote control Geofence NOTE If the specified area is set beforehand us- If the doors and the tailgate are unlocked us- ing the smartphone app, an alert is sent NOTE ing the smartphone app when no doors or the to the smartphone using a short message tailgate are opened within a certain length of service (SMS), e-mail, or push notifica-...
Page 32: Installation Of Accessories
MITSUBISHI MOTORS, but also for a MITSUBISHI MOTORS Authorized Service Point, to check whether the attach- ment or installation of such parts affects the overall safety of your vehicle.
Page 33: Modification/Alterations To The Electrical Or Fuel Systems
MITSUBISHI MOTORS guidelines. cial. Maximum safety can only be ensured with parts recommended, sold and fitted or CAUTION installed by a MITSUBISHI MOTORS au- Safety and disposal thorized Service Point...
Page 34: Disposal Information For Used Batteries
Disposal information for used batteries Protect the environment Event Data Recording NOTE EDR data are recorded by your vehicle only It is illegal to pollute drains, water courses This vehicle is equipped with an event data if a non-trivial crash situation occurs; no da- and soil.
Page 35 Locking and unlocking Keys....................3-02 Electronic immobilizer (Anti-theft starting system)......3-03 Keyless entry system................3-04 Keyless operation system*..............3-08 Doors....................3-15 Central door locks................3-17 Dead Lock System*................3-18 “Child-protection” rear doors..............3-19 Tailgate....................3-20 Security alarm system*............... 3-22 Electric window control..............3-29 Power panoramic sunroof*..............3-32 OGKE19E1...
Page 36: Keys
Keys Keys WARNING NOTE When taking a key on flights, do not press • Do not clean with ultrasonic cleaners or The key fits all locks. any switches on the key while on the similar equipment. plane. If a switch is pressed on the plane, •...
Page 37: Electronic Immobilizer (Anti-Theft Starting System)
If the engine er system. Doing so could cause the immo- does not start, we recommend you to con- bilizer to malfunction. tact your MITSUBISHI MOTORS Au- thorized Service Point. Locking and unlocking 3-03...
Page 38: Keyless Entry System
“•” position, the room lamp will illumi- If you lose one of them, contact a mirror retractor switch) MITSUBISHI MOTORS Authorized Serv- nate for approximately 15 seconds and the ice Point as soon as possible. To obtain a re- turn-signal lamps will blink twice.
Page 39 If you wish to add a key, we recommend you tor switch, the outside rear-view mirrors au- lamps are flashed by the confirmation to contact your MITSUBISHI MOTORS tomatically retract or extend when all the function can be changed. Authorized Service Point.
Page 40 Functions can be modified as stated below. open. tion is set, a chime will sound to tell you the Please consult a MITSUBISHI MOTORS 3. Press the LOCK switch (1) for 4 to 10 Authorized Service Point. condition of the door and tailgate unlock...
Page 41 NOTE + side You may purchase a replacement battery at an electric appliance store. - side A MITSUBISHI MOTORS Authorized Service Point can replace the battery for you if you prefer. Coin type battery 1. Remove the screw (A) from the key.
Page 42: Keyless Operation System
Please con- start the engine simply by carrying the key- sult a MITSUBISHI MOTORS Authorized less operation key with you. Service Point. The switches on the keyless operation key...
Page 43 Keyless operation system* NOTE NOTE NOTE • The keyless operation system is carried Because the keyless operation key continual- If the keyless operation key battery is wear- together with a communications device ly receives signals, strong radio wave recep- ing out or there are strong electromagnetic such as a cellular phone or radio set, or tion could affect battery wear.
Page 44 Keyless operation system* Operating range for starting the NOTE NOTE engine Locking and unlocking operate only when If a keyless operation key is too close to the you press a door or tailgate switch that de- door or door window, it may be possible to The operating range is the interior of the ve- tects the keyless operation key.
Page 45 Keyless operation system* A- Driver’s or front passenger’s door lock/ NOTE NOTE unlock switch Be sure to have the keyless operation key The tailgate open switch (C) can be used to with you before locking the vehicle. Even if check that the vehicle is locked properly. the keyless operation key is left in the vehi- Press the tailgate open switch within approx- cle in the glove box or other small storage...
Page 46 For further in- For further information, please contact your ly 30 seconds, relocking will automatically formation, please contact a MITSUBISHI MITSUBISHI MOTORS Authorized Serv- occur. MOTORS Authorized Service Point. ice Point. Also refer to “Locking and unlocking: Doors,...
Page 47 Keyless operation system* Warning activation In order to prevent vehicle theft or the accidental operation of the keyless operation system, the buzzer and the display on the information screen in the multi-information display are used to alert the driver. If a warning is activated, always check the vehicle and the keyless operation key. The warning is also displayed if there is a fault in the keyless operation system.
Page 48 For further information, please contact a MITSUBISHI MOTORS Authorized Service Point. Even if you have the keyless operation key within the en-...
Page 49: Doors
Doors Item Display Buzzer Note (Solution) Door ajar prevention Inner buzzer sounds When the operation mode in OFF, if you try to lock the doors system once and tailgate by pressing the driver’s or front passenger’s door Outer buzzer sounds ap- lock/unlock switch, or the tailgate LOCK switch with one of the proximately 3 seconds doors or the tailgate not completely closed, a warning is issued...
Page 50 Doors Pull the inside door handle towards you to CAUTION NOTE open the door. Be careful not to lock the doors while the When locking or unlocking with the key, on- key is inside the vehicle. ly the driver’s door will be locked or un- NOTE locked.
Page 51: Central Door Locks
To acti- and tailgate The driver’s door cannot be locked using the vate or deactivate these functions, please con- inside lock knob while the driver’s door is tact a MITSUBISHI MOTORS Authorized opened. Using the central door lock Service Point. switch...
Page 52: Dead Lock System
Dead Lock System* B- Unlock switch NOTE CAUTION On vehicles equipped with the Smartphone Do not set the Dead Lock System when Link Display Audio or the MITSUBISHI someone is inside the vehicle. With the Dead Multi-Communication System (MMCS), Lock System set, it is not possible to unlock screen operations can be used to make the the doors using the inside lock knobs.
Page 53: Child-Protection" Rear Doors
(A) on the key, the driver’s or front passeng- Dead Lock System is simultaneously set er’s door lock/unlock switch (C), or the tail- again. gate lock switch (D). For details, please con- tact a MITSUBISHI MOTORS Authorized Service Point. 1- Lock 2- Unlock Locking and unlocking...
Page 54: Tailgate
Tailgate To lock/unlock Child protection helps prevent the rear doors WARNING from being opened accidentally from the in- When opening and closing the tailgate, side. The tailgate can be locked or unlocked by us- make sure of the surrounding safety and If the lever is set to the locked position, the ing the central door lock switch (driver side).
Page 55 Tailgate To open It is designed to provide a way to open the WARNING tailgate in the case of a discharged battery. Always keep the release lever lid on the 1. Open the lid (A) inside of the tailgate. To open from outside the vehi- tailgate closed when driving so that your luggage cannot accidentally bump against the lever and open the tailgate.
Page 56: Security Alarm System
Have vehicle inspected To prevent damage or faulty operation. tled “Changing the security alarm settings” MITSUBISHI MOTORS Authorized Serv- • Do not hold the gas struts when closing ice Point. on page 3-24. the tailgate.
Page 57 Security alarm system* The security alarm has four During this time, it is possible to temporarily NOTE open a door or the tailgate without using the modes: • Leaving an unstable object such as a stuf- keyless entry system or the keyless operation fed toy or accessory in the vehicle function and without causing the alarm to •...
Page 58 Security alarm system* Changing the security alarm The turn-signal lamps blink and the horn (the siren for vehicles equipped with the interior settings alarm sensor) sounds, warning people around It is possible to set the security alarm to the the vehicle of an abnormal condition. “active”...
Page 59 MITSUBISHI MOTORS Authorized Serv- Alarm inactive the setting change mode would be can- ice Point. celled. To start over, perform the proce- Alarm active Avoid leaving valuable items inside the ve- dure again from step 3.)
Page 60 Security alarm system* By locking the vehicle using the keyless NOTE Keyless entry key Keyless operation key entry system or the keyless operation If the bonnet is open, the security indicator function, the system preparation mode is illuminates, and the system does not enter activated.
Page 61 Security alarm system* To deactivate the vehicle impact The buzzer will sound once and the function Turning the ignition switch to the “ON” will be activated. position. (except for vehicles equipped detection function and the inte- with the keyless operation system) rior intrusion detection function Putting the operation mode in ON.
Page 62 As long as they are registered, any of the tomatic locking can be adjusted. Please con- keys, other than the one used to activate the sult a MITSUBISHI MOTORS Authorized 2. The alarm will be activated for approxi- system, can be used to cancel the system.
Page 63: Electric Window Control
Electric window control Pressing the LOCK or UNLOCK switch NOTE WARNING on the key. Even if the battery is disconnected, the alarm Before operating the electric window con- (After pressing the LOCK switch, the activation memory will not be erased. trol, make sure that nothing can get trap- vehicle will lock if all the doors and the ped (head, hand, finger, etc.).
Page 64 Electric window control Driver’s switches If the switch for the driver’s window is fully The driver’s switches can be used to operate pressed down/pulled up, the door window au- all door windows. A window can be opened Type 1 tomatically opens/closes completely. or closed by operating the corresponding If you want to stop the window movement, switch.
Page 65 Electric window control Safety mechanism Press the switch down for opening the win- dow, and pull up the switch for closing it. Type 1 When the driver’s door window is automati- cally closed by pulling up the switch fully, if a hand or head is trapped in the closing win- dow, it will lower automatically.
Page 66: Power Panoramic Sunroof
Power panoramic sunroof* Nonetheless, make sure that nobody puts NOTE NOTE their head or hand out of the window when The safety mechanism can be activated if the If the following operation is performed, the closing a window. driving conditions or other circumstances safety mechanism will be cancelled and the The lowered window will become operation- cause the driver’s door window to be subjec-...
Page 67 Power panoramic sunroof* Front sunroof & front shade WARNING NOTE Never leave the vehicle without removing Depending on the model of ski carriers or The front sunroof & front shade can only be the key. roof carriers, the front sunroof may make operated with the ignition switch in the “ON”...
Page 68 Power panoramic sunroof* To stop the sunroof before it is fully open, NOTE NOTE operate the switches in any of the directions Depending on the position of the front If the front sunroof is open, it will close to- (1) to (6). shade, the front shade will open together gether with the front shade.
Page 69 After the rear shade opens, you can use the ter you perform the resetting procedure, con- switch to close it. tact a MITSUBISHI MOTORS Authorized If the safety mechanism operates five times Service Point. or more consecutively, you will not be able to close the rear shade normally.
Page 70 If the rear shade does not move correctly to the fully closed position after you perform resetting procedure, contact MITSUBISHI MOTORS Authorized Service Point. CAUTION The safety mechanism is cancelled just be- fore the rear shade is fully closed. This al- lows the rear shade to close completely.
Page 71 Seats and seat belts Seat adjustment................... 4-02 Front seat.....................4-02 Rear seats.................... 4-03 Heated seats*..................4-04 Head restraints..................4-05 Making a luggage area................ 4-07 Seat belts..................... 4-08 Pregnant women restraint..............4-14 Seat belt pretensioner system and force limiter system...... 4-14 Child restraint..................4-15 Seat belt inspection................4-25 Supplemental restraint system (SRS) - airbag........
Page 72: Seat Adjustment
Seat adjustment Seat adjustment WARNING CAUTION To minimize the risk of personal injury in When sliding or reclining the seat rearward, Adjust the driver’s seat so that you are com- the event of a collision or sudden braking, pay careful attention to the rear seat passen- fortable and that you can reach the pedals, the seatbacks should always be in the al- gers.
Page 73: Rear Seats
Rear seats Power type (driver’s side on- NOTE Rear seats ly)* To prevent the battery from running down, operate the switch with the engine running. Armrest* The lid of the floor console box can be moved forward and backward, and used as an armrest.
Page 74: Heated Seats
Heated seats* NOTE NOTE CAUTION It is possible to adjust the seatback angle and The top surface of the armrest contains a Do not place heavy objects on the seat or move the seats forward or backward inde- drink holder for rear seat occupants. stick pins, needles, or other pointed objects pendently on each side.
Page 75: Head Restraints
Head restraints For the front seats For the rear seats Head restraints Operate the switch as indicated by arrows. Each time the switch is pressed, the mode WARNING The indication lamp (A) will illuminate while changes to the next one in the following se- the heater is on.
Page 76 Head restraints To raise the head restraint, move it upward. To raise the head restraint, move it upward. WARNING To lower the restraint, move it downward To lower the restraint, move it downward When a person sits in the rear seats, pull while pressing the height adjusting knob (A) while pushing the height adjusting knob (A) up the head restraint to a height at which...
Page 77: Making A Luggage Area
Making a luggage area To install CAUTION CAUTION The shape and size of the head restraint dif- Confirm that the height adjusting knob (A) NOTE fers according to the seat. Always use the is correctly adjusted as shown in the illustra- correct head restraint provided for the seat tion, and also lift the head restraints to en- Before installing the head restraint to a rear...
Page 78: Seat Belts
Seat belts The front seat belts and/or rear outboard seat NOTE NOTE belts have a pretensioner system. These belts It is possible to folding the seat independent- If you do not move the rear seat to its most are used the same way as a conventional seat ly on each side.
Page 79 Seat belts To unfasten WARNING NOTE Hold the latch plate and push the button on No modifications or additions should be When the seat belts cannot be pulled out in a the buckle. made by the user which will either pre- locked condition, pull the belts once force- vent the seat belt adjusting devices from fully and then return them.
Page 80 Seat belts NOTE [For the front passenger] WARNING If the seat belt (A) or ring (B) becomes dirty, Do not install any accessory or sticker the belt may not retract smoothly. If the seat that makes the lamp difficult to see. Type 1 belt and ring are dirty, clean them with a mild soap or detergent solution.
Page 81 Seat belts If the ignition switch is turned to the “ON” NOTE WARNING position or the operation mode is put in ON If the seat belts are initially fastened but a When adjusting the seat belt anchor, set it while a seat belt is not fastened, the warning seat belt is unfastened while the vehicle is at a position that is sufficiently high so lamp comes on for approximately 30 seconds...
Page 82 Seat belts To fasten the latch plate (A) is turned to the front 5. Insert the latch plate (A) into the buckle side. (D). 1. Pull out the buckle (C) from the seat- back. Refer to “Rear seat belt storage” on page 4-13.
Page 83 Seat belts Rear seat belt storage 1. Hold the latch plate (A) and push the 3. Retract the seat belt and remove it from button on the buckle (D). the seat belt guide (E). When the seat belt is not in use, store it as shown in the illustration.
Page 84: Pregnant Women Restraint
(ve- floor console must be performed in line with MITSUBISHI MOTORS guidelines. It is Pregnant women restraint hicles equipped with SRS side airbags and...
Page 85: Child Restraint
Child restraint Force limiter system WARNING WARNING In the event of a collision, each force limiter When attaching a child restraint system Extreme Hazard! system will effectively absorb the load ap- to the rear seat, prevent the front seat- NEVER use a rearward facing child re- plied to the seat belt to minimize the impact backs from touching the child’s feet and straint on a seat protected by an ACTIVE...
Page 86 Child restraint Infants and small children Before purchasing a child restraint sys- WARNING tem, try installing it in the rear seat to When transporting infants and small children A REARWARD FACING CHILD RE- make sure there is a good fit. Because of in your vehicle, follow the instruction given STRAINT must NOT be used in the front the location of the seat belt buckles and...
Page 87 Child restraint NOTE Depending on the seating position in the ve- hicle and the child restraint system that you have, the child restraint can be attached us- ing one of the following two ways: Using the lower anchorage in the rear seat •...
Page 88 II & III -15 to KIDFIX XP: MZ315025 E1-04301304 36 kg : MITSUBISHI MOTORS Europe B.V. reserves the right to changes without any prior announcement. For detailed information, consult your MITSUBISHI MOTORS Authorized Service Point. 4-18 Seats and seat belts...
Page 89 Child restraint CAUTION When installing a child restraint system, remove the head restraint from the seat. When installing a child restraint system, adjust the seat slide to its most rearward position. When installing a child restraint system on the rear seat, adjust the front seat to prevent the front seatback from touching the child’s feet and child restraint system.
Page 90 36 kg MZ315025 : MITSUBISHI MOTORS Europe B.V. reserves the right to changes without any prior announcement. For detailed information, consult your MITSUBISHI MOTORS Authorized Service Point. : With front passenger’s airbag deactivated by means of front passenger’s airbag ON-OFF switch : Do not remove the head restraint when installing a booster cushion.
Page 91 Child restraint CAUTION When installing a child restraint system, remove the head restraint from the seat. However, do not remove the head restraint when installing a booster cush- ion (see page 4-24). When installing a child restraint system, adjust the seat slide to its most rearward position. When installing a child restraint system on the rear seat, adjust the front seat to prevent the front seatback from touching the child’s feet and child restraint system.
