Related Manuals for Vista VIPER-HDAENC16

Summary of Contents for Vista VIPER-HDAENC16

  • Page 1 User Manual VIPER-HDAENC16 16 Chn Encoder Analogue to IP converter...
  • Page 2 Please read this manual thoroughly before use and keep it handy for future reference.
  • Page 3 Before You Begin Read these instructions before installing or operating this product. Note: This installation should be made by a qualified service person and should conform to local codes. This manual provides installation and operation information. To use this document, you must have the following minimum qualifications: A basic knowledge of CCTV systems and components A basic knowledge of electrical wiring and low-voltage electrical connections...
  • Page 4 The manufacturer declares that the product supplied with this document is compliant the provisions of the EMC Directive 2004/108/EC, the CE Marking Directive 93/68 EEC and all associated amendments. All lead-free products offered by the company comply with the requirements of the Eu- ropean law on the Restriction of Hazardous Substances (RoHS) directive: 2011/65/EU, which means our manufacture processes and products are strictly “lead-free”...
  • Page 5 IMPORTANT SAFEGUARDS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. 8.

  • Page 6: Table Of Contents

    Table of Contents Table of Contents ..........................12 Overview Connections Package Contents ........................15 Encoder Description ......................15 Installation Connecting with Exterior Device ....................18 Starting System ........................20 Quick Setup ..........................21 3.4.1 Account........................21 3.4.2 System ........................22 3.4.3 Network ........................
  • Page 7 5.3.1 Basic .......................... 44 5.3.2 Advanced ........................46 DEVICE ........................... 49 5.4.1 Display ........................49 5.4.2 PTZ > PTZ ......................... 53 5.4.3 Serial Device > Serial Device ..................54 STREAM ..........................55 5.5.1 Stream ........................55 EVENT ............................ 57 5.7.1 System ........................

  • Page 8: Overview

    Overview This manual describes the installation, Set-up and Use of the VIPERHDAENC16 16ch HD Analogue to IP Encoder. Users can monitor HD analog cameras through network and also can be monitored by local HDMI moni- tor. The device features include the following: Convenient UI from user’s viewpoint Composite input port for 16 channels Providing AHD, TVI, 960H, and D1...

  • Page 9: Connections

    Connections Package Contents The device package contents consist of the following: Note Please check all components involved. Table 2-1 Package contents Name Name Encoder Quick guide DC Power Adapter Program CD Encoder Description Each part is listed in the below: Figure 2-1 Name and Connection of each front section Table 2-2 Name and Function of each front section Name...
  • Page 10 Figure 2-2 Name and Connection of each rear section Table 2-3 Name and Function of each rear section Name Function Audio In Camera audio input port. Video In Camera video input port. CVBS CVBS output port. VGA output port. HDMI HDMI output port.

  • Page 11: Installation

    Installation This chapter describes the installation of the Encoder Use the diagram below to help connect external devices Figure 2-3 Connection map Set up Sequence 1 Connect exterior device 2 Power up the Encoder 3 Use the Quick setup wizard for basic setting...

  • Page 12: Connecting With Exterior Device

    Connecting with Exterior Device How to connect each port to rear section of the unit: 1 Place the unit in a stable flat surface. 2 Make a room between front/rear sides of the device to avoid damaging connectors. Do NOT install the device too close to the wall. Protruding connectors on the Warning rear of the unit may be damaged if there is not enough space.
  • Page 13 9 Connect USB port in front section of the unit with a mouse. 10 Connect the 12VDC Power supply Note No power button; supplying power automatically starts the unit.

  • Page 14: Starting System

    Starting System On power up 1 The following test icons will appear in order 2 On completion of a buzzer sounds, the following screen is presented. 3 In Log in screen, enter the ID, Password and press OK. Default ID & Password is admin/admin. Click to see the MAC address.

  • Page 15: Quick Setup

    Quick Setup On boot up the quick start guide will appear, this allow the setup of the following basic items: 1 Account 2 System 3 Network 4 Time/Date 3.4.1 Account How to set Account of Easy Installation: 1 Click the keyboard icon to set ID and Password users want. 2 With keyboard UI, set the ID and Password, and press OK.

