Summary of Contents for Vista VK2-4KXDECODER

  • Page 1 VK2-4KXDECODER User manual...
  • Page 2 Please read this manual thoroughly before use and keep it handy for future reference.
  • Page 3: Table Of Contents

    Contents Overview ..............................8 Package Contents ......................... 8 Decoder Description ........................8 Installation ............................. 10 Starting System .......................... 10 Quick Setup ..........................11 2.2.1 Account ..........................11 2.2.2 System..........................11 2.2.3 Network ..........................12 2.2.4 Time/Date .......................... 12 2.2.5 Easy Installation Wizard....................... 13 Live Screen Configuration ........................
  • Page 4 Before You Begin Read these instructions before installing or operating this product. Note: This installation should be made by a qualified service person and should conform to local codes. This manual provides installation and operation information. To use this document, you must have the following minimum qualifications: ...
  • Page 5 This apparatus is manufactured to comply with the radio interference. A Declaration of Conformity in accordance with the following EU standards has been made. The manufacturer declares that the product supplied with this document is compliant the provisions of the EMC Directive 2004/108/EC, the CE Marking Directive 93/68 EEC and all associated amendments.
  • Page 6 IMPORTANT SAFEGUARDS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. 8.
  • Page 7 CE COMPLIANCE STATEMENT WARNING This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
  • Page 8: Overview

    Overview Package Contents The device package contents consist of the following: Note Please check all components involved. Table 1-1 Package contents 번호 Name Name Decoder Mounting Bracket DC 12V Adaptor Bracket fixing screws Quick guide Program CD Decoder Description Each part is listed in the below: Figure 1-1 Name and Connection of each front section Table 1-2 Name and Function of each front section Name...
  • Page 9 Figure 1-2 Name and Connection of rear section Table 1-3 Name and Function of rear section Name Function NETWORK Network connection AUDIO OUT Audio output port. CVBS CVBS (Spot Video) output port. HDMI HDMI output port. ALARM OUT Alarm output connector. DC12V Power supply connector.
  • Page 10: Installation

    Installation You can fix the product on the wall using the supplied bracket. Refer to the drawing below for the hole position of the bracket. Figure 2-1 Dimension Starting System On power up the following icons will appear sequentially: 1 Switching on initialize with below icons in order. 2 When the buzzer sounds, the start screen will be presented.
  • Page 11: Quick Setup

    Quick Setup 2.2.1 Account 4 Set ID and Password. ▪ Default ID/Password is admin/admin. Note ▪ Change the password for security. 2.2.2 System 5 Set each item in System menu. Language: Select system language.  Device Name: Enter the device name. ...
  • Page 12: Network

    2.2.3 Network 8 Set each item in Network setting screen. WAN Port: Select whether to use static IP or dynamic IP.  IP Address, Subnet Mask, Gateway, DNS, Port, and RTSP port server: As for dynamic IP, enter  information in each space. 9 Press Save button to save set value.
  • Page 13: Easy Installation Wizard

    2.2.5 Easy Installation Wizard 14 Tick the “Use” box, if you want the wizard to run on every power up, it is recommended to leave this un-ticked 15 Press Save button to save set value and exit the Easy Installation menus.
  • Page 14: Live Screen Configuration

    Live Screen Configuration Explanation of User Interface screen. Figure 3-1 UI Screen Configuration Table 3-1 Items and Description of UI Screen Configuration Item Description Live screen Show live video of connected cameras. Quick menu Clicking the right button on the mouse displays Quick menu. See “3.4 Quick Menu”...
  • Page 15: Quick Menu

    Quick menu This chapter explains the Quick menu which is displayed on a right click of the mouse. Figure 3-2 Quick menu Table 3-2 Quick menu Item and Description Item Description Screen Mode Selecting the partition mode of live screen (Full, 2X2, 1+7, 3X3, 2+8, 4x4, PIP and Save Sequence).
  • Page 16: Channel Assign

    3.2.1 Channel Assign Cameras / Video files can be dragged to screen segments from the Channel Assign menu Figure 3-3 Channel Assign Table 3-3 Camera Registration Item Description Reload the list. Local Display registered image list. Display media file list. Displayed registered device list.
  • Page 17: Setup Menu

    Setup menu This chapter describes the main Setup menu, accessed from the Quick menu Figure 4-1 Setup menu Selecting the menu opens the setting screen. Table 4-1 Setup menu Item and Description Item Description SYSTEM Main system settings CAMERA Camera Settings DEVICE Peripheral device settings NETWORK...
  • Page 18: Main Standard Buttons In Setup Menu

    Main standard buttons in Setup menu Table 4-3 Item and Description of standard buttons in Setup menu Item Description Default Reverse changed settings to default factory settings. Save Save the set content. Cancel Cancel the set value. Restore Cancel the set value, and reverse it to default. Apply Apply the content set.
  • Page 19: System