Page 92 Child restraint Tether anchorage locations Installing a child restraint sys- CAUTION tem to the lower anchorage Your vehicle has two child restraint anchor- Do not sit in the centre seating position of (ISOFIX child restraint mount- age points on the backside of the rear seats. the rear seat when installing a child restraint ings) and tether anchorage system on the left side of the rear seat.
Page 93 Child restraint To install 5. Latch the tether strap hook (C) of the child restraint system to the tether an- NOTE chorage bar (D) and tighten the top teth- er strap hook so it is securely fastened. On vehicles with the cargo area cover, install the cargo area cover in the rear position or remove it.
Page 94 Child restraint To install Installing a child restraint sys- WARNING tem to a 3-point type seat belt 1. Put a child restraint system on the seat in For some types of child restraint, the lock- (with emergency locking mech- which you wish to install it, and remove ing clip (A) should be used to help avoid anism) personal injury during a collision or sud-...
Page 95: Seat Belt Inspection
Seat belt inspection To remove Supplemental restraint WARNING system (SRS) - airbag Remove the plate from the buckle, then re- Once the pretensioner has been activated, move the seat belt from the child restraint it cannot be re-used. It must be replaced together with the re- system.
Page 96 Supplemental restraint system (SRS) - airbag How the Supplemental Re- The SRS curtain airbags (if so equipped) are 5- Front passenger’s airbag ON-OFF designed to supplement properly worn seat switch straint System works belts and provide the driver and passenger The SRS includes the following components: with protection against head injuries in cer- tain moderate-to-severe side impact colli-...
Page 97 Supplemental restraint system (SRS) - airbag The airbags deployment produces a sudden, WARNING WARNING loud noise, and releases some smoke and IT IS VERY IMPORTANT TO BE Place all infants and small children in the powder, but these conditions are not injuri- PROPERLY SEATED.
Page 98 Supplemental restraint system (SRS) - airbag Caution for installing the child Front passenger’s airbag ON- WARNING restraint on vehicle with front OFF switch Infants and small children should never passenger’s airbag be unrestrained, stand up against the in- The front passenger’s airbag ON-OFF switch strument panel or be held in your arms or can be used to disable the front passenger’s The label shown here is attached on vehicles...
Page 99 To turn an airbag off child restraint system to the front pas- senger seat. We recommend you to have the system inspected by a WARNING MITSUBISHI MOTORS Authorized Type 2 Service Point. To reduce risk of serious or fatal injury: •...
Page 100 Supplemental restraint system (SRS) - airbag Driver’s knee airbag system* 3. Turn the ignition switch to the “ON” po- The driver’s airbag and the front passenger’s sition or put the operation mode in ON. airbag are designed to inflate at the same The driver’s knee airbag is located under the The front passenger’s airbag OFF indi- time even if the passenger seat is not occu-...
Page 101 Supplemental restraint system (SRS) - airbag The front airbags and driver’s Deployment of front airbags The front airbags and driver’s knee airbag knee airbag MAY NOT DE- will deploy if the severity of impact is above and driver’s knee airbag PLOY when…...
Page 102 Supplemental restraint system (SRS) - airbag The front airbags and driver’s Because the front airbags and driver’s knee Because the front airbags and driver’s knee knee airbag MAY DEPLOY airbag do not protect the occupant in all types airbag may deploy in certain types of unex- when…...
Page 103 MITSUBISHI MOTORS cause serious injury if the airbag inflates. Authorized Service Point. Do not attach accessories to the lower por- tion of the driver’s side instrument panel.
Page 104 Supplemental restraint system (SRS) - airbag The side airbags and curtain Deployment of side airbags and On vehicles equipped with the ERA-GLO- airbags MAY NOT DEPLOY NASS, when the airbag control unit detects a curtain airbags when... rollover of the vehicle, the curtain airbags will deploy.
Page 105 Supplemental restraint system (SRS) - airbag The side airbags and curtain 3- Collision with a utility pole, tree or other 2- Rear end collisions airbags ARE NOT DESIGNED narrow object 3- Pitch end over end TO DEPLOY when... Because the side airbags and curtain airbags The side airbags and curtain airbags are not do not protect the occupant in all types of designed to deploy in conditions where they...
Page 106 We recommend work around and on the They could interfere with proper side air- side airbags and curtain airbags system to bag inflation. be done by a MITSUBISHI MOTORS Do not install seat covers on seats with Authorized Service Point. side airbags.
Page 107 SRS in- the ignition switch is turned to the “ON” po- checked by a MITSUBISHI MOTORS spected to ensure it is in proper working sition or the operation mode is put in ON.
Page 108 OGKE19E1...
Page 109 Instruments and controls Instruments..................5-02 Multi-information display..............5-02 Indication lamp, warning lamp, and information screen display list..................5-21 Indication lamps..................5-44 Warning lamps..................5-45 Information screen display..............5-47 Head Up Display (HUD)*..............5-48 Combination headlamps and dipper switch........5-53 Headlamp levelling................5-60 Turn-signal lever................. 5-62 Hazard warning flasher switch............5-62 ECO mode switch*................
Page 110: Instruments
Instruments Instruments NOTE You can adjust to 8 different levels respec- tively for when the position lamps are illu- minated and when they are not. The meter illumination switches automati- cally to the adjusted brightness, depending on the brightness outside the vehicle. The brightness level of the instruments is stored when the ignition switch is turned off or the operation mode is put in OFF.
Page 111 Multi-information display [When the ignition switch or mark display screen ® p. 5-06 2- Information screen ® p. 5-04 the operation mode is OFF] Interrupt display screen ® p. 5-06 3- Door ajar warning display screen ® p. 5-07 4- Odometer ® p. 5-08 5- “...
Page 112 Multi-information display Multi-information display Information screen (when the 9- Cruise control display screen* ® p. 6-57 switches ignition switch or the operation 10- Adaptive Cruise Control System (ACC) mode is OFF) Each time the multi-information display display screen* ® p. 6-67 switches are operated, the buzzer sounds and Press the switch to display the information...
Page 113 Multi-information display Information screen (when the Information screen (when the 3- Driving range display ® p. 5-10 ECO drive assist display* ® p. 5-12 ignition switch is turned from ignition switch or the operation 4- Average fuel consumption display the “LOCK” position to the mode is ON) ®...
Page 114 Multi-information display Redisplay of a warning display To return to the screen displayed before NOTE screen the warning display While driving, the function setting screen is Even if the cause of the warning display is When the mark is displayed, if you press not displayed even if you operate the multi- not eliminated, you can return to the screen information display switches.
Page 115 Multi-information display Fuel remaining display screen NOTE CAUTION This displays the amount of fuel remaining. Before moving your vehicle, check that the When the mark is displayed, the warning warning display is OFF. display screen can be redisplayed on the in- formation screen.
Page 116 Multi-information display Fuel remaining warning dis- Tripmeter CAUTION play The tripmeter indicates the distance travelled Do not run out of fuel, or the catalytic con- between two points. verter may be adversely affected. If the When the fuel is reduced to approximately 8 warning display appears, refuel as soon as litres, the information screen switches to the possible.
Page 117 OFF to ON, the warning To modify the display settings, have it adjus- display is displayed for a few seconds on ted at a MITSUBISHI MOTORS Authorized the information screen. Service Point. 2. Press and hold the...
Page 118 Multi-information display Driving range display 3. Press the switch while the icon is NOTE flashing to change the display from “---” This displays the approximate driving range When “---” is displayed, after a certain dis- to “CLEAR”. After this, the time until (how many more kilometres or miles you can tance and a certain period of time, the dis- the next periodic inspection will be dis-...
Page 119 Multi-information display NOTE NOTE The display setting can be changed to the The initial (default) setting is “Auto reset preferred units (km or miles). mode”. Refer to “Changing the function settings” on The average fuel consumption depends on page 5-13. the driving condition (road condition, driv- ing behavior, etc.).
Page 120 Multi-information display The “ ” mark (A) in the instant fuel gauge shows the average fuel consumption. ECO drive level When the value of instant fuel consumption surpasses the value of average fuel consump- tion, the instant fuel consumption is dis- played with a green bar graph.
Page 121 Multi-information display Changing the function settings The display shows the overall ECO score the function has counted from the time when the The “Display language”, “Temperature unit”, ignition switch is turned to “ON” to the time “Fuel consumption unit”, and “Average fuel when it is turned to “LOCK”...
Page 122 Multi-information display 3. Press the switch to switch to the top screen (A) for the menu screens. Then, press the switch or switch to switch to the menu screens (B). 4. Changing display language 10. Changing the navigation information switch ®...
Page 123 Multi-information display 2. Press the switch or switch several When the following operation is per- NOTE times to switch to the “AVERAGE formed, the mode setting is automatical- If no operations are made within approxi- FUEL CONSUMPTION RESET ly switched from manual to auto. mately 30 seconds of the menu screen being MODE”...
Page 124 Multi-information display When the engine switch or the operation 1. Switch to the function setting screen. NOTE mode is in the following conditions, the Refer to “Changing the function set- The display units for the driving range, the average fuel consumption display and tings”...
Page 125 Multi-information display Then, press the switch to switch to the 3. Press the switch or switch to select NOTE setting selection screen. the desired language, and then press the vehicles equipped with switch to confirm the setting. MITSUBISHI Multi-Communication Sys- The setting is changed to the selected tem (MMCS), the temperature value of the language.
Page 126 Multi-information display SYNC” screen. Then, press the switch 1. Switch to the function setting screen. NOTE to switch to the setting selection screen. Refer to “Changing the function set- • When “ON” (language cooperation ena- tings” on page 5-13. bled) has been selected with the language 2.
Page 127 Multi-information display 3. Press the switch or switch to select 3. Press the switch or switch to select NOTE the time, and then press the switch to the sound, and then press the switch to The operation sound setting only deactivates confirm the setting.
Page 128 Multi-information display 3. Press the switch or switch to select 3. Press the switch or switch to select 3. Press the switch or switch to select the setting, and then press the switch the setting, and then press the switch “RESET”, and then press and hold the to confirm the setting.
Page 129: Indication Lamp, Warning Lamp, And Information Screen Display List
Indication lamp, warning lamp, and information screen display list Indication lamp, warning lamp, and information screen display list Indication and warning lamp list 1- Position lamp indication lamp 7- LED headlamp warning lamp* 11- Blind Spot Warning (BSW) indication ® p. 5-45 ®...
Page 130 Abnormal voltage or a static electricity discharge is generated by the operation of installed electrical equipment (including after-market parts). If the warning display appears many times, we recommend you to consult a MITSUBISHI MOTORS Authorized Service Point. Warning display list...
Page 131 Indication lamp, warning lamp, and information screen display list Screen Cause Solution (Reference) The washer fluid is running low. Replenish the container with washer fluid. Refer to “Washer fluid” on page 10-06. Refer to “Capacity” on page 11-12. There is a fault in the LED headlamps. recommend consult MITSUBISHI...
Page 132 Indication lamp, warning lamp, and information screen display list Screen Cause Solution (Reference) Engine switch is pressed one time Although the engine switch was pressed, Touch the keyless operation key to the en- the keyless operation key could not be de- gine switch.
Page 133 Indication lamp, warning lamp, and information screen display list Screen Cause Solution (Reference) There is a fault in the EPS. Have vehicle inspected MITSUBISHI MOTORS Authorized Service Point as soon as possible. Refer to “Electric power steering system (EPS)” on page 6-54. There is a fault in the ABS.
Page 134 Put the operation mode in OFF, and then izer (Anti-theft starting system). start the engine again. If the warning is not cancelled, please contact a MITSUBISHI MOTORS Au- thorized Service Point. The driver’s door is open when the opera- Put the operation mode in OFF.
Page 135 Indication lamp, warning lamp, and information screen display list Screen Cause Solution (Reference) The engine is overheated. Stop the vehicle in a safe place and take corrective measures. Refer to “Engine overheating” on page 8-10. The automatic transmission (CVT) fluid Refer to “INVECS-III CVT with 8-step temperature is too high.
Page 136 Indication lamp, warning lamp, and information screen display list Screen Cause Solution (Reference) You are driving with the parking brake Release the parking brake. Refer to still applied. “Brake warning display” on page 5-47. The brake fluid level in the reservoir has Immediately stop the vehicle in a safe fallen to a low level.
Page 137 Indication lamp, warning lamp, and information screen display list Screen Cause Solution (Reference) The Electric parking brake has been auto- Refer to “Brake auto hold” on page 6-46. matically applied. The brake auto hold is automatically can- Refer to “Brake auto hold” on page 6-46. celled.
Page 138 Indication lamp, warning lamp, and information screen display list Screen Cause Solution (Reference) The brake auto hold system does not turn Press the brake auto hold switch after fas- on because the driver’s seat belt is not fas- tening the driver’s seat belt. tened.
Page 139 Refer to “S-AWC (Super-All Wheel Con- trol) ” on page 6-39. More than the specified limit amount of Immediately have your vehicle checked particulate matter (PM) accumulates in- by a MITSUBISHI MOTORS Authorized side the gasoline particulate filter (GPF). Service Point. Instruments and controls 5-31...
Page 140 Indication lamp, warning lamp, and information screen display list Screen Cause Solution (Reference) An excessive amount of particulate matter Refer to “Gasoline particulate filter (PM) accumulates inside the gasoline par- (GPF)*” on page 6-24 ticulate filter (GPF). The outside temperature is 3 °C(37 °F) or Be careful of ice on the road.
Page 141 Indication lamp, warning lamp, and information screen display list Screen Cause Solution (Reference) The Adaptive Cruise Control System (ACC) control is automatically cancelled and the system is placed in the standby state. Conditions for the start of control are not met, the Adaptive Cruise Control System (ACC) cannot start the control.
Page 142 Indication lamp, warning lamp, and information screen display list Screen Cause Solution (Reference) There is a fault in the Adaptive Cruise We recommend you to have it checked. Control System (ACC). Refer to “To terminate ACC control” on page 6-76. Foreign objects, such as dirt, snow or ice, Remove a foreign object on the bumper adhere to the bumper surface around the...
Page 143 Indication lamp, warning lamp, and information screen display list Screen Cause Solution (Reference) The FCM braking function of the Forward Refer to “FCM braking function” on page Collision Mitigation system (FCM) has 6-82. been activated. The Forward Collision Mitigation system Refer to “System problem warning”...
Page 144 Indication lamp, warning lamp, and information screen display list Screen Cause Solution (Reference) The Ultrasonic misacceleration Mitigation When the warning display does not disap- System (UMS) sensor is temporarily not pear after waiting for a while, contact a available for some reason such as the en- MITSUBISHI MOTORS Authorized...
Page 145 Indication lamp, warning lamp, and information screen display list Screen Cause Solution (Reference) The Ultrasonic misacceleration Mitigation Refer to “Ultrasonic misacceleration Miti- System (UMS) is activated. gation System (UMS)*” on page 6-90. The Blind Spot Warning (BSW) sensor is When the warning display does not disap- temporarily not available for some reason pear after waiting for a while, contact a such as the environmental condition or in-...
Page 146 Indication lamp, warning lamp, and information screen display list Screen Cause Solution (Reference) Foreign objects, such as dirt, snow or ice, Remove a foreign object on the bumper adhere to the bumper surface around the surface around the sensor. sensor. When the warning display does not disap- pear after having cleaned the bumper sur- face...
Page 147 Indication lamp, warning lamp, and information screen display list Screen Cause Solution (Reference) The Forward Collision Mitigation system After the temperature of the sensor has (FCM), Lane Departure Warning (LDW) been in range, the system will automati- and Automatic High-Beam (AHB) are cally return to operation.
Page 148 Indication lamp, warning lamp, and information screen display list Screen Cause Solution (Reference) Refer to “Auto Stop & Go (AS&G) sys- On vehicles with CVT, the engine was not tem” on page 6-25. automatically started by the Auto Stop & Go (AS&G) system.
Page 149 Indication lamp, warning lamp, and information screen display list NOTE NOTE The navigation information display can be Please read this section and also the separate turned on or off. owner’s manual for MITSUBISHI Multi- Refer to “Changing the navigation informa- Communication System (MMCS).
Page 150 Indication lamp, warning lamp, and information screen display list Screen System operation status Reference Refer to “S-AWC (Super-All Wheel Con- When “AUTO” mode of S-AWC is selec- trol)” on page 6-39. ted. When “SNOW” mode of S-AWC is selec- ted. When “GRAVEL”...
Page 151 Indication lamp, warning lamp, and information screen display list Screen System operation status Reference When the Forward Collision Mitigation Refer to “FCM and Ultrasonic misaccelera- system (FCM) is activated or the timing of tion Mitigation System (UMS)* ON/OFF an alarm is changed. switch”...