  • Page 16: System

    3.4.2 System 1 Set each item in System setting screen. System Mode: Select input video type(Analog Only or Analog+IP cam)  Language: Select system language.  Device Name: Enter the device name.  Keyboard ID: To identify device usages in controlling Encoder with RS485 through a keyboard ...

  • Page 17: Time/Date

    3.4.4 Time/Date 1 Set each item in Time/Date setting screen. Network Time Sync: Select network for synchronizing with time server.  System Time: Not for synchronizing with network time server, set the device time; otherwise (ap-  plying for Daylight saving time), select DST. Time Zone: Select time zone for the system being installed.

  • Page 18: Live Screen Configuration

    Live Screen Configuration Figure 4-1 UI Screen Configuration Table 4-1 Items and Description of UI Screen Configuration Item Description Setup menu Set up menu heading will appear when the mouse is moved to the top of the screen, when logged in at Administrator level. Live screen Show live video of connected cameras.

  • Page 19: Icons In Live Screen

    Icons in Live screen Each icon in the live screen displays a present setting status or a function. UI screen consists of like be- low. Chosen live screen is marked as a blue frame; mouse-located live screen is marked Note as yellow one.

  • Page 20: Live Launcher Menu

    Live Launcher menu Figure 4-3 Launcher menu Table 4-3 Launcher menu Item and Description Item Description Log in/out status and logged in ID. Date & Time Displaying present date and time. Moving to previous/next partition screen. Displaying live screen in order set (toggle). Selecting partition mode to mark in live screen (single screen, 4-, 9-, and 16- partition).

  • Page 21: Quick Menu

    Quick menu Right click on the screen to display the Quick menu as below: Figure 4-4 Quick menu Table 4-4 Quick menu Item and Description Item Description Screen Mode Selecting the partition mode of live screen (Full, 2X2, 3X3, and 4x4). Zoom in Magnifying selected live screen (Zoom out, 2 times, 4 times, and 8 times).

  • Page 22: Ptz Control

    4.3.1 PTZ Control The location of images may be moved to monitor with PTZ ball. PTZ Control menu can be displayed if relevant channel’s protocol is set in DEVICE > Note PTZ in the upper live screen. Figure 4-5 Quick menu > PTZ Control Table 4-5 Quick menu >...

  • Page 23: Camera Registration

    In PTZ Control screen, clicking the right button of the mouse displays Quick menu. Figure 4-6 PTZ Control Quick menu Table 4-6 PTZ Control Item and Description in Quick menu Item Description Preset, Tour, Run PTZ functions. Scan, Pattern Exit Transforming to live screen menu in PTZ Control menu.
  • Page 24 Table 4-7 Camera Registration Item Description Search the connected IP cameras. Auto Assign Automatically assign the channel windows. Port Show the detected camera port. Assign Selecting the channel windows manually. Model Show detected camera model number. Show detected camera IP address. Status Show connection status.

  • Page 25: Status > Event

    Item Description Mode Select video stream format (RTSP/HTTP). 4.3.3 Status > Event Users can see the real-time event information of the unit in Event tap in Status screen. Figure 4-9 Status > Event in Quick menu Table 4-9 Status > Event Item and Description in Quick menu Item Description Temporary fixing or releasing an event list (toggle).

  • Page 26: Status > Stream

    4.3.4 Status > Stream Users can see the stream status in Stream tap in Status screen. Figure 4-10 Status > Stream in Quick menu Table 4-10 Status > Stream Item and Description in Quick menu Item Description Input Type Displaying the input video type. Main Stream Displaying the main stream status.

  • Page 27: Setup Menu

    Setup menu This chapter describes Setup menu in the upper side of the screen. Figure 5-1 Setup menu Selecting the menu opens the setting screen. Setup screen is available to click Setup in Quick menu by clicking the right button Note of the mouse.
  • Page 28 Table 5-2 Setup menu tree 1 Depth 2 Depth 3 Depth System System F/W Upgrade Time/Date Time/Date Holiday SYSTEM Account User Export/Import Configuration Factory Default Basic Basic Audio In/Out CAMERA Scan Mode Advanced Advanced Display Spot Display DEVICE Sequence Serial Device Serial Device Main Stream STREAM...