    SYSTEM 4.2.1 System Set and upgrade the basic items of the system. System > System Set the basic items in the System. Table 4-4 SYSTEM > System > System Item and Description Name Function Language Set the system language. Device Name Enter the device name (Only English is possible).
  • Page 20 System > F/W Upgrade Table 4-5 SYSTEM > System > F/W Upgrade Item and Description Name Function Current Version Displaying the present tool version. Device Connect USB memory that has files to upgrade to the USB port, select files to upgrade. Upgrade button Run upgrade.
  • Page 21: Time/Date

    4.2.2 Time/Date Time/Date > Time/Date Set the date, time, and holidays of the system. Table 4-6 SYSTEM > Time/Date > Time/Date Item and Description Name Function System Time Set the date and time. ▪ DST: Select whether to use summer time. ▪...
  • Page 22: Account > User

    4.2.3 Account > User Set the user’s account details. Table 4-7 SYSTEM > Account > User Item and Description Name Function Add Group Add users’ group. Add User Add users to a specified group. Group List Display a total group list. User List Display user lists across groups.
  • Page 23 Press Add Group button, then Add Group screen displays. Table 4-8 SYSTEM > Account > User > Add Group Item and Description Name Function Name Enter the group name. PERMISSION Select the functions that can be accessed by this group Select channels that can be accessed by this group.
  • Page 24: Configuration (Config)

    4.2.4 Configuration (Config) Config > Export/Import The system settings can be saved and then up-loaded into another device. Table 4-10 SYSTEM > Config > Export/Import Item and Description Name Function Device Select an exterior connector with USB. ▪ USB: Displays the USB device connected. ▪...
  • Page 25 Config > Factory Default Default the setting value of the device. Table 4-11 SYSTEM > Config > Factory Default Item and Description Name Function Select All Select/deselect all items to be defaulted. /Unselect All Default Item Select/deselect related items to be defaulted. (System, Device, Network) Default button Default the system to the factory settings...
  • Page 26: Camera

    CAMERA 4.3.1 Channel Channel > Basic Set the basic items of camera per channel. Table 4-12 CAMERA > Channel > Basic Item and Description Name Function Display the channel name. Title Edit the camera name by click on the keyboard icon, then using the on screen keyboard.
  • Page 27: Device

    DEVICE 4.4.1 Display Settings related to a display device and live screen. Display > Display Set the display device. Table 4-13 DEVICE > Display > Display Item and Description Name Function HDMI Select the resolution of the display device (1920x1080, 3840x2160). Display Stream Set stream mode (Auto, Sub stream only).
  • Page 28 Display > OSD Set the OSD of the display device. Figure 4-2 DEVICE > Display > OSD Table 4-14 DEVICE > Display > OSD Item and Description Name Function Camera Name Select the way to display camera / channel information on the live screen (Off, CH+Title, CH, DevName, CH+DevName).
  • Page 29: Serial Device > Serial Device

    4.4.2 Serial Device > Serial Device Used to set up remote keyboards or RS485 PTZ telemetry protcols. Table 4-15 DEVICE > Serial Device > Serial Device Item and Description Name Function USB (to Serial) Set communication transmission value of USB device. RS-485 Set communication transmission value of RS-485 connector.
  • Page 30: Network

    NETWORK 4.5.1 Basic > WAN Port Basic > WAN Port To set the network WAN port Table 4-16 NETWORK > Basic > WAN Port Item and Description Name Function Static IP Check if you use static IP. For using static IP, enter IP address, Subnet Mask, and Gateway.
  • Page 31: Displaying Media Files

    Displaying Media files The VK2-4KXDECODER can display media files for advertising or information as either full screen or in smaller segments of a split screen view. Notes: 1. The smallest segment size for media display is quarter of the screen.
  • Page 32: Adding Media File To The Decoder

    Adding Media file to the Decoder The media file can be stored on either a USB pen or a Micro SD memory card. Insert the USB pen (1) or SD card (2) into the Decoder With in the Channel Assign menu page the media files available will be displayed with in the AVI section of the drop-down menu on the left of the screen.
  • Page 33: Product Specfication

    Product Specfication Model Decoder VIDEO Video Input 16ch Video Input Resolution Up to 8MP Compression H.264, H.265 Media File Play Max. 4ch Display Output 1 HDMI, 1 BNC(CVBS) HDMI: 3840x2160, 1920x1080 Display Resolution CVBS: NTSC/PAL Display Speed HDMI: 400/480fps, CVBS: 25/30fps(PAL/NTSC) Display Mode HDMI: 1/4/8/9/10/16 CVBS: 1 NETWORK...