Page 152: Indication Lamps
Indication lamps The setting for rest interval can be changed. Screen Solution Stop the vehicle in a safe place, turn off the engine, and take a rest. Use this display as rough guide for taking rests during a long drive. The interval from the start of your trip until this message is displayed can be set.
Page 153: Warning Lamps
Warning lamps Front fog lamp indication Always make sure that the lamp goes off be- CAUTION fore driving. lamp* • The brake warning lamp remains illumi- With the ignition switch or the operation nated during driving. This lamp illuminates while mode in ON, the brake warning lamp illumi- The vehicle should be brought to a halt in the front fog lamps are on.
Page 154 Prolonged driving with this lamp on may leased. Immediately contact the nearest illuminates. cause further damage to the emission control MITSUBISHI MOTORS Authorized Serv- system. It could also affect fuel economy Normally, this lamp illumi- ice Point. When the warning lamp comes on and drivability.
Page 155: Information Screen Display
Information screen display When the ignition switch is turned to the Information screen display CAUTION “ON” position or the operation mode is put in • Should the brakes fail, use engine braking ON, if the brake fluid is low, this warning is Brake warning display to reduce your speed and observe the fol- displayed.
Page 156: Head Up Display (Hud)
Vehicle speed diately consult a MITSUBISHI MOTORS a safe place and check the engine oil level. Authorized Service Point. If the warning is displayed while the engine Navigation information* oil level is normal, have it inspected.
Page 157 MITSUBISHI MOTORS Authorized Serv- movement. If the display does not open or ing or obstruct the opening operation, result- ice Point.
Page 158 Head Up Display (HUD)* Adjusting the angle of the dis- 2. The setting top screen will be displayed NOTE if the vehicle is stopped, push the play If the HUD was open when the ignition switch again. switch was turned to the “LOCK” position When the display is open, push the side or or the operation mode was put in OFF, the...
Page 159 Head Up Display (HUD)* Adjusting the brightness of the 1. To change the display setting, push the 3. The display setting screen will be dis- switch when the display is open. played. display When the display is open, push the side or Navigation information: ON side of the...
Page 160 Head Up Display (HUD)* 5. Push the side or side of the 6. Push the side of the switch to select switch to select “OFF” or “ON”, and “RETURN”. Push the switch to con- then push the switch. firm the setting. Navigation information: ON Navigation information: ON Navigation information: OFF...
Page 161: Combination Headlamps And Dipper Switch
Combination headlamps and dipper switch 7. Push again the switch while “RE- Rotate the switch to turn on the lamps. CAUTION TURN” is selected in the setting screen, Do not use cleaners or protectants that con- and the navigation system display will tain silicone or wax.
Page 162 For further information, we recommend you cally when the driver’s door is opened. the headlamps are subsequently turned back to consult a MITSUBISHI MOTORS Au- [Except for vehicles equipped with key- on by the automatic on/off control, the front thorized Service Point.
Page 163 Have the vehicle If the lamp switch is in the “ ” or “ ” checked at a MITSUBISHI MOTORS Au- position, or if the tail lamps are on when the thorized Service Point. Headlamp flasher lamp switch is in the “AUTO”...
Page 164 Combination headlamps and dipper switch If the AHB switch is pressed again, the NOTE WARNING AHB will be deactivated and AHB indi- If you turn the lamps off with the headlamps The headlamp beams (high/low) may not cator will go off. set to high-beam, the headlamps are auto- be switched automatically under certain matically returned to their low beam setting.
Page 165 Combination headlamps and dipper switch NOTE NOTE Manual switching The headlamps may not be switched from The AHB recognises environmental condi- Switching to low beam high-beam to low beam under the following tions by sensing a light source ahead of your 1.
Page 166 ON, please contact a into the other lamps. sensor, the following warning display will MITSUBISHI MOTORS Authorized Service • The rear end of a vehicle in front (such as appear.
Page 167 Contact a the low beam setting. • The welcome light function can be deacti- MITSUBISHI MOTORS Authorized Service vated. Point for inspection of the sensor. For further information, please contact your MITSUBISHI MOTORS Authorized Serv- ice Point.
Page 168: Headlamp Levelling
“0” The coming home light function can be • deactivated. For further information, please contact your MITSUBISHI MOTORS Authorized Serv- “2” ice Point. On vehicles equipped with the Smartphone Link Display Audio or the MITSUBISHI Multi-Communication System...
Page 169 Headlamp levelling Switch position 5 passengers (including Vehicle condition Switch position [Vehicles with 2WD] driver) + Full luggage “2” loading/Driver + Full lug- Switch position Driver only/Driver + 1 gage loading front passenger Switch position Driver + Full luggage Switch position 5 passengers (including loading “3”...
Page 170: Turn-Signal Lever
When making a normal turn, use posi- For further information, we recommend This mechanism automatically adjusts the di- tion (1). The lever will return automati- you to consult a MITSUBISHI MOTORS rection of the headlamps (beam position) de- cally when cornering is completed. Authorized Service Point.
Page 171: Eco Mode Switch
Push the switch to turn on the hazard warning air conditioning system to improve fuel effi- For further information, we recommend you flashers, all turn-signal lamps flash continu- to consult a MITSUBISHI MOTORS Au- ciency. ously. To turn them off, push the switch thorized Service Point.
Page 172: Fog Lamp Switch
Fog lamp switch Turn the knob once in the “ON” direction to Fog lamp switch NOTE turn on the front fog lamps. Turn the knob Do not use fog lamps except in conditions of once more in the “ON” direction to turn on Front fog lamp switch* fog, otherwise excessive lamp glare may the rear fog lamp.
Page 173: Wiper And Washer Switch
Wiper and washer switch If the blades are frozen to the windscreen or If the lever is put in the “AUTO” position, NOTE rear window, do not operate the wipers until the rain sensor (A) will detect the extent of To turn the rear fog lamp on again, turn the the ice has melted and the blades are freed, rain (or snow, other moisture, dust, etc.) and...
Page 174 For further information, we recommend To protect the rubber parts of the wipers, this ized Service Point when replacing the wind- you to consult a MITSUBISHI MOTORS operation of the wipers does not take place screen or reinforcing the glass around the Authorized Service Point.
Page 175 Wiper and washer switch The wipers will operate once if the lever is The wipers will operate once if the lever is On vehicles equipped with a headlamp wash- raised to the “MIST” position and released moved to the “AUTO” position and the knob er, while the headlamps are on, the headlamp when the ignition switch or the operation (C) is turned in the “+”...
Page 176 6 position. seconds. For further information, we recommend you For further information, we recommend you to consult a MITSUBISHI MOTORS Au- INT- The wiper operates continuously to consult a MITSUBISHI MOTORS Au- thorized Service Point.
Page 177: Rear Window Demister Switch
For further information, we recommend you the headlamp washer operates together with Otherwise, the motor may burn out. to consult a MITSUBISHI MOTORS Au- the windscreen washer the first time the Periodically check the level of washer thorized Service Point.
Page 178: Heated Windscreen Switch
5 to 10 minutes depending on cally at the same time. For further information, we recommend you the outside temperature. To turn off the heat- to consult a MITSUBISHI MOTORS Au- ed windscreen while it is operating, push the thorized Service Point. switch again.
Page 179: Heated Steering Wheel Switch
Heated steering wheel switch* CAUTION CAUTION Heating range While heated windscreen is operating, the • People with sensitive skin The heated steering wheel can be operated outer surface of the windscreen will be hot. If water or any other liquid is spilled on the when the ignition switch or operation mode is Do not touch the windscreen to prevent steering wheel, allow it to dry thoroughly...
Page 180 OGKE19E1...
Page 181 Starting and driving Economical driving................6-02 Electric power steering system (EPS)..........6-54 Driving, alcohol and drugs..............6-02 Active stability control (ASC)............6-55 Safe driving techniques...............6-03 Cruise control*..................6-57 Running-in recommendations............. 6-03 Speed Limiter*..................6-62 Parking brake..................6-04 Adaptive Cruise Control System (ACC)*...........6-67 Parking....................6-08 Forward Collision Mitigation system (FCM)*........
Page 182: Economical Driving
Economical driving Cargo loads The drive mode-selector should be set to Economical driving “AUTO” (Electronically controlled 4WD) when driving 4WD vehicles to obtain best Do not drive with unnecessary articles in the For economical driving, there are some tech- possible fuel economy. luggage compartment.
Page 183: Safe Driving Techniques
Safe driving techniques Floor mats Your driving ability can be seriously im- Make sure that infants and small chil- paired even with blood alcohol levels far be- dren are properly restrained in accord- low the legal minimum. If you have been ance with the laws and regulations, and WARNING drinking, don’t drive.
Page 184: Parking Brake
Parking brake Lever type parking brake* Keep to the running-in speed limit Shift point Speed limit shown below. position 100 km/h (62 mph) Please note that the legal speed limits To apply displayed must be adhered to. position 110 km/h (68 mph) Do not exceed loading limits.
Page 185 Parking brake Electric parking brake* NOTE CAUTION The Electric parking brake is the system that Apply sufficient force to the parking brake Before driving, be sure that the parking applies the parking brake by the electric mo- lever to hold the vehicle stationary after the brake is fully released and brake warning foot brake is released.
Page 186 “LOCK” position or the operation mode contact a MITSUBISHI MOTORS Author- Refer to “Brake auto hold” on page 6-46. is put in OFF. ized Service Point.
Page 187 The selector lever is in the “D” (Drive) the brake system may be malfunctioning. or the “R” (Reverse) position. Contact the nearest MITSUBISHI MOTORS The driver’s seat belt is fastened. Authorized Service Point. Starting and driving...
Page 188: Parking
Immediately contact the wheel gently touches the kerb. Warning lamp (yellow) nearest MITSUBISHI MOTORS Authorized On vehicles equipped with M/T, apply the Service Point. For details, refer to “Electric parking brake and place the gearshift lever parking brake warning light (yellow)”...
Page 189: Steering Wheel Height And Reach Adjustment
Steering wheel height and reach adjustment Steering wheel height and On vehicles equipped with M/T, apply the WARNING parking brake and place the gearshift lever reach adjustment Leaving the engine running risks injury into the 1 position. or death from accidentally moving the On vehicles equipped with CVT, apply the gearshift lever (with M/T), the selector 1.
Page 190: Inside Rear-View Mirror
Inside rear-view mirror It is possible to move the mirror up and down The lever (A) at the bottom of the mirror can Inside rear-view mirror to adjust its position. be used to adjust the mirror to reduce the glare from the headlamps of vehicles behind Adjust the rear-view mirror only after making you during night driving.
Page 191: Outside Rear-View Mirrors
Outside rear-view mirrors When the headlamps of the vehicles behind Outside rear-view mirrors Type 1 you are very bright, the reflection factor of the rear-view mirror is automatically changed To adjust the mirror position to reduce the glare. The outside rear-view mirrors can be operat- ed when the ignition switch is in the “ON”...
Page 192 Outside rear-view mirrors Retracting and extending the CAUTION On vehicles equipped with the mirror re- outside mirrors tractor switch It is possible to retract and extend the mir- rors by hand. After retracting a mirror using The outside mirror can be retracted in to- Retracting and extending the the mirror retractor switch, however, you wards the side window to prevent damage...
Page 193 The indication lamp (A) will illuminate while For further information, we recommend you NOTE to consult a MITSUBISHI MOTORS Au- the demister is on. thorized Service Point. Functions can be modified as stated below. On vehicles equipped with the Smartphone...
Page 194: Ignition Switch
The ACC power auto-cutout function can matically return to the “ON” position. be deactivated. For details, we recommend you to consult NOTE a MITSUBISHI MOTORS Authorized Service Point. Your vehicle is equipped with an electronic On vehicles equipped with the Smart- immobilizer.
Page 195: Engine Switch
Do not turn the key to the “START” position flashing orange. Immediately contact a while the engine is running. Doing so could MITSUBISHI MOTORS Authorized Serv- damage the starter motor. ice Point. If the engine switch operation is not smooth...
Page 196 Engine switch* Changing the operation mode NOTE Electrical devices such as the audio and ac- If you press the engine switch without de- When the battery in the keyless operation cessory socket can be operated. pressing the brake pedal (CVT) or the clutch key has worn out, or the keyless operation The indication lamp on the engine switch il- key is out of the vehicle, a warning display...
Page 197 For details, we recommend you to consult keyless entry system, keyless opera- is selected automatically. Before disconnect- a MITSUBISHI MOTORS Authorized tion function and steering lock will ing the battery for repair or replacement, Service Point.
Page 198: Steering Wheel Lock
Steering wheel lock To unlock Operation mode ON reminder NOTE system Turn the key to the “ACC” position while When the following operation is performed moving the steering wheel slightly right and with the operation mode in OFF and the se- lector lever in the “P”...
Page 199: Starting And Stopping The Engine
If your vehicle needs to be towed, unlock the again, have your vehicle checked at a steering wheel. less operation system MITSUBISHI MOTORS Authorized Serv- Refer to “Emergency towing” on page Do not operate the starter motor continu- ice Point.
Page 200 Starting and stopping the engine On vehicles equipped with CVT, make CAUTION CAUTION sure the selector lever is in the “P” Release the ignition key as soon as the en- Never attempt to start the engine by pushing (PARK) position. gine starts to avoid damaging the starter mo- or pulling the vehicle.
Page 201 Starting and stopping the engine 3. If the engine still will not start, the en- NOTE NOTE gine could be flooded with too much Minor noises may be heard on engine start- After the engine has not started for a while, petrol.
Page 202 Starting and stopping the engine On vehicles equipped with CVT, make 3. If the engine still will not start, the en- NOTE sure the selector lever is in the “P” gine could be flooded with too much When starting the engine, the selector lever (PARK) position.
Page 203 Starting and stopping the engine 1. Bring the vehicle to a complete stop. 1. Depress the brake pedal firmly with your NOTE 2. Firmly apply the parking brake while de- right foot (CVT) or the clutch pedal If you have to bring the engine to an emer- pressing the brake pedal.
Page 204: Gasoline Particulate Filter (Gpf)
Gasoline particulate filter (GPF)* GPF warning display NOTE WARNING If metal objects or other keys are near the The GPF reaches very high temperatures. keyless operation key, the keyless operation Do not park your vehicle in areas where key may not be recognized. combustible materials such as dry grass Instead of depressing the brake pedal, the or leaves can come in contact with a hot...
Page 205: Turbocharger Operation
If an abnormal condition occurs in the GPF matically stops and restarts the engine with- contact your MITSUBISHI MOTORS Au- system, the GPF warning display appears and out operating the ignition switch or engine thorized Service Point.
Page 206: Auto Stop & Go (As&G) System
Auto Stop & Go (AS&G) system* Automatically stopping the en- 3. Release the clutch pedal. The engine will gine (on vehicles equipped with stop automatically. When the Adaptive Cruise Control M/T) System (ACC) is turned on (on vehicles equipped with the ACC) 1.
Page 207 Auto Stop & Go (AS&G) system* CAUTION NOTE NOTE Observe the following precautions when the • After the engine is started, approximately In the following cases, the engine will not engine is stopped automatically. Otherwise, 30 seconds or more have not elapsed stop automatically even if the indica- an unexpected accident might occur when...
Page 208 Auto Stop & Go (AS&G) system* When the vehicle in front starts moving or NOTE NOTE when you depress the accelerator pedal, the If the air conditioning is operating, set the If the engine does not restart automatically, engine restarts automatically. temperature control higher to lengthen the the warning display will appear in the infor- time that the engine is stopped automatical-...
Page 209 Auto Stop & Go (AS&G) system* NOTE CAUTION CAUTION [On vehicles equipped with CVT] wise an unexpected accident might occur • Move the selector lever from the “N” The engine will not restart even if release the when the engine restarts. (NEUTRAL) to “D”...
Page 210: Manual Transmission
AS&G system is malfunctioning and will pressing the brake pedal. (on vehicles equip- not operate. ped with the keyless operation system) recommend consult MITSUBISHI MOTORS Authorized Service To deactivate AS&G OFF indicator display Point. The AS&G system is automatically activated Manual transmission* when the ignition switch is turned to the “ON”...
Page 211: Invecs-Iii Cvt With 8-Step Sports Mode
INVECS-III CVT with 8-step Sports Mode* Moving the gearshift lever to CAUTION CAUTION the “R” (Reverse) position Do not put the gearshift lever into the re- If the pull-ring will not return from the verse position while the vehicle is moving pulled-up position, we recommend you to Pull up the pull-ring (A), then move the gear- forward.
Page 212 INVECS-III CVT with 8-step Sports Mode* Also you can manually shift up and shift In the main gate, the selector lever has four WARNING down the transmission. Refer to “Sports positions, and is equipped with a lock button If the lock button is always pushed to op- mode”...
Page 213 “ON” position or the operation mode in ON, the battery may be flat or the shift-lock mechanism may be malfunctioning. Immedi- ately have your vehicle checked by a MITSUBISHI MOTORS Authorized Service Point. If you need to move the vehicle, shift the se- lector lever as follows.