  • Page 29: General Buttons In Setup Menu

    General buttons in Setup menu This section depicts General buttons in Setup menu. Figure 5-2 General buttons in Setup menu Table 5-3 Item and Description of General buttons in Setup menu Item Description Default Reverse changed setting value to default in factory. Save Save the set content.

  • Page 30: System

    SYSTEM In SYSTEM, basic system environment is set. 5.2.1 System Set and upgrade the basic items of the system. System > System Set the basic items in the System. Figure 5-3 SYSTEM > System > System Table 5-4 SYSTEM > System > System Item and Description Name Function Language...
  • Page 31 System > F/W Upgrade Set the upgraded items of the system. Figure 5-4 SYSTEM > System > F/W Upgrade Table 5-5 SYSTEM > System > F/W Upgrade Item and Description Name Function Current Version Displaying the present tool version. Device Connect USB memory that has files to upgrade to the USB port, select files to upgrade.

  • Page 32: Time/Date

    5.2.2 Time/Date Set the date, time, and holidays of the system. Time/Date > Time/Date Set the date, time, and holidays of the system. Figure 5-5 SYSTEM > Time/Date > Time/Date Table 5-6 SYSTEM > Time/Date > Time/Date Item and Description Name Function System Time...
  • Page 33 Time/Date > Holiday Set holidays of the system. Figure 5-6 SYSTEM > Time/Date > Holiday Table 5-7 SYSTEM > Time/Date > Holiday Item and Description Name Function Year Select years to set holidays. Delete selected holidays. Add Holiday Add holidays. List Display added holiday lists.

  • Page 34: Account > User

    Name Function Type Select the holiday types. e.g.,) Selecting Relative and 1, first, and Sun, which designates annual January of the 1 Sunday as a holiday. Calendar Select the holiday to add. 5.2.3 Account > User Set the user’s account of the system. Figure 5-8 SYSTEM >...
  • Page 35 Press Add Group button, then Add Group screen displays. Figure 5-9 SYSTEM > Account > User > Add Group Table 5-10 SYSTEM > Account > User > Add Group Item and Description Name Function Name Enter the group name. PERMISSION Select items to permit access.

  • Page 36: Configuration (Config)

    5.2.4 Configuration (Config) Set Export/Import and Factory Default of the system. Config > Export/Import Through a save medium, users may apply information set to other devices identically. Figure 5-11 SYSTEM > Config > Export/Import Table 5-12 SYSTEM > Config > Export/Import Item and Description Name Function Device...
  • Page 37 Config > Factory Default Default the setting value of the device. Figure 5-12 SYSTEM > Config > Factory Default Table 5-13 SYSTEM > Config > Factory Default Item and Description Name Function Select All Select/deselect all items to be defaulted. /Unselect All Default Item Select/deselect related items to be defaulted.

  • Page 38: Camera

    CAMERA In CAMERA section, set the camera to be connected with the device. 5.3.1 Basic Set the fundamental functions of camera and audio. Basic > Basic Set the basic items of camera by channels. Figure 5-13 CAMERA > Basic > Basic Table 5-14 CAMERA >...
  • Page 39 Press Copy Covert Setup button, then Copy Covert Setup screen displays. Figure 5-14 CAMERA > Basic > Basic > Copy Covert Setup Table 5-15 CAMERA > Basic > Basic > Copy Covert Setup Item and Description Name Function From Select a channel converted setting. Select a channel to be copied.