Page 214 INVECS-III CVT with 8-step Sports Mode* Selector lever position display If the ambient temperature is low, the selector NOTE lever position display on the multi-informa- When the ignition switch is turned to the While the selector lever position display is tion display may blink when the selector lev- “ON”...
Page 215 INVECS-III CVT with 8-step Sports Mode* “N” NEUTRAL CAUTION NOTE At this position, the transmission is disengag- To prevent transmission damage, never shift • Pull the + (SHIFT UP) side shift paddle ed. It is the same as the neutral position on a into the “D”...
Page 216 INVECS-III CVT with 8-step Sports Mode* Shift paddles position display CAUTION NOTE The currently selected position is displayed In sports mode, the driver must execute up- The upward shift may be made automatical- on the multi information display. ward shifts in accordance with prevailing ly in sports mode when the engine revolu- road conditions, taking care to keep the en- tions rise and approach the tachometer’s red...
Page 217 If the warning display remains, Operating the accelerator pedal while the problem with the CVT position switch. It is contact a MITSUBISHI MOTORS Author- other foot is resting on the brake pedal will not seen during normal driving. ized Service Point immediately.
Page 218 INVECS-III CVT with 8-step Sports Mode* DRIVING DOWNHILL If you are going to leave the vehicle unatten- CAUTION ded, always switch off the engine and carry According to the conditions, the transmission Do not race the engine with brake pedal the key.
Page 219: S-Awc (Super All Wheel Control)
S-AWC (Super All Wheel Control)* S-AWC (Super All Wheel NOTE S-AWC drive Function mode Control)* On vehicles equipped with the lever type parking brake, if the parking brake lever is This mode is chiefly suit- pulled up while the vehicle is moving, the able for the snow road.
Page 220 S-AWC (Super All Wheel Control)* S-AWC drive mode-selector The drive mode display will appear on the in- NOTE formation screen for a few seconds, and then The drive mode can be switched by press the Even if an S-AWC drive mode other than the original screen will return.
Page 221: 4-Wheel Drive Operation
Have your vehicle inspected immediately by cations. a MITSUBISHI MOTORS Authorized Serv- Yaw control function display Not only does this ensure better handling on ice Point.
Page 222 (tyre chains) is recommended. sures. Maintain a safe distance between vehicles, MITSUBISHI MOTORS is not responsible avoid sudden braking, and use engine brak- to the operator for any damage or injury ing (downshifting). caused or liability incurred by improper and negligent operation of a vehicle.
Page 223: Inspection And Maintenance Following Rough Road Operation
Inspection and maintenance following rough road operation Driving on sandy or muddy Check the depth of the water and the terrain NOTE before attempting to drive through it. Drive roads Avoid sudden braking, sudden acceleration slowly to avoid creating excessive water and sharp turning;...
Page 224: Cautions On Handling Of 4-Wheel Drive Vehicles
Cautions on handling of 4-wheel drive vehicles* Towing Carefully wash the vehicle with water. Install only the specified tyres on all Drive the vehicle slowly while lightly wheels. Refer to “Tyres and wheels” on depressing the brake pedal in order to page 11-10.
Page 225: Braking
Braking Jacking up a 4-wheel drive ve- Brake system When brakes are wet hicle The service brake is divided into two brake Check the brake system while driving at a circuits. And your vehicle is equipped with low speed immediately after starting, espe- WARNING power brakes.
Page 226: Brake Auto Hold
Brake auto hold* Brake pad The driver’s door is closed. WARNING Never leave the vehicle while it is being Avoid hard braking situations. stopped by the brake auto hold system. New brakes need to be broken-in by When leaving the vehicle, apply the park- moderate use for the first 200 km.
Page 227 Brake auto hold* The brake auto hold indication lamp in the NOTE NOTE instrument cluster will come on while the • If this warning appears, fasten the driver’s If you keep pressing the brake auto hold system activates. seat belt. switch after setting the brake auto hold to ON (Stand by), the brake auto hold will re- turn to OFF as a protection function is oper-...
Page 228 Brake auto hold* NOTE NOTE NOTE press the accelerator pedal and the vehicle • When the system detects the vehicle slid- If the ignition switch is turned to the starts moving again. ing down a slope. “LOCK” position or the operation mode is If the following operation is performed, the put in OFF with the selector lever in any po- brake auto hold will be deactivated and the...
Page 229: Hill Start Assist
Hill start assist If you want to turn off the system while the CAUTION NOTE brake auto hold indication lamp is illumina- Do not overly rely on the hill start assist to When reversing on an uphill slope, place the ted, press the switch while depressing the prevent backwards movement of the vehicle.
Page 230: Brake Assist System
When the brake assist system is in use, you inspected by a MITSUBISHI MOTORS Au- may feel as if the depressed brake pedal is thorized Service Point as soon as possible. Warning lamp/display...
Page 231: Active Yaw Control (Ayc)
Active Yaw Control (AYC) NOTE CAUTION Vehicles with 2WD The AYC operation status is displayed. You may hear an operation noise when the Control of the braking force does not en- brake pedal is depressed suddenly while sta- hance the stopping performance of the vehi- tionary.
Page 232: Emergency Stop Signal System
Emergency stop signal system Emergency stop signal • Driving on gravel or snow-covered NOTE roads. system • The brake pedal has been depressed, and • Driving with snow traction device the system judges that it was sudden brak- (tyre chains) installed. ing from the vehicle deceleration and the This is a device that reduces the possibility of •...
Page 233 Anti-lock brake system (ABS) • When the vehicle is driven for a while If there is a malfunction in the system, the Stop the vehicle in a safe place. after the engine is turned on. ABS warning lamp will come on and the Restart the engine and check to see whether The ABS can be used after the vehicle warning display will appear on the informa-...
Page 234: Electric Power Steering System (Eps)
If this happens, have your ve- sors (A) and the cables located at each wheel. hicle inspected at a MITSUBISHI MOTORS Authorized Service Point. Front Rear...
Page 235: Active Stability Control (Asc)
The headlamps will return MITSUBISHI MOTORS Authorized Serv- This system, like any other system, has lim- to their original brightness after a short ice Point as soon as possible.
Page 236 Active stability control (ASC) NOTE NOTE CAUTION When the ASC is activated, you may feel a The stability control function operates at For safety reasons, the ASC OFF switch vibration in the vehicle body or hear a whin- speeds of approximately 15 km/h (9 mph) or should be operated when your vehicle is ing sound from the engine compartment.
Page 237: Cruise Control
Cruise control* ASC warning lamp/display CAUTION CAUTION If an abnormal condition occurs in the sys- If the 2WD vehicle is towed with the igni- When indicator blinks, ASC is operating, tem, the following warning lamp/display will tion switch in the “ON” position or the oper- which means that the road is slippery or that turn on.
Page 238 Cruise control* Cruise control switches To activate CAUTION 1. With the ignition switch in the “ON” po- When you do not wish to drive at a set sition or the operation mode in ON, speed, turn off the cruise control for safety. Do not use cruise control when driving con- press the CRUISE CONTROL ON/OFF ditions will not allow you to stay at the same...
Page 239 Cruise control* Accelerator pedal To increase the set speed 2. Accelerate or decelerate to your desired speed, then push down and release the There are two ways to increase the set speed. While driving at the set speed, use the accel- “SET -”...
Page 240 Cruise control* Brake pedal To temporarily increase or de- When you reach your desired speed, release the switch. Your new cruising speed is now crease the speed While driving at the set speed, use the brake set. pedal, which disengages the cruise control, To temporarily increase the then push down the “SET -”...
Page 241 Cruise control* Refer to “To resume the set speed” on page The set speed driving is deactivated automat- CAUTION 6-61. ically in any of the following ways. When the set speed driving is deactivated When you depress the clutch pedal (on automatically in any situation other than vehicles equipped with M/T).
Page 242: Speed Limiter
Speed Limiter* NOTE NOTE If the clutch pedal (M/T) is depressed, the However, this gives priority to audio and Speed Limiter does not activate. visual signal of safety reasons or driver’s de- mand. Under either of the following conditions, If the set speed is too lower based on current however, using the switch does not allow you If the vehicle speed exceeds the set speed shift position, the Speed Limiter may not...
Page 243 Speed Limiter* To activate D- “CANCEL” switch A- Control state To cancel the Speed Limiter. There are three control states as below. Accelerate or decelerate to your desired LIMIT OFF speed, and push down the “SET -” switch When the Speed Limiter is in STAND- NOTE (B).
Page 244 Speed Limiter* To increase the set speed By using the CANCEL switch, Accelerate to driver’s desired vehicle speed and push down SET - switch (B) and release. the accelerator pedal and the By using the RES + switch SET - switch Push up the “RES +”...
Page 245 Speed Limiter* If the set speed reaches to your desired speed, By using the CANCEL switch, Decelerate to driver’s desired speed and push release the “SET -” switch (B). down SET - switch (B) and release. the service brake and the SET - switch Press the “CANCEL”...
Page 246 Stop using the Speed Limiter and turn off sages appear in the combination meter. the Speed Limiter. Have your vehicle in- spected by a MITSUBISHI MOTORS Serv- ice Point. 6-66 Starting and driving...
Page 247: Adaptive Cruise Control System (Acc)
Adaptive Cruise Control System (ACC)* If you desire, a cruise control without inter- CAUTION WARNING vention of the following distance control is There is a possibility to occur jerk, depend- This system may not correctly detect the also selectable. ing on a running resistance. Be careful. actual situation depending on the type of vehicle in front and its conditions, the weather conditions, and the road condi-...
Page 248 The cover in front of the sensor and the please do not use the ACC and contact a could lead to an accident. sensor should be kept clean. MITSUBISHI MOTORS Authorized Serv- • On roads with heavy traffic or roads in- ice Point.
Page 249 Adaptive Cruise Control System (ACC)* When ACC detects no vehicle If the vehicle in front stops, the ACC reacts NOTE to it by stopping your vehicle. in front within the set distance When the ACC system is in the stationary When the ACC system enters the stationary vehicle hold state, the stop lamps will illumi- Your vehicle runs at a speed to which you set.
Page 250 Adaptive Cruise Control System (ACC)* Proximity alarm WARNING CAUTION While the ACC is active, if your vehicle ap- Your vehicle may accelerate up to the set • When there is an abnormality in the sys- proaches too closely to a vehicle in front be- speed in the following situations.
Page 251 Indicates that the ACC is ON. tem. 4- “CANCEL” switch 2- Control state indicator: Please contact a MITSUBISHI MOTORS Used to cancel the control function of Indicates that the ACC is active. Authorized Service Point. ACC or the cruise control.
Page 252 Adaptive Cruise Control System (ACC)* 4- Vehicles in front symbol: The display on the information screen of the State Comes on when the ACC detects a vehi- multi-information display will switch to show Stand by Active cle ahead. Two types of indication: information on the ACC.
Page 253 Adaptive Cruise Control System (ACC)* When your desired speed is reached, release When the ACC is initialized, the “SET” indi- NOTE the “SET -” switch; then this speed is set and cator lights up on the screen. At the same •...
Page 254 Adaptive Cruise Control System (ACC)* CAUTION NOTE By using the “RES +” switch: The set speed increases by 1 km/h (1 mph) The setting speed should be set up the suita- The set speed indication on the display turns every time you push up the “RES +” switch ble speed according to a situation.
Page 255 Adaptive Cruise Control System (ACC)* To temporarily accelerate the CAUTION By using the “SET -” switch: vehicle The set speed decreases by 1 km/h (1 mph) The setting speed should be set up the suita- Simply depress the accelerator pedal to tem- every time you push down the “SET -”...
Page 256 Adaptive Cruise Control System (ACC)* Depress the brake pedal (except for the NOTE stationary vehicle hold state). In certain conditions, the braking control and alarming functions of the ACC may not work for a short while after releasing the ac- The ACC control is automatically cancelled celerator pedal.
Page 257 ACC has a mal- can temporarily not operate, the ACC system sliding down a slope while the vehicle is function. Contact a MITSUBISHI MOTORS operation will be cancelled automatically, and in the stationary vehicle hold state.
Page 258 Adaptive Cruise Control System (ACC)* To turn off ACC To resume the control NOTE After cancelling the ACC control (i.e. placing Press the ACC ON/OFF switch when the The conditions to be met before the ACC the system in the standby state) by pressing ACC is in the ON state to turn off the ACC.
Page 259: Forward Collision Mitigation System (Fcm)
Forward Collision Mitigation system (FCM)* To activate cruise control (au- Forward Collision NOTE tomatic speed control) Mitigation system (FCM)* The following distance varies as a function of the speed; the faster the set speed, the lon- If you hold the ACC ON/OFF switch pressed ger the following distance.
Page 260 Forward Collision Mitigation system (FCM)* If you turn the FCM ON/OFF, the Ultrasonic WARNING Type 2 misacceleration Mitigation System (UMS) al- A driver is responsible for driving safely. so turns ON/OFF at the same time. (Vehicles The FCM is the system to mitigate colli- equipped with the UMS) sion-caused damages or to avoid collisions as much as possible.
Page 261 Forward Collision Mitigation system (FCM)* Forward collision warning FCM brake assist function CAUTION function If the system judges that there is a risk of Under certain conditions, the audible alarm your vehicle colliding with a vehicle or a pe- may not work at all or may be scarcely audi- If the system judges that there is a risk of ble.
Page 262 Forward Collision Mitigation system (FCM)* Type 2 FCM braking function CAUTION If the system judges that there is a high risk Against a vehicle: Approximately 5 to • When the FCM has detected a problem in of your vehicle colliding with a vehicle or a 180 km/h (3 to 110 mph).
Page 263 Forward Collision Mitigation system (FCM)* CAUTION CAUTION CAUTION • When a vehicle in front does not have re- • windscreen wipers • When a pedestrian’s clothing appears to flectors (lamp reflector) or the position of MITSUBISHI MOTORS GENUINE be nearly the same colour or brightness as the reflector is low.
Page 264 Forward Collision Mitigation system (FCM)* CAUTION CAUTION CAUTION • When there is a structure (B) beside the • When passing close to a vehicle, pedes- • When passing through a plastic curtain entrance of a curve and intersection. trian or object. etc.
Page 265 Forward Collision Mitigation system (FCM)* NOTE NOTE A sound will be heard during the activation When the FCM and Ultrasonic misaccelera- of automatic braking, this is a function of the tion Mitigation System (UMS)* ON/OFF brake control and is not abnormal. switch is held pressed to change the ON/OFF state of the FCM, the ON/OFF state of the UMS is also changed at the same...
Page 266 Forward Collision Mitigation system (FCM)* When the camera and radar Distance mode: FAR cannot detect accurately (Type 2 only) When the FCM system determines that it cannot detect objects properly, the FCM will become inoperative. This can occur when: When the sensor performance returns, the In adverse weather conditions, such as FCM functions will resume operation.
Page 267 If the display keeps showing the message, there is a possibility that the FCM has a mal- there is a possibility that the FCM has a mal- function. Contact a MITSUBISHI MOTORS function. Authorized Service Point for inspection of Contact a MITSUBISHI MOTORS Author- the system.
Page 268 If the inside of the windscreen where the tion. sensor is installed becomes dirty or fog- Refer to “Wiper blades” on page 9-05. ged, contact a MITSUBISHI MOTORS When replacing the wiper blades, use on- Authorized Service Point. ly MITSUBISHI MOTORS GENUINE •...
Page 269 Forward Collision Mitigation system (FCM)* For Israel CAUTION Laser warning label The sensor emits infrared rays when the ig- nition switch is turned to the “ON” position and the operation mode is put in ON. Do not look into the sensor by using optical goods such as a magnifying glass.
Page 270: Ultrasonic Misacceleration Mitigation System (Ums)
Ultrasonic misacceleration Mitigation System (UMS)* Ultrasonic misacceleration Mitigation System (UMS)* The Ultrasonic misacceleration Mitigation System (UMS) operates to prevent sudden starts and mitigate collision-caused damages by suppress- ing the engine output for up to approximately 5 seconds when the system judges that the system is detected the vehicle or obstacles within ap- proximately 4 m in front and behind your vehicle and judges that accelerator pedal was depressed promptly and too strongly such as misopera- tion of it.
Page 271 Ultrasonic misacceleration Mitigation System (UMS)* Situation Operation display Buzzer When an obstacle is detected behind your vehicle with the se- Intermittent lector lever in the “R” (Reverse) position, if the accelerator beeping sound pedal is depressed promptly and too strongly, the engine out- put is suppressed for up to approximately 5 seconds.
Page 272 Ultrasonic misacceleration Mitigation System (UMS)* CAUTION The UMS does not operate in the following conditions: • The ignition switch or the operation mode is other than ON. • The UMS is set to OFF by operating the FCM and Ultrasonic misacceleration Mitigation System (UMS)* ON/OFF switch. •...
Page 273 Ultrasonic misacceleration Mitigation System (UMS)* CAUTION The UMS may be triggered in the following situations. • When water, snow or sand on the road are extorted by the vehicle in front or an oncoming vehicle. • When there are objects, steps or projections on the road surface. •...
Page 274 Do not modify the suspension of your vehicle. If the bumper has been exposed to an impact, the sensors may fail and prevent the system from functioning properly. Have the vehicle inspected a MITSUBISHI MOTORS Authorized Service Point. Obstacle detection areas...
Page 275: Blind Spot Warning (Bsw) (With Lane Change Assist)
Blind Spot Warning lamp in the contact a MITSUBISHI MOTORS Author- If the height of an object is lower than the corresponding outside rear-view mirror will ized Service Point.
Page 276 Blind Spot Warning (BSW) (with Lane Change Assist)* Detection areas Depending on the relative speed between your vehicle and a vehicle in the next lane, The BSW uses two sensors (A) located inside the BSW will detect up to approximately 70 the rear bumper.
Page 277 Blind Spot Warning (BSW) (with Lane Change Assist)* To operate WARNING WARNING When the ignition switch is turned to the • When a vehicle is travelling alongside • When the bumper surface around the “ON” position or the operation mode is put in of your vehicle at nearly the same speed sensor is covered with dirt, snow and for prolonged periods of time.
Page 278 Blind Spot Warning (BSW) (with Lane Change Assist)* NOTE NOTE • The speed of your vehicle is approximate- The Blind Spot Warning lamp in the outside ly 10 km/h (6 mph) or higher. rear-view mirror may come on or blink in the following conditions.
Page 279: Rear Cross Traffic Alert (Rcta)
Have the vehicle tion screen of the multi-information display. inspected at a MITSUBISHI MOTORS Au- thorized Service Point as soon as possible. NOTE When the warning display appears, the sensor...
Page 280 Rear Cross Traffic Alert (RCTA)* Detection areas WARNING Never rely solely on the RCTA when The detection area is shown as illustrated. backing up. The RCTA is an aid system. It is not a substitute for your safe and careful driving. Always check visually be- hind and all around your vehicle for other vehicles, persons, animals or obstructions.
Page 281: Lane Departure Warning (Ldw)
Lane Departure Warning (LDW)* Refer to “Blind Spot Warning (BSW): Sys- CAUTION CAUTION tem problem warning” on page 6-98. • When the reversing speed of your vehicle If the bumper has experienced an impact, the is approximately 18 km/h (11 mph) or sensor may have been damaged and the Lane Departure Warning higher.
Page 282 Lane Departure Warning (LDW)* The system automatically shifts from the “ON” state to the standby state if all of the following conditions are simultaneously met. indicator on the information screen in the multi-information display will be changed from white to green. The vehicle speed is approximately 65 km/h (40 mph) or higher.
Page 283 “LANE DEPARTURE” appears on warning specific to the type of the problem is Contact a MITSUBISHI MOTORS Author- the information screen of the multi-informa- given together with an audible alarm. ized Service Point for inspection of the sen-...
Page 284 • When running on a road portion with in- or outlet of a tunnel. MITSUBISHI MOTORS Authorized Serv- completely removed old lane markings, • When turning steep curves. ice Point.
Page 285: Tyre Pressure Monitoring System (Tpms)
• When the vehicle is equipped with non- erly. See an MITSUBISHI MOTORS Au- The system only indicates when a tyre is sig- standard tyres (including excessively thorized Service Point as soon as possible nificantly under-inflated.
Page 286 ON, it means that the TPMS is not work- Refer to “If the warning lamp/display illumi- ing properly. Have the system inspected by a nates while driving” on page 6-107 and take MITSUBISHI MOTORS Authorized Serv- the necessary measures. ice Point. In such situations, a malfunctioning of the...
Page 287 Tyre pressure monitoring system (TPMS)* If the warning lamp/display il- Under-inflation also reduces fuel efficiency NOTE and tyre tread life, and may affect the vehi- luminates while driving The warning display is displayed on the in- cle’s handling and stopping ability. formation screen in the multi-information 1.
Page 288 Authorized Service Point. If the tyre repair is not done by a MITSUBISHI MOTORS Au- the sensors. thorized Service Point, damage to the tyre inflation pressure sensor is not covered by your warranty.
Page 289 Tyre pressure monitoring system (TPMS)* Reset of low tyre pressure 5. Drive for a while. The reset is completed 1. Switch to the function setting screen. if the warning lamp goes out. Refer to “Multi-information display warning threshold switches” on page 5-04. The threshold is set based on the tyre pres- Refer to “Changing the function set- sure which the reset function is executed by...
Page 290: Parking Sensors (Front/Rear)
Parking sensors (Front/Rear)* Corner and back sensor loca- NOTE CAUTION tions The tyre ID set is NOT changed, in case that The parking sensors assist you in determin- There are eight sensors (A) in the front and only 1 set of ID is registered. ing the approximate distance between the When changing the tyre ID set, the reset vehicle and any objects.
Page 291 Parking sensors (Front/Rear)* The detection areas are within approximately NOTE CAUTION 60 cm (A) from the front and corner sensors The sensors do not detect objects located in • The vehicle is driven on a rough road and 125 cm (B) from the back sensors. the area directly below or near the bumper.
Page 292 Parking sensors (Front/Rear)* Warning for obstacles To operate Back sensor (vehicles without a towing bar) To operate the system, the operation mode is If there is an obstacle in the vicinity of the put in ON. When the parking sensors are op- vehicle, a warning will be issued with the in- Vehicle to obstacle Warning display/...
Page 293 Parking sensors (Front/Rear)* Warning display NOTE NOTE In case there is a malfunction in the parking When the sensors detect different obstacles The mode of the detection area can be sensors, the display for the malfunctioning at the same time, the information screen in switched only when the selector lever is in the multi-information display indicates the the “R”...
Page 294: Rear-View Camera
Rear-view camera* Location of rear-view camera Even after the buzzer and display has stopped CAUTION warning, the indication lamp (A) on “SO- The rear-view camera (A) is integrated into The rear-view camera is an assistance sys- NAR” switch will continue blinking until the the part near the tailgate handle.
Page 295 Rear-view camera* Red line (B) indicates approximately NOTE 50 cm behind the rear bumper. Because the rear-view camera has a special Two Green lines (C) indicate approxi- lens, the lines on the ground between park- mately 20 cm outside of the vehicle ing spaces may not look parallel on the body.
Page 296 Rear-view camera* NOTE NOTE NOTE When the vehicle is tilting because of the • When there is an upward slope at the The reference lines for distance and vehicle number of people in the vehicle, the weight back. width are intended to indicate the distance to and positioning of luggage, and/or the condi- a flat object such as a level, flat road surface.
Page 297: Multi Around Monitor
Multi Around Monitor* Location of each cameras Multi Around Monitor* CAUTION Be sure to visually confirm safety around the The cameras are integrated into the location The Multi Around Monitor is a system that vehicle with your own eyes. Especially, the as shown below.
Page 298 Multi Around Monitor* Range of view of the Multi Range of view of the Multi WARNING Around Monitor cameras Around Monitor Do not install anything which will disturb the operation of the cameras around the The range of view of the Multi Around Mon- location of them.
Page 299 Multi Around Monitor* Bird’s eye-view/Rear-view mode Bird’s eye-view/Front-view CAUTION mode Views of the surroundings of the vehicle and The cameras have special lenses that can behind the vehicle are displayed. Views of the surroundings of the vehicle and make objects shown on the screen appear to be closer or further away than they actually the front of the vehicle are displayed.
Page 300 Multi Around Monitor* Operation with the selector lev- NOTE NOTE It is not possible to fully see obstacles when If there is no operation for 3 minutes after the lens is dirty. If the lens becomes conta- the Multi Around Monitor is displayed by When you place the selector lever in the “R”...
Page 301 Be sure to have it inspected with the steering wheel turned. It disap- 1- Approximately 100 cm from the by a MITSUBISHI MOTORS Authorized pears when the steering wheel is in the Service Point. front edge of the front bumper neutral position.
Page 302 Multi Around Monitor* Therefore when there is an obstacle on the NOTE upward slope, it appears farther than its ac- When the expected course lines are dis- tual position. played in the rear-view, the expected course lines are also displayed in the bird’s eye- view (Front: broken line, Rear: solid line).
Page 303 Multi Around Monitor* Therefore when there is an obstacle on the Therefore when there is an obstacle on the However, the vehicle may hit the truck be- upward slope, it appears farther than its ac- downward slope, it appears closer than its ac- cause the body of the truck strays onto the tual position.
Page 304 Multi Around Monitor* When approaching to solid objects Side-view mode Bird’s eye-view mode The reference lines for distance and vehicle Reference lines for the vehicle width and the An overhead view in which the vehicle is width are intended to indicate the distance to front end of the vehicle are displayed on the looked down is displayed so that you can a flat object such as a level, flat road surface.
Page 305 Multi Around Monitor* CAUTION NOTE CAUTION The bird’s eye-view is an simulated view In the Bird’s eye-view mode, since the views For reasons of safety, do not operate the processed by combining view captured by captured by the four cameras, “Front-view switch while driving.
Page 306: Cargo Loads
Cargo loads precautions MITSUBISHI MOTORS Authorized Serv- Before driving and after travelling a short ice Point. distance, always check the load to make sure CAUTION it is securely fastened to the roof carrier.
Page 307: Trailer Towing
Never exceed the maximum towable weight that meets all relevant regulations in your with brake and the maximum trailer-nose area, consult a MITSUBISHI MOTORS Au- weight as listed in the specifications. thorized Service Point. For the specific value, refer to “Vehicle Check that your towing bar coupling ball weight”...
Page 308 Trailer towing* Be sure that the driving speed does not CAUTION 21 mm exceed 100 km/h (62 mph) for trailer op- 68.5 mm On vehicles equipped with CVT, if the eration. warning display is showing, the temperature It is also recommended that you obey the 328.5 mm of the CVT fluid is high.
Page 309 For pleasant driving Important air conditioning operation tips..........7-02 Ashtray*....................7-79 Ventilators................... 7-02 Accessory socket.................7-80 Automatic air conditioning*............... 7-05 Interior lamps..................7-80 Dual-zone automatic climate control air conditioning*......7-10 Storage spaces..................7-83 Customizing the air conditioning............7-15 Drink holder..................7-84 Air purifier..................7-22 Bottle holder..................7-85 LW/MW/FM radio/CD player*............
Page 310: Important Air Conditioning Operation Tips
Important air conditioning operation tips During a long period of disuse Important air conditioning When operating the system, make sure the air intake, which is located in front operation tips of the windscreen, is free of obstructions The air conditioning should be operated for at such as leaves and snow.
Page 311 Ventilators To close the ventilator, move the knob (A) to 1. Open the inside as far as possible. 2. Close CAUTION Be careful not to spill beverages, etc., into the ventilators. Doing so might cause the air conditioning not to function normally. NOTE The cool air from the ventilators may appear as a mist.
Page 312 Ventilators Changing the position of air flowing from the ventilators Each time the MODE switch is pressed, the mode changes to the next one in the following sequence: “ ” → “ ” → “ ” → “ ” → “...
Page 313: Automatic Air Conditioning
Automatic air conditioning* NOTE If your vehicle is equipped with the Auto Stop & Go (AS&G) system, the windows may start to fog up while the AS&G system is operating. If this occurs, press the demister switch to remove fog from the windows. When using the “...
Page 314 Automatic air conditioning* Demisting of the windscreen • Operating the system in manual mode CAUTION ® p. 7-07 and door windows When setting the MODE switch to the • Adjusting blower speed “ ” position, it also can prevent the win- ®...
Page 315 Automatic air conditioning* Operating the system in auto- Adjusting the blower speed NOTE matic mode Press of the blower speed selection If the blower speed selection switch, A/C switch to increase the blower speed. switch, MODE switch, or air selection switch is operated while the system is oper- Press of the blower speed selection...
Page 316 Refer to “Changing the temperature unit” on ger compartment. For further information, we recommend you page 5-16. to consult a MITSUBISHI MOTORS Au- While the engine coolant temperature is low, thorized Service Point. the temperature of air flowing will not be Refer to “Customizing the air conditioning”...
Page 317 Automatic air conditioning* Recirculated air: Indication lamp (A) is CAUTION NOTE Normally, use the outside position to prevent When the engine coolant temperature rises Air is recirculated inside the passenger the windows from fogging up. to a certain level, the air selection is auto- compartment.
Page 318: Dual-Zone Automatic Climate Control Air Conditioning
Dual-zone automatic climate control air conditioning* Dual-zone automatic climate control air conditioning* The air conditioning can only be used while the engine is running. 6. Air selection switch ® p. 7-14 15. Blower speed display ® p. 7-12 1. Driver’s side temperature control switch (LHD vehicles) ®...
Page 319 Dual-zone automatic climate control air conditioning* Demisting of the windscreen • Operating the system in automatic CAUTION mode ® p. 7-12 and door windows For safety, make sure you have a clear view • Operating the system in manual mode through all the windows.
Page 320 Dual-zone automatic climate control air conditioning* Operating the system in auto- Press of the blower speed selection NOTE switch to decrease the blower speed. matic mode If the blower speed selection switch, A/C The selected blower speed (A) will be shown switch, MODE switch, or air selection in the display.
Page 321 Refer to “Changing the temperature unit” on For further information, we recommend you page 5-16. to consult a MITSUBISHI MOTORS Au- While the engine coolant temperature is low, NOTE thorized Service Point. the temperature of air flowing will not be Refer to “Customizing the air conditioning”...
Page 322 Dual-zone automatic climate control air conditioning* Switching the air conditioning Recirculated air: Indication lamp (A) is NOTE system ON/OFF When the engine coolant temperature rises Air is recirculated inside the passenger to a certain level, the air selection is auto- Press the switch to turn the air conditioning compartment.
Page 323: Customizing The Air Conditioning
Customizing the air conditioning Customizing the air conditioning The following customise functions can be applied. Modification method MITSUBISHI MITSUBISHI Automatic cli- Smart phone Item Setting content Factory setting Multi-Commu- MOTORS Au- Link Display mate control nication System thorized Service panel Audio Point (MMCS)
Page 324 Customizing the air conditioning Modification method MITSUBISHI MITSUBISHI Smart phone Automatic cli- Item Setting content Factory setting Multi-Commu- MOTORS Au- Link Display mate control nication System thorized Service panel Audio Point (MMCS) Allows you to se- A/C switch control lect the function that switches au- tomatically or Automatically...
Page 325 Customizing the air conditioning Modification method MITSUBISHI MITSUBISHI Smart phone Automatic cli- Item Setting content Factory setting Multi-Commu- MOTORS Au- Link Display mate control nication System thorized Service panel Audio Point (MMCS) Allows you to se- ECO mode lect the function that operates or does not operate economical driv-...
Page 326 Customizing the air conditioning Modification method MITSUBISHI MITSUBISHI Smart phone Automatic cli- Item Setting content Factory setting Multi-Commu- MOTORS Au- Link Display mate control nication System thorized Service panel Audio Point (MMCS) Foot/Demister airflow ratio When you select MODE switch, this al- lows you to set the ratio between Normal...
Page 327 Customizing the air conditioning Modification method MITSUBISHI MITSUBISHI Smart phone Automatic cli- Item Setting content Factory setting Multi-Commu- MOTORS Au- Link Display mate control nication System thorized Service panel Audio Point (MMCS) Face/Foot airflow ratio When you select MODE switch, this al- lows you to set the ratio between Normal...
Page 328 Customizing the air conditioning Modification method MITSUBISHI MITSUBISHI Smart phone Automatic cli- Item Setting content Factory setting Multi-Commu- MOTORS Au- Link Display mate control nication System thorized Service panel Audio Point (MMCS) Automatic rear operation Allows you to se- demist at engine start lect the function that switches auto or manual opera-...
Page 329 Customizing the air conditioning Modification method MITSUBISHI MITSUBISHI Smart phone Automatic cli- Item Setting content Factory setting Multi-Commu- MOTORS Au- Link Display mate control nication System thorized Service panel Audio Point (MMCS) Setting temperature When you feel that it is hot or cold to the setting temperature, it is Normal...
Page 330: Air Purifier
Air purifier Important Points on Usage When the setting is changed from disa- NOTE ble to enable 2 sounds are emitted and To listen to the audio system while the en- the indicator flashes three times. iPod/iPhone Playback Func- gine is not running, turn the ignition switch tion* to the “ACC”...
Page 331 LW/MW/FM radio/CD player* Inc., registered in the U.S. and other NOTE countries. ® For vehicles with a Bluetooth 2.0 interface, Apple is not responsible for the opera- the types of devices that can be connected tion of this device or its compliance with may vary.
Page 332 LW/MW/FM radio/CD player* 5th generation 5th generation (video) (video) 6th generation 5th generation 4th generation (video) (video camera) 3rd generation 2nd generation 1st generation (video) (aluminium) 7-24 For pleasant driving OGKE19E1...
Page 333: Handling Of Discs
Handling of Discs Important Points on Handling If discs are not going to be used for a long period of time, remove these from the product. Fingerprints or other marks on the read surface of the disc may result in its con- Disc Playback Environment tent being more difficult to read.
Page 334: Audio Files (Mp3/Wma/Aac)
Audio Files (MP3/WMA/AAC) Do not insert irregularly-shaped discs Playback of other than standard CDs is Maxi- (for example, heart-shaped), as these not guaranteed. Even if the audio can be may result in malfunction. Additionally, played back, the audio quality cannot be Type Size play-...
Page 335 Audio Files (MP3/WMA/AAC) If the MP3/WMA/AAC format audio files in- You can create a folder structure as in Genre - NOTE cludes title information or other data, then Artist - Album - Track (MP3/WMA/AAC Files larger than 2GB in size cannot be this can be displayed.
Page 336 Audio Files (MP3/WMA/AAC) NOTE Speci- Speci- Name fica- Explanation Name fica- Explanation The order in which folders and audio files tion tion are displayed on this product may be differ- ent to how they are displayed on a computer. ISO96 Level Maximum 8 Maxi-...
Page 337 Audio Files (MP3/WMA/AAC) Standards for MP3 Files That Standards for WMA Files That Item Details Can Be Played Back Can Be Played Back Maximum 64 characters Specifications for MP3 files that can be Specifications for WMA files that can be number of played are as shown below.
Page 338: Important Points On Safety For The Customer
Sampling MPEG4 8/11.025/12/16/22.05 jury or damage to yourself, other users, or and consult a MITSUBISHI MOTORS frequency property. /24/32/44.1/48 Authorized Service Point. [kHz] Continuing to use the product may result MPEG2 8/11.025/12/16/22.05...
Page 339: Operation Keys
Operation Keys WARNING Do not disassemble or modify the prod- uct. This may lead to malfunction, fire, or electric shock. During thunderstorms, do not touch the antenna or the front panel. This may lead to electrical shock from lightning. CAUTION Turn the power on, and resume playback Turn the PWR/VOL key clockwise to in- from the previous status.
Page 340 Operation Keys Disc slot Disc *Label side Push the disc in a certain amount, and the product will pull the disc in, and playback will start. 2. Press the key. This will eject the disc from the product, so remove the disc. CAUTION When replacing discs, first ensure that the vehicle is stopped in an area in which stop-...
Page 341 Operation Keys Explanation of Buttons This explains names and functions of each part. 6- PWR/VOL key 12- PAGE key Use to eject a disc. Adjust the volume, and turn the power Display indicator page advance. 2- 3 key/4 ON/OFF. 13- 5 For audio, rewind/fast forward.
Page 342: Listening To The Radio
Listening to the Radio key/ 16- MENU key /SEL key For audio, select audio track/file; for ra- Switch to Menu mode. Adjust audio quality and select items. dio, perform automatic station selection For radio, manually select stations. or ensemble/service station selection. Steering wheel audio remote 3- MODE Key Requires DAB tuner connection.
Page 343: Listening To Dab
Listening to DAB* 2. Turn the /SEL key to select PTY. NOTE Reduces the frequency being /SEL key The PTY (program content) indicator received. (counter- Pressing the preset key will select the previ- will flash, and station selection will au- clockwise) ously registered frequency.
Page 344 Listening to DAB* Select a Service Register the Service NOTE If the text information for the service name 1. Hold down the key or the key. Register the service in advance, and select cannot be obtained, then nothing is dis- Receives the lead services of the ensem- this at a later time.
Page 345: Listening To Traffic Messages
Listening to Traffic Messages NOTE NOTE Listening to CDs When selecting PTY, select the PTY to reg- If traffic messages are received, then this This explains how to listen to audio CDs ister, and hold down any of the keys from will switch to the volume of the previously (CD-DA/CD-TEXT).
Page 346: Listening To Mp3S
Listening to MP3s Fast Forward or Rewind Repeat playback of the track currently being Listening to MP3s played. Hold down the 3 key or the 4 key. This explains how to listen to audio files on a Fast forward/rewind is possible. NOTE disc.
Page 347: Listening To An Ipod
Listening to an iPod Random Playback (RDM) 4. Press the /SEL key. CAUTION This plays the selected file (track). Press the 2RDM key. No indemnification for data loss resulting Play the tracks in the folder in a random or- when the iPod/iPhone is connected to the NOTE product will be possible.
Page 348 Listening to an iPod Repeat Playback (RPT) NOTE NOTE Press the 1RPT key. When connecting the iPod/iPhone, use a If an iPod/iPhone does not operate correctly, commercially available iPod connection ca- then remove the iPod/iPhone from the prod- ble. uct, reset, then reconnect. Repeat playback of the track currently being Set up the device in order that no unsafe ac- played.
Page 349: Listening To Audio Files On A Usb Device
Listening to Audio Files on a USB Device Search Tracks NOTE CAUTION If there is no operation for five seconds after Depending on how the devices are handled, Search categories or track names, and select a selecting the track, that file is played back. audio files being damaged or lost, therefore track.
Page 350 Listening to Audio Files on a USB Device Select the Track (File) NOTE Repeat playback of the tracks within the fold- Buttons on the product will not operate er currently being played. Press the key or key to select the while USB device is connected.
Page 351: To Play Ipod/Usb Memory Device Tracks Via Voice Opera
® To play iPod/USB memory device tracks via voice operation (vehicles with Bluetooth 2.0 interface) To play iPod/USB memory 1. Turn the /SEL key to select the folder. NOTE 2. Press the /SEL key. device tracks via voice Pressing again will cancel. Even if the file is selected, all folder random operation (vehicles with Files within the selected folder are dis-...
Page 352 ® To play iPod/USB memory device tracks via voice operation (vehicles with Bluetooth 2.0 interface) To search by artist name NOTE NOTE 1. Say “Play” on the main menu. If you say “No” to three or all artist names ® The Bluetooth 2.0 interface starts recogniz- uttered by the system, the voice guide will...
Page 353 ® To play iPod/USB memory device tracks via voice operation (vehicles with Bluetooth 2.0 interface) 2. After the voice guide says “Would you 6. After the voice guide says “Playing NOTE like to play by Artist, Album, Playlist or <playlist>,” the system creates an index If you say “No”...
Page 354: Listening To Bluetooth Audio
Listening to Bluetooth Audio* NOTE NOTE NOTE If you say “Genre <type>,” you can skip If the confirmation function is active, the Depending on the type of Bluetooth-capable step 3. voice guide confirms if the genre is correct. audio devices, usage may not be possible, or If the genre is correct, say “Yes”.
Page 355 Listening to Bluetooth Audio* Operation methods below describe situations This enables selection of the next or previous NOTE once connection has been completed. track. Pressing again will cancel. Fast Forward or Rewind NOTE Scan Playback (SCAN) If the iPod/iPhone is connected via Blue- Hold down the 3 key or the 4 key.
Page 356: Display Indicator
Display Indicator Display Indicator This explains content of the display indicator. During DAB Reception* Change the Display Mode CAUTION You can change the content of the display in- This switches in the order “Service name”, The operation of changing display contents dicator.
Page 357: Audio Quality And Volume Balance Adjustment
Audio Quality and Volume Balance Adjustment During CD-DA playback Adjust Audio Quality and Vol- NOTE ume Balance This switches in the order “Disc title”, “Track During display of the ID3tag, hold down the title”, and “Operating status”. DISP key to switch to the folder title display. 1.
Page 358: System Settings
System Settings DAB Setting* RDS Setting just- Turn counter- Turn clockwise ment clockwise Change DAB settings Change RDS settings items (“Set value” bold typeface indicates factory (“Set value” bold typeface indicates factory SCV OFF, LOW MID, HIGH default settings.) default settings.) (SCV effect is (SCV effect is OFF/low)
Page 359 System Settings Settings Settings val- Settings con- Settings Settings val- Settings con- Settings Settings val- Settings con- name tent name tent name tent REG OFF Automatical- PI-S OFF Do not search SVENSK Set the dis- ly track the for the same play language local station station or lo-...
Page 360 System Settings PHONE Settings NOTE Settings Settings val- Settings con- name tent Some models may not be confirmed as con- Change the mobile phone voice cut-in set- CT OFF Do not up- nected, or may not connect. ® tings and the Bluetooth 2.0 interface lan- date the time guage.
Page 361 System Settings Settings Settings Settings con- Settings content Settings name value value tent FRENCH ule voice lan- PHONE During mobile phone voice guage. IN-R cut-in, output sound from the GER- right front speaker. PHONE During mobile phone voice SPANISH IN-LR cut-in, output sound from the ITALIAN left and right front speakers.
Page 362: Troubleshooting
Turn the power OFF and wait a short while. If the prob- USB BUS PWR There is high or low electrical current or voltage. lem persists, consult a MITSUBISHI MOTORS Author- LSI ERROR There is an internal malfunction for some reason.
Page 363 An abnormal direct voltage has been sent to the speak- Turn the power OFF and wait a short while. If the prob- ers. lem persists, consult a MITSUBISHI MOTORS Au- thorized Service Point. If You Think Something Is Not Working Properly...
Page 364: Link System
Link System* http://www.jciblueconnect.com/faq/fulldi- Link System* WARNING sclosure.pdf ® Although the Bluetooth 2.0 interface al- The Link System takes overall control of the lows you to make hands-free calls, if you ® Bluetooth 2.0 interface* devices connected via the USB input terminal choose to use the cellular phone while ®...
Page 365 For details on the Bluetooth 2.0 interface, you can see them by accessing the Press this button to change to voice rec- MITSUBISHI MOTORS website. ognition mode. Please read and agree the “Warning about While the system is in voice recognition Links to the Web Sites of Other Companies”...
Page 366 ® Bluetooth 2.0 interface* • In such circumstances, you can press NOTE NOTE the button briefly to switch between Call waiting and three-way calls can be used If the voice command that you say differs callers. You will switch to the first ®...
Page 367 ® Bluetooth 2.0 interface* If you are at the main menu, say “Cancel” to 5. The voice guide will say “Confirmation NOTE prompts are <off/on>” and then the sys- ® exit from the Bluetooth 2.0 interface. The voice guide will repeat the same mes- tem will return to the main menu.
Page 368 “Cancel” to quit the voice input mode and ® This makes it easier for the Bluetooth NOTE then check with a MITSUBISHI MOTORS interface to recognise voice commands said Authorized Service Point. Password will be required to access the sys- by you.
Page 369 ® Bluetooth 2.0 interface* in the “P” (PARK) position, and apply 5. The voice guide will prompt for phrase Enabling and disabling the the parking brake. 1. Repeat the corresponding phrase lis- voice model and retraining ted in table “Enrollment commands” on You can turn a voice model registered with page 7-76.
Page 370 ® Bluetooth 2.0 interface* To pair ® Connecting the Bluetooth NOTE ® interface and Bluetooth ® To pair a Bluetooth device with the Blue- If 7 devices have already been paired, the vice voice guide will say “Maximum devices ® tooth 2.0 interface, use either one of the fol- paired”...
Page 371 ® Bluetooth 2.0 interface* NOTE NOTE NOTE The pairing code entered here is only used If you enter the wrong number, the voice ® You cannot pair any Bluetooth device with ® guide will say “Pairing failed” and the pair- for the Bluetooth connection certification.
Page 372 ® Bluetooth 2.0 interface* manual for instructions.” and then will 7. The voice guide will say “Pairing Com- NOTE say “The pairing code is <pairing plete. Would you like to import the con- ® If the Bluetooth 2.0 interface cannot recog- code>.”...
Page 373 ® Bluetooth 2.0 interface* 8. The voice guide will say “Do you want correct. Answer “Yes” to continue and When the confirmation function is on, to pair a device now?” Answer “Yes,” connect to the cellular phone. the system will ask you again whether the system will proceed to Step 3 in the Answer “No,”...
Page 374 ® Bluetooth 2.0 interface* 4. The voice guide will say “Select one of ® NOTE To check a paired Bluetooth the following: pair, edit, delete, or list.” device If you press and release the SPEECH button Say “Delete.” and say “Continue” or “Previous” while the ®...
Page 375 ® Bluetooth 2.0 interface* Operating a music player con- ® To make a call tooth devices and device tags of corre- sponding devices in order, starting with ® nected via Bluetooth You can make a call in the following 3 ways ®...
Page 376 ® Bluetooth 2.0 interface* 3. After the voice guide says “Name NOTE NOTE please,” say the name you want to call, In the case of English, the system will recog- If the name you selected has matching data from those registered in the phone book. nise both “zero”...
Page 377 ® Bluetooth 2.0 interface* Phone book function If the CD player or radio was playing when Redialing the incoming call was received, the audio ® You can redial the last number called, based The Bluetooth 2.0 interface has 2 types of system will mute the sound from the CD on the history of dialed calls in the paired cel- unique phone books that are different from...
Page 378 ® Bluetooth 2.0 interface* The vehicle phone book can be used with all bile, or other?” Say the location for 7. The voice guide will repeat the tele- paired cellular phones. which you want to register a telephone phone number you have just read, and number.
Page 379 ® Bluetooth 2.0 interface* NOTE NOTE NOTE Transfer is not permitted unless the vehicle If the maximum number of entries are al- Pressing the HANG-UP button or pressing is parked. Before transferring, make sure ready registered, the voice guide will say and holding the SPEECH button will cancel that the vehicle is parked in a safe location.
Page 380 ® Bluetooth 2.0 interface* 10. The voice guide will say “Would you 7. The voice guide will repeat the tele- NOTE like to import another contact?” phone number. Say “List names,” and the names registered Answer “Yes” if you want to continue When the confirmation function is on, in the phone book will be read out in order.
Page 381 ® Bluetooth 2.0 interface* 5. When the voice guide is done reading the phone book entry in which the tele- NOTE the list, it will say “End of list, would phone number you want to delete is reg- Say “List names,” and the names registered you like to start from the beginning?”...
Page 382 ® Bluetooth 2.0 interface* 6. The system will ask if you really want to 4. For confirmation purposes, the voice ® The Bluetooth 2.0 interface automatically delete the selected telephone number(s) guide will ask “Are you sure you want to converts from text to voice the names regis- to go ahead with the deletion, answer erase everything from your hands-free...
Page 383 ® Bluetooth 2.0 interface* Answer “No,” to return to the main NOTE menu. All or part of data may not be transferred, even when the cellular phone supports Blue- NOTE ® tooth , depending on the compatibility of the device. The transfer may take some time to com- Only a home, a work, and a mobile number plete depending on the number of contacts.
Page 384: Usb Input Terminal
USB input terminal* Enrollment commands The USB input terminal (A) is located in the This section explains how to connect and re- USB input terminal* indicated position. move a USB memory device or iPod. See the following section for details on how You can connect your USB memory device to play music files.
Page 385 USB input terminal* How to connect an iPod 2. Connect a commercially available USB [For vehicles equipped with connector cable (B) to the USB memory LW/MW/FM radio/CD player] 1. Park your vehicle in a safe place and device (A). turn the ignition switch to the “LOCK” Refer to “Listening to an iPod”...
Page 386: Sun Visors
Sun visors For connectable device type for “iPod ,” NOTE Sun visors “iPod classic ,” “iPod nano ,” “iPod touch ” Do not connect to the USB input terminal and “iPhone ,” access the MITSUBISHI any device (hard disk, card reader, memory MOTORS website.
Page 387: Ashtray
Ashtray* Type 1 Type 2 Ashtray* Operating the lid of the vanity mirror will au- A vanity mirror is fitted to the back of the CAUTION tomatically turn on the mirror lamp (A). sun visor. Put out matches and cigarettes before they are placed in the ashtray.
Page 388: Accessory Socket
Accessory socket Mounting position for movea- CAUTION Floor console ble ashtray When the accessory socket is not in use, be sure to close the lid or install the cap, be- The moveable ashtray can be installed in the cause the socket might become clogged by drink holder.
Page 389 Interior lamps Room lamps 4. LED interior illumination (Smartphone Position of On/off control tray) lamp switch 5. LED interior illumination (Front drink 2-DOOR The lamp illuminates when holder) Front a door or the tailgate is )/(•) opened. It goes off approxi- NOTE mately 15 seconds after all doors and the tailgate are...
Page 390 The time until the lamp goes off can be ad- justed. details, please consult The lamp illuminates when the tailgate is MITSUBISHI MOTORS Authorized Serv- opened, and goes off when the tailgate is ice Point. closed. On vehicles equipped with the Smartphone Link Display Audio or the MITSUBISHI...
Page 391: Storage Spaces
The time until the lamps au- tomatically go off can be adjusted. For de- tails and support, consult your nearest MITSUBISHI MOTORS Authorized Serv- ice Point. On vehicles equipped with the Smartphone Link Display Audio or the MITSUBISHI...
Page 392: Drink Holder
If you accidentally spill a beverage, wipe up as much liquid as possible and imme- diately consult a MITSUBISHI MOTORS Authorized Service Point. CAUTION Do not drink beverages while driving. This is distracting and could cause an accident.
Page 393: Bottle Holder
(A). If you accidentally spill a beverage, wipe up as much liquid as possible and imme- diately consult a MITSUBISHI MOTORS Authorized Service Point. CAUTION Do not drink beverages while driving. This NOTE is distracting and could cause an accident.
Page 394 Cargo area cover* To change position To refit 2. After changing the position, gently shake the entire cover to make sure it is securely retained. There are two installation holes (B) for the Refit the cover by performing the removal cover.
Page 395: Assist Grips
Assist grips NOTE CAUTION WARNING Except for vehicles equipped with a spare Do not use the assist grips when getting into Do not put a hanger or any heavy or poin- tyre, the cover can be stored under the lug- or out of the vehicle.
Page 396: Convenient Hook
Convenient hook CAUTION Luggage floor board Do not pile up the luggage beyond the seat- 1. Hold the tab (A) and lift the luggage back height. Also, firmly secure the luggage. floor board. Otherwise, serious accidents could result due to hindered rearward view or flying objects during sudden braking.
Page 397 For emergencies ERA-GLONASS*................8-02 If the vehicle breaks down..............8-08 If the operation mode cannot be changed to OFF (vehicles equipped with the keyless operation system)......... 8-08 Emergency starting................8-08 Engine overheating................8-10 Tools and jack*................... 8-11 Tyre repair kit*..................8-13 How to change a tyre................8-19 Towing....................
Page 398: Era-Glonass
ERA-GLONASS* Flow of the emergency call ERA-GLONASS* WARNING • When the vehicle is in a place where ra- ERA-GLONASS is a system designed to re- dio waves cannot be transmitted and duce the severity of accidents. The location received. (for example, indoor, a base- and vehicle information is transmitted from ment parking area, mountainous area, inside a tunnel, etc.)
Page 399 60 seconds. (The vehicle may be in a The battery life is approximately 3 years. place where radio waves cannot be Have the system inspected or the battery transmitted and received.) replaced by a MITSUBISHI MOTORS Authorized Service Point immediately. For emergencies 8-03 OGKE19E1...
Page 400 ERA-GLONASS* 4. The green lamp blinks slowly, and the 6. The emergency call centre arranges for WARNING location and vehicle information is trans- despatch of the emergency vehicle as re- An error may occur between the actual mitted to the emergency call centre. quired.
Page 401 “ON” seconds) seconds) ure in the system. In this case, immediately have the system inspected at a MITSUBISHI MOTORS Au- thorized Service Point. Extinguishes Extinguishes The system works normally. − No sound After approximately 20 seconds after setting...
Page 402 Before operation, stop the vehicle in a safe Therefore, if you want to check the system, switch. please consult a MITSUBISHI MOTORS place, with good visibility, where radio 4. Press the SOS switch 3 or more times. Authorized Service Point.
Page 403 If you do not press the SOS switch within failure in the system. Have the system in- approximately 20 seconds, the test mode spected by a MITSUBISHI MOTORS ends. Authorized Service Point immediately. For emergencies...
Page 404: If The Vehicle Breaks Down
Refer to “Hazard warning flasher switch” on Check the jumper cables for damage and Contact a MITSUBISHI MOTORS Au- page 5-62. corrosion before use. thorized Service Point. Always wear protective eye goggles when If the engine stops/fails working near the battery.
Page 405 Emergency starting 4. Make sure battery electrolyte is at the hicle with the discharged battery at the 6. Start the engine in the vehicle which has proper level. point farthest from the battery. the booster battery, let the engine idle a Refer to “Battery”...
Page 406: Engine Overheating
[If the cooling fans are not turning] When the engine is overheating, the informa- Stop the engine immediately and contact tion screen in the multi-information display a MITSUBISHI MOTORS Authorized WARNING will be interrupted and the engine coolant Service Point for assistance.
Page 407: Tools And Jack
Tools and jack* 6. Examine the radiator hoses for coolant The storage location of the tools and jack leakage and the drive belt for looseness should be remembered in case of an emer- FULL or damage. gency. If there is anything wrong with the cool- ing system or drive belt, we recommend Vehicles with normal spare wheel you to have it checked and repaired.
Page 408 Tools and jack* Jack 2- Jack 2. Retract the jack and remove it from its installation fitting (A). The jack is used only for the purpose of Vehicles with tyre repair kit changing a tyre when a tyre is punctured. NOTE The jack is maintenance-free.
Page 409: Tyre Repair Kit
Do not allow children to touch the tyre seal- ant. Do not breathe in the vapours of tyre sealant. Be sure to use a MITSUBISHI MOTORS 1- Tyre compressor GENUINE tyre sealant. 2- Tyre sealant bottle 3- Valve insert (spare)
Page 410 The puncture hole has a length or width of ly, be sure to purchase a new one from a 4 mm or more. MITSUBISHI MOTORS Authorized Serv- • The tyre is punctured in the side wall (A), ice Point before the expiry date.
Page 411 Tyre repair kit* squeeze it again and again to inject all of NOTE the sealant into the tyre. In cold conditions (when the ambient tem- perature is 0 °C or lower), thickening of the tyre sealant can make the tyre sealant hard to squeeze out of the bottle.
Page 412 Tyre repair kit* 12. After injecting the sealant, securely fit 14. Place the compressor (L) with its air the valve remover (E) into the end of the pressure gauge (M) on top. filler hose (J) to prevent sealant from Pull out the compressor’s power cord leaking from the empty bottle.
Page 413 Tyre repair kit* (Refer to “Tyre inflation pressures” on CAUTION CAUTION page 10-10.) The compressor is not waterproof. If you use If the compressor becomes sluggish or hot it in rain, make sure water does not get on it. while operating, it is overheating. Immedi- Any sand or dust sucked into the compressor ately place the switch in the OFF position could make the compressor break down.
Page 414 Tyre repair kit* CAUTION CAUTION If you sense any abnormality while driving, If the tyre pressure is lower than the mini- stop the vehicle and contact a MITSUBISHI mum permitted pressure (1.3 bar {130 MOTORS Authorized Service Point or an- kPa}), the tyre cannot successfully be re- other specialist.
Page 415: How To Change A Tyre
Please give the empty sealant bottle to your (Reverse) position. perature is 0 °C or lower), the time and driv- MITSUBISHI MOTORS Authorized Serv- On vehicles with CVT, move the selec- ing distance necessary until completion of ice Point when you purchase new sealant or tor lever to the “P”...
Page 416 Driving with an insufficient tyre pressure MITSUBISHI MOTORS Authorized Serv- an accident. can lead to an accident. If you have no ice Point.
Page 417 How to change a tyre 2. Place the jack under one of the jacking CAUTION NOTE points (A) shown in the illustration. Use Upon installation of the temporary spare Put the spare wheel under the vehicle body the jacking point closest to the tyre you wheel, the ground clearance is reduced as near the jack.
Page 418 How to change a tyre 3. Rotate the jack by hand until the flange Slowly rotate the wheel nut wrench until WARNING portion (B) fits in the groove (C) at the the tyre is raised slightly off the ground Do not turn the raised wheel. The tyres top of the jack.
Page 419 How to change a tyre nuts make light contact with the wheel WARNING CAUTION and the wheel is not loose. Mount the spare wheel with the valve Never apply oil to either the wheel bolts or stem (I) facing outboard. If you cannot see the nuts, or they will tighten too much.
Page 420 How to change a tyre Tightening torque 88 to 108 Nm 12. Check your tyre inflation pressure at the CAUTION next gasstation. The correct tyre pres- If the steering wheel vibrates when driving sures are shown on the driver’s door la- after changing the tyre, we recommend you bel.
Page 421 How to change a tyre To install Wheel covers* NOTE 1. Make sure the tabs (A) of the back of the vehicles with T155/90D16 To remove wheel cover are not broken and correctly T155/80D17 size spare wheel, the clamp cannot be used for a normal size tyre. fitted on the rings (B).
Page 422: Towing
Authorized Service Point or a commercial tow truck service for assistance. Only when you cannot receive a towing serv- ice from a MITSUBISHI MOTORS Author- NOTE ized Service Point or commercial tow truck service, tow your vehicle carefully in accord-...
Page 423 Towing Towing the vehicle by a tow The regulations concerning towing may dif- CAUTION fer from country to country. It is recommen- truck [For 2WD vehicles equipped with the Active ded that you obey the regulations of the area Stability Control (ASC)] where you are driving your vehicle.
Page 424 Towing Turn the ignition switch to the “ACC” posi- If the engine is not running, perform the tion or put the operation mode in ACC and following operation to unlock the steer- secure the steering wheel in a straight-ahead ing wheel. position with a rope or tiedown strap.
Page 425 Towing Otherwise, the instructions are the same as CAUTION WARNING for “When being towed by another vehicle”. Do not leave the ignition switch in the When going down a long slope, the brakes “LOCK” position or the operation mode in may overheat, reducing effectiveness.
Page 426: Operation Under Adverse Driving Conditions
Operation under adverse driving conditions Operation under adverse (c) Always maintain the specified tyre infla- Accumulation of ice on the braking sys- tion pressures. tem can cause the wheels to lock. Pull driving conditions away from a standstill slowly after con- On a snow-covered or frozen firming safety around the vehicle.
Page 427 Operation under adverse driving conditions Manufacturer of the vehicle is proceeding from the following assumption: taking the decision to keep driving under conditions mentioned above, driver takes all actions at own risk, aware of possible conse- quences. For emergencies 8-31 OGKE19E1...
Page 428 OGKE19E1...
Page 429 Vehicle care Vehicle care precautions..............9-02 Cleaning the interior of your vehicle..........9-02 Cleaning the exterior of your vehicle..........9-03 OGKE19E1...
Page 430 Vehicle care precautions Cleaning the interior of your Vehicle care precautions NOTE vehicle Do not use cleaners, conditioners, and pro- In order to maintain the value of your vehi- tectants containing silicons or wax. cle, it is necessary to perform regular mainte- Such products can cause discolouring and, After cleaning the interior of your vehicle nance using the proper procedures.
Page 431 Cleaning the exterior of your vehicle Genuine leather* Cleaning the exterior of Rinse thoroughly and wipe dry with a soft cloth. After washing the vehicle, carefully your vehicle 1. To clean, lightly wipe the leather with a clean the joints and flanges of the doors, bon- soft cloth soaked in a mild soap and wa- net and other sections where dirt is likely to ter solution.
Page 432 Cleaning the exterior of your vehicle Waxing CAUTION CAUTION Waxing the vehicle will help prevent the ad- • Maintain a distance of approximately • As your vehicle has a rain sensor, place herence of dust and road chemicals to the 70 cm or more between the vehicle body the wiper switch lever in the “OFF”...
Page 433 Cleaning the exterior of your vehicle Cleaning plastic parts Aluminium wheels* Glass cleaner can be used to remove oil, grease, insect carcasses, etc. After washing Use a sponge or chamois leather. 1. Remove dirt using a sponge while sprin- the glass, wipe it dry with a clean, dry, soft If a car wax adheres on a grey or black rough kling water on the wheels.
Page 434 Cleaning the exterior of your vehicle NOTE The surface treatment on the inside of the glass may be removed if hard cloth or organ- ic solvent (benzine, kerosene, thinner, etc.) is used. Engine compartment Clean the engine compartment at the begin- ning and end of winter.
Page 435 Maintenance Service precautions................10-02 Catalytic converter................10-03 Bonnet....................10-03 Engine oil..................10-04 Engine coolant...................10-05 Washer fluid..................10-06 Brake fluid/Clutch fluid*..............10-07 Battery....................10-08 Tyres....................10-10 Wiper blade rubber replacement............10-14 General maintenance.................10-16 Fusible links..................10-16 Fuses....................10-17 Replacement of lamp bulbs...............10-21 OGKE19E1...
Page 436: Service Precautions
MITSUBISHI MOTORS Authorized Service etc., does not become caught by the cool- Point or another specialist. ing fans, drive belts, or other moving In the event a malfunction or a problem is parts.
Page 437: Catalytic Converter
Catalytic converter 2- Engine oil cap Bonnet CAUTION 3- Engine coolant reservoir Only open the bonnet when the wipers are in 4- Washer fluid reservoir the original position. Failure to do so may 5- Brake fluid reservoir/Clutch fluid reser- To open cause damage to the bonnet, wiper arms or voir* front windscreen.
Page 438: Engine Oil
Engine oil To close B- Maximum level NOTE If this does not close the bonnet, release it 1. Unlatch the support bar and clip it in its The engine oil used has a significant effect on from a slightly higher position. holder.
Page 439: Engine Coolant
To add coolant Engine coolant If those conditions are unknown, contact a The cooling system is a closed system and MITSUBISHI MOTORS Authorized Serv- normally the loss of coolant should be very To check the coolant level ice Point. slight. A noticeable drop in the coolant level could indicate leakage.
Page 440: Washer Fluid
Concentrations exceeding 60 % will result in a reduction of both the anti-freeze and cool- Use “MITSUBISHI MOTORS GENUINE ing performance thus adversely affecting the SUPER LONG LIFE COOLANT PREMI- engine. UM” or equivalent*.
Page 441: Brake Fluid/Clutch Fluid
Brake fluid/Clutch fluid* To check the fluid level The fluid in the master cylinder should be NOTE checked when doing other work under the The washer fluid container serves the wind- bonnet. The brake system should also be The fluid level must be between the “MAX” screen, rear window and headlamps (if so checked for leakage at the same time.
Page 442: Battery
Battery Checking battery electrolyte Removing and installing the air CAUTION level duct Use only the specified brake fluid. Do not mix or add different brands of brake To replenish with the distilled water, remove fluid to prevent chemical reactions. Do not the air duct.
Page 443 Battery During cold weather NOTE CAUTION Loosen the nut (B), and then disconnect the Keep it out of reach of children. The capacity of the battery is reduced at low battery cable from the positive (+) terminal. Never disconnect the battery when the igni- temperatures.
Page 444: Tyres
Tyres NOTE Tyres When the vehicle is to be left unused for a WARNING long period of time, remove the battery and store it in a place where the battery fluid will Driving with tyres that are worn, dam- not freeze. The battery should be stored only aged or improperly inflated can lead to a in a fully charged condition.
Page 445 MITSUBISHI MOTORS GENUINE wheels. damage. Replace the tyres if there are deep Consult a MITSUBISHI MOTORS Author- cuts or cracks. Also check each tyre for CAUTION ized Service Point before using wheels that pieces of metal or pebbles.
Page 446 Tyres Tyre rotation When rotating tyres, check for uneven wear CAUTION and damage. Abnormal wear is usually Tyre wear varies with vehicle conditions, A temporary spare tyre can be fitted tempo- caused by incorrect tyre pressure, improper road surface conditions and individual driv- rarily in place of a tyre that has been re- wheel alignment, out of balance wheel, or se- er’s driving habits.
Page 447 After driving around for 100-300 meters, body. MOTORS GENUINE wheels should be stop and retighten the snow traction device Contact a MITSUBISHI MOTORS Author- used. Use of another type of wheel risks air (tyre chains). leaks and sensor damage, as it will not be...
Page 448: Wiper Blade Rubber Replacement
Wiper blade rubber replacement Wiper blade rubber Refer to the illustration to ensure that the CAUTION retainers are correctly aligned as you at- replacement An aluminium wheel can be damaged by a tach them. snow traction device (tyre chains) while driving.
Page 449 Wiper blade rubber replacement 5. Push the wiper blade until the hook (B) Refer to “Rear window wiper and wash- engages securely with the stopper (A). er” on page 5-68 CAUTION Do not allow the wiper arm to fall onto the Rear window wiper blade window glass;...
Page 450: General Maintenance
If you see a suspicious fuel leak or if you Hinges and latches lubrication smell fuel, do not operate the vehicle; call your MITSUBISHI MOTORS Author- ized Service Point for assistance. Check all latches and hinges, and, if necessa- ry, have them lubricated.
Page 451: Fuses
Fuses Pull the fuse lid to remove it. 1. Open the glove box. WARNING 2. Uncouple the rod (B) on the right side of Fusible links must not be replaced by any the glove box by pulling the rod to the other device.
Page 452 Fuses 4. Pull the glove box from the bottom to re- NOTE Sym- Electrical sys- move it. pacity Spare fuses are provided on the cover of fuse block in the engine compartment. Always Rear window Engine compartment 30 A use a fuse of the same capacity for replace- demister ment.
Page 453 Fuses Engine compartment fuse loca- Sym- Electrical sys- Sym- pacity Electrical system paci- tion table SRS airbag 7.5 A Electric parking brake Radio 15 A Fuse block Control unit re- Anti-lock 7.5 A braking system Interior lamps 15 A Anti-lock (Room lamps) braking system Reversing lamps...
Page 454 Fuses Some fuses may not be installed on your Sym- Sym- vehicle, depending on the vehicle model Electrical system paci- Electrical system paci- or specifications. The table above shows the main equip- Front fog Electric Parking ment corresponding to each fuse. 15 A lamps brake/Adaptive...
Page 455: Replacement Of Lamp Bulbs
Replacement of lamp bulbs Fuse replacement 4. Insert a new fuse of the same capacity by using the fuse puller into the same 1. Before replacing a fuse, always turn off place the fuse block. the electrical circuit concerned and place the ignition switch in the “LOCK”...
Page 456 Replacement of lamp bulbs CAUTION CAUTION NOTE Do not install commercially available LED Never hold the halogen lamp bulb with a When it rains or when the vehicle has been type bulbs. bare hand, dirty glove, etc. washed, the inside of the lens sometimes be- Commercially available LED type bulbs The oil from your hand could cause the bulb comes foggy.
Page 457 Reversing lamp (LHD vehicles): 16 W the bulb. Front (W16W) If you need to repair or replace these lamps, 7- Rear turn-signal lamps: 21 W (WY21W) contact a MITSUBISHI MOTORS Author- 8- Stop lamps: − ized Service Point. • Headlamps (LED type) •...
Page 458 Replacement of lamp bulbs Inside 2. While pulling the tab (B), pull out the NOTE socket (C). If you need to repair or replace these lamps, contact a MITSUBISHI MOTORS Author- ized Service Point. • LED interior illumination (Smartphone tray) •...
Page 459 Replacement of lamp bulbs NOTE After installing the cap (A), make sure that the mark (E) on the cap is pointing upward and the cap is locked in place. If the cap is not locked in place, it may become detached while the vehicle is being driven.
Page 460 Replacement of lamp bulbs *: Front of the vehicle 5. To install the bulb, perform the removal steps in reverse. NOTE When refitting the clip (D), first insert part (G) of the clip into the hole and then press part (H) into it. *: Front of the vehicle *: Front of the vehicle 4.
Page 461 Replacement of lamp bulbs Rear fog lamp (driver’s side)/ 5. Turn the bulb (H) anticlockwise to re- 2. Turn the socket (C) anticlockwise to re- move it. move it, and then pull the bulb out of the Reversing lamp (Passenger’s socket.
Page 462 Replacement of lamp bulbs 3. Turn the socket (D) anticlockwise to re- NOTE move it, and then pull the bulb out of the Fully return the splash shield (B) to its origi- socket. nal position in the rear bumper. *: Rear of the vehicle When refitting the clip (A), first insert part 2.
Page 463 The stop lamp use an LED instead of the upward angle. bulb. If you need to repair or replace the stop lamp, contact a MITSUBISHI MOTORS Authorized Service Point. 4. To install the bulb, perform the removal steps in reverse.
Page 464 Replacement of lamp bulbs Licence plate lamps 3. Remove the bulb from the socket. 1. Remove while pressing the lamp unit (A) to the left side of the vehicle. 4. To install the bulb, perform the removal steps in reverse. 2.
Page 465 Specifications Vehicle labelling................11-02 Vehicle dimensions................11-04 Vehicle performance................11-05 Vehicle weight...................11-05 Engine specifications................ 11-08 Electrical system................11-09 Tyres and wheels................11-10 Mass Emissions................. 11-11 Capacity.....................11-12 OGKE19E1...
Page 466: Vehicle Labelling
Vehicle labelling Vehicle information code plate 1- Model code Vehicle labelling 2- Engine model code 3- Transmission model code The vehicle information code plate is riveted 4- Body colour code Vehicle identification number as shown in the illustration. 5- Interior code 6- Option code The vehicle identification number is stamped 7- Exterior code...
Page 467 Vehicle labelling Engine model/number The engine model and number are stamped on the engine cylinder block as shown in the illustration. *: Front of the vehicle Specifications 11-03 OGKE19E1...
Page 468: Vehicle Dimensions
Vehicle dimensions Vehicle dimensions Front track 1,545 mm Overall width 1,805 mm Front overhang 955 mm Wheel base 2,670 mm Rear overhang 780 mm Overall length 4,405 mm Ground clearance (unladen) 183 mm Overall height (unladen) 1,685 mm Rear track 1,545 mm 11-04 Specifications...
Page 469: Vehicle Performance
Vehicle performance Minimum Body 5.7 m turning ra- Wheel 5.3 m dius Vehicle performance 200 km/h (124 mph) , 205 km/h (127 mph) Maximum speed 195 km/h (121 mph) , 200 km/h (124 mph) : Vehicles for Russia, Kazakhstan, Belarus, Ukraine and Moldova Vehicle weight Except for vehicles for Russia, Kazakhstan, Belarus, Ukraine and Moldova Vehicles with M/T...
Page 470 Vehicle weight GK1WXJJXL6/ GK1WXJXXL6/ GK1WXJSXL6/ Item GK1WXJJXR6 GK1WXJXXR6 GK1WXJSXR6 Without brake 750 kg Maximum trailer-nose weight 80 kg Maximum gross combination weight 3,650 kg Maximum permissible weight of the coupling device 25 kg Maximum roof load 50 kg Vehicles with CVT GK1WXTJXL GK1WXTXX GK1WXTSX...
Page 471 Vehicle weight GK1WXTJXL GK1WXTXX GK1WXTSX GK1WXTJXZ GK1WXTXX GK1WXTSX ZL6/ ZL6/ Item GK1WXTJX GK1WXTXX GK1WXTSX GK1WXTJXZ GK1WXTXX GK1WXTSX Maximum permissible weight of the cou- 25 kg pling device Maximum roof load 50 kg NOTE Vehicle usage condition should never exceed above “Maximum” values. Trailer specifications indicate the manufacturer’s recommendation.
Page 472: Engine Specifications
Engine specifications Item GK1WXJMUL GK1WXJHUL GK1WXTMUL GK1WXTHUL GK1WXTMUZ GK1WXTHUZ With brake 1,600 kg Maximum towa- ble weight Without brake 750 kg Maximum trailer-nose weight 80 kg Maximum gross combination 3,650 kg 3,700 kg weight Maximum permissible weight of 25 kg the coupling device Maximum roof load 50 kg...
Page 473: Electrical System
Electrical system Bore 75.0 mm Stroke 84.8 mm Camshaft Double overhead Mixture preparation Electronic injection Maximum output (ECC net) 120 kW/5,500 rpm 110 kW/5,500 rpm Maximum torque (ECC net) 250 N•m/2,400 to 4,500 rpm 250 N•m/2,000 to 3,500 rpm : Vehicles for Russia, Kazakhstan, Belarus, Ukraine and Moldova Electrical system Except for vehicles for Russia, Kazakh- Vehicles for Russia, Kazakhstan, Bela-...
Page 474: Tyres And Wheels
18x7J Offset 38 mm NOTE When replacing the tyres or wheels, refer to “Replacing tyres and wheels ” on page 10-11. Contact your MITSUBISHI MOTORS Authorized Service Point for details on the combination used on your vehicle. 11-10 Specifications OGKE19E1...
Page 475: Co 2 Mass Emissions
Mass Emissions Mass Emissions Combined (g/km) Item NEDC WLTC GK1WXJJXL6/GK1WXJJXR6/ GK1WXJXXL6/GK1WXJXXR6 GK1WXJSXL6/GK1WXJSXR6 GK1WXTJXL6/GK1WXTJXR6/ GK1WXTXXL6/GK1WXTXXR6 GK1WXTSXL6/GK1WXTSXR6 GK1WXTJXZL6/GK1WXTJXZR6/ GK1WXTXXZL6/GK1WXTXXZR6 GK1WXTSXZL6/GK1WXTSXZR6 : New European Driving Cycle : Worldwide harmonized Light vehicles Test Cycle NOTE The results given do not express or imply any guarantee of the CO mass emissions of the particular vehicle.
Page 476: Capacity
Capacity Capacity Item Quantity Lubricants Engine oil Refer to page 10-04. Oil pan 4.0 litres Oil filter 0.2 litre Oil cooler 0.1 litre As required Brake fluid DOT3 or DOT4 Brake fluid Clutch fluid Washer fluid 4.3 litres — : Similar high quality ethylene glycol based non-silicate, non-amine, non-nitrate and non-borate coolant with long life hybrid organic acid tech- nology 11-12 Specifications...
Page 477 : Similar high quality ethylene glycol based non-silicate, non-amine, non-nitrate and non-borate coolant with long life hybrid organic acid tech- nology CAUTION Use only the MITSUBISHI MOTORS GENUINE CVTF-J4. Use of a different fluid could damage the transmission. Item Quantity...
Page 478 OGKE19E1...
Page 479 Alphabetical index Audio CD player............7-22 LW/MW/FM radio........7-22 4-wheel drive operation........6-41 Capacities............11-12 Troubleshooting..........7-54 Auto Stop & Go (AS&G) system......6-25 Card holder........7-78,7-79,7-84 Automatic air conditioning........7-05 Cargo area cover..........7-85 Automatic High-Beam (AHB)......5-56 Cargo loads............6-126 Accessory (Installation)........2-10 Automatic transmission Catalytic converter..........
Page 480 Alphabetical index Coat hook............7-87 Electronic immobilizer (Anti-theft Front room lamp starting system)..........3-03 Combination headlamps and dipper switch..5-53 Bulb capacity and location......10-24 Emergency key..........3-15 Front seats............4-02 Coolant (engine)........10-05,11-12 Emergency starting..........8-08 Front turn-signal lamps Cruise control............ 6-57 Emergency stop signal system......
Page 481 Alphabetical index Headlamp flasher.......... 5-55 Replacement..........10-24 Switch............5-53 Heated mirror............ 6-13 Key number tag..........3-02 Making a luggage area........4-07 Heated seats............4-04 Keyless entry system.........3-04 Manual transmission......... 6-30 Heated steering wheel switch......5-71 Keyless operation system........3-08 Manual transmission oil........11-12 Heated windscreen switch.........5-70 Emergency key..........3-15 Map lamps............
Page 482 Alphabetical index Bulb capacity and location......10-22 Replacement..........10-29 Specifications..........11-02 Power panoramic sunroof........3-32 Roof carrier precaution........6-126 Speed Limiter............ 6-62 Precautions to observe when using Room lamps............7-81 Starting and stopping the engine....... 6-19 wipers and washers.......... 5-69 Running-in recommendations......6-03 Steering Pregnant women restraint........4-14 Steering wheel height adjustment....
Page 483 Alphabetical index Manual transmission........6-30 Vehicle labeling..........11-02 Turbocharger operation........6-25 Vehicle performance........11-05 Turn-signal indication lamps......5-44 Vehicle weight..........11-05 Turn/Lane-change signals......... 5-62 Ventilators............7-02 Tyre pressure monitoring system (TPMS)..6-105 Tyre repair kit............ 8-13 Tyres..............10-10 Warning lamps...........5-45 How to change a tyre........8-19 Washer Inflation pressures........
Page 484 OGKE19E1...
Page 485 Declaration of Conformity 13- 1 OGKE19E1...
Page 486 Declaration of Conformity 13- 2 OGKE19E1...
Page 487 Declaration of Conformity 13- 3 OGKE19E1...
Page 488 Declaration of Conformity 13- 4 OGKE19E1...
Page 489 Declaration of Conformity 13- 5 OGKE19E1...
Page 490 Declaration of Conformity 13- 6 OGKE19E1...
Page 491 Declaration of Conformity 13- 7 OGKE19E1...
Page 492 Declaration of Conformity 13- 8 OGKE19E1...
Page 493 Declaration of Conformity 13- 9 OGKE19E1...
Page 494 Declaration of Conformity 13- 10 OGKE19E1...
Page 495 Declaration of Conformity 13- 11 OGKE19E1...
Page 496 Declaration of Conformity 13- 12 OGKE19E1...
Page 497 Declaration of Conformity 13- 13 OGKE19E1...
Page 498 Declaration of Conformity 13- 14 OGKE19E1...
Page 499 Declaration of Conformity 13- 15 OGKE19E1...
Page 500 Declaration of Conformity 13- 16 OGKE19E1...
Page 501 Declaration of Conformity 13- 17 OGKE19E1...
Page 502 Declaration of Conformity 13- 18 OGKE19E1...
Page 503 Declaration of Conformity 13- 19 OGKE19E1...
Page 504 Declaration of Conformity 13- 20 OGKE19E1...
Page 505 Declaration of Conformity 13- 21 OGKE19E1...
Page 506 Declaration of Conformity 13- 22 OGKE19E1...
Page 507 Declaration of Conformity 13- 23 OGKE19E1...
Page 508 Declaration of Conformity 13- 24 OGKE19E1...
Page 509 Declaration of Conformity 13- 25 OGKE19E1...
Page 510 Declaration of Conformity 13- 26 OGKE19E1...
Page 511 Declaration of Conformity 13- 27 OGKE19E1...
Page 512 Declaration of Conformity 13- 28 OGKE19E1...
Page 513 Declaration of Conformity 13- 29 OGKE19E1...
Page 514 Declaration of Conformity 13- 30 OGKE19E1...
Page 515 Declaration of Conformity 13- 31 OGKE19E1...
Page 516 Declaration of Conformity 13- 32 OGKE19E1...
Page 517 Declaration of Conformity 13- 33 OGKE19E1...
Page 518 Declaration of Conformity 13- 34 OGKE19E1...
Page 519 Declaration of Conformity 13- 35 OGKE19E1...
Page 520 Declaration of Conformity 13- 36 OGKE19E1...
Page 521 Declaration of Conformity 13- 37 OGKE19E1...
Page 522 Declaration of Conformity 13- 38 OGKE19E1...
Page 523 Declaration of Conformity 13- 39 OGKE19E1...
Page 524 Declaration of Conformity 13- 40 OGKE19E1...
Page 525 Declaration of Conformity 13- 41 OGKE19E1...
Page 526 Declaration of Conformity 13- 42 OGKE19E1...
Page 527 Declaration of Conformity 13- 43 OGKE19E1...
Page 528 Declaration of Conformity 13- 44 OGKE19E1...
Page 529 Declaration of Conformity 13- 45 OGKE19E1...
Page 530 Declaration of Conformity 13- 46 OGKE19E1...
Page 531 Declaration of Conformity 13- 47 OGKE19E1...
Page 532 Declaration of Conformity 13- 48 OGKE19E1...
Page 533 Declaration of Conformity 13- 49 OGKE19E1...
Page 534 Declaration of Conformity 13- 50 OGKE19E1...
Page 535 Declaration of Conformity 13- 51 OGKE19E1...
Page 536 Declaration of Conformity 13- 52 OGKE19E1...
Page 537 Declaration of Conformity 13- 53 OGKE19E1...
Page 538 Declaration of Conformity 13- 54 OGKE19E1...
Page 539 Declaration of Conformity 13- 55 OGKE19E1...
Page 540 Declaration of Conformity 13- 56 OGKE19E1...
Page 541 Declaration of Conformity 13- 57 OGKE19E1...
Page 542 Declaration of Conformity 13- 58 OGKE19E1...
Page 543 Declaration of Conformity 13- 59 OGKE19E1...
Page 544 Declaration of Conformity 13- 60 OGKE19E1...
Page 545 Declaration of Conformity 13- 61 OGKE19E1...
Page 546 Declaration of Conformity 13- 62 OGKE19E1...
Page 547 Declaration of Conformity 13- 63 OGKE19E1...
Page 548 Declaration of Conformity 13- 64 OGKE19E1...
Page 549 Declaration of Conformity 13- 65 OGKE19E1...
Page 550 Declaration of Conformity 13- 66 OGKE19E1...
Page 551 Declaration of Conformity 13- 67 OGKE19E1...
Page 552 Declaration of Conformity 13- 68 OGKE19E1...
Page 553 Declaration of Conformity 13- 69 OGKE19E1...
Page 554 Declaration of Conformity 13- 70 OGKE19E1...
Page 555 Declaration of Conformity 13- 71 OGKE19E1...
Page 556 Declaration of Conformity 13- 72 OGKE19E1...
Page 557 Declaration of Conformity 13- 73 OGKE19E1...
Page 558 Declaration of Conformity 13- 74 OGKE19E1...
Page 559 Declaration of Conformity 13- 75 OGKE19E1...
Page 560 Declaration of Conformity 13- 76 OGKE19E1...
Page 561 Declaration of Conformity 13- 77 OGKE19E1...
Page 562 Declaration of Conformity 13- 78 OGKE19E1...
Page 563 Declaration of Conformity 13- 79 OGKE19E1...
Page 564 Declaration of Conformity 13- 80 OGKE19E1...
Page 565 Declaration of Conformity 13- 81 OGKE19E1...
Page 566 Declaration of Conformity 13- 82 OGKE19E1...
Page 567 Declaration of Conformity 13- 83 OGKE19E1...
Page 568 OGKE19E1...
Page 569 OGKE19E1...
Page 570 OGKE19E1...

Save PDF