  • Page 40: Advanced

    Table 5-16 CAMERA > Basic > Audio In Item and Description Name Function Display channels of audio Select/deselect whether to use audio. Assign Select channels to be assigned audio. 5.3.2 Advanced Set camera video, stream and privacy mask. Advanced > Scan Mode Figure 5-16 CAMERA >...
  • Page 41 Advanced > Advanced Figure 5-17 CAMERA > Advanced > Advanced Table 5-18 CAMERA > Advanced > Advanced Item and Description Name Function Display channels. Video Set brightness, contrast, and color of the camera. Privacy Mask Set the privacy field; display field numbers set in parenthesis (at most 4 setting available).
  • Page 42 Locate the mouse in the Privacy Mask field, and then click Editing Icon ( ) in the right corner, then Privacy Mask screen displays. Figure 5-18 CAMERA > Advanced > Privacy Mask Table 5-19 CAMERA > Advanced > Privacy Mask Item and Description Name Function Select channels to set privacy field.

  • Page 43: Device

    DEVICE In DEVICE, set the device to connect with the unit. 5.4.1 Display Set matters related to a display device and live screen. Display > Display Set the display device. Figure 5-19 DEVICE > Display > Display Table 5-20 DEVICE > Display > Display Item and Description Name Function HDMI/VGA...
  • Page 44 Display > Spot Set the Spot output. Figure 5-20 DEVICE > Display > Spot Table 5-21 DEVICE > Display > Spot Item and Description Name Function Sequence Set the channel and dwell time (5, 10, 20, 30sec) when the Auto mode of Spot Monitor is selected.
  • Page 45 Display > OSD Set the OSD of the display device. Figure 5-21 DEVICE > Display > OSD Table 5-22 DEVICE > Display > OSD Item and Description Name Function Camera Name Select the way to display camera in live screen (Off, CH+Title, CH). Live Bar Select the way to display the live bar (Always On, Auto Hide).
  • Page 46 Display > Sequence Set the play sequence of live screen. Figure 5-22 DEVICE > Display > Sequence Table 5-23 DEVICE > Display > Sequence Item and Description Name Function Quad Sequence Set to convert automatically as 4-partition screen on the time basis. Division Select screen partition mode to be marked in the below table (Full and Quad).

  • Page 47: Ptz > Ptz

    Clicking Add Sequence displays Add Sequence screen. Figure 5-23 DEVICE > Display > Sequence > Add Sequence Table 5-24 DEVICE > Display > Sequence > Add Sequence Item and Description Name Function Dwell Time Select time to play (3 sec, 5 sec, 10 sec, 15 sec, and 30 sec). Division Select the partition screen to play (Full, Quad).

  • Page 48: Serial Device > Serial Device

    Table 5-25 DEVICE > PTZ > PTZ Item and Description Name Function Copy PTZ Setup Apply setting history to all or selected channels in the same way. Display channels. Select camera ID connected to relevant channels (1-255). Protocol Select protocol of camera connected to relevant channels. Speed Select pan-tilt of camera connected to relevant channels (1-5).

  • Page 49: Stream

    STREAM In STREAM, users may set main and sub stream. 5.5.1 Stream Stream > Main Stream Set the resolution, framerate, and image quality of the main Stream. Figure 5-26 Stream > Stream > Main Stream Table 5-27 Stream > Stream > Main Stream Item and Description Name Function Display channels.
  • Page 50 Stream > Sub Stream Set the resolution, framerate, and image quality of the sub Stream. Figure 5-27 Stream > Stream > Main Stream Table 5-28 Stream > Stream > Main Stream Item and Description Name Function Display channels. Resolution Set the resolution of video clips (1080P, 720P, and 960H). Framerate Select stream FPS (1-30).

  • Page 51: Event

    EVENT In EVENT, users may set each event of the device. 5.7.1 System System > System Set the system event of the device. Figure 5-28 Event > System > System Table 5-29 Event > System > System Item and Description Name Function System Restart...

  • Page 52: Alarm In

    5.7.2 Alarm In Set the sensor alarms and schedule. Alarm In > Setup Set the sensor alarms. Figure 5-29 Event > Alarm In > Setup Table 5-30 Event > Alarm In > Setup Item and Description Name Function Sensor Display sensor numbers. Select/deselect whether to use alarm in the sensor.
  • Page 53 Placing your mouse on Alarm, Group Rec, Noti., Preset and clicking editing Icon( ) in right corner displays Event : Alarm screen. Figure 5-30 Event > Alarm In > Setup > Event : Alarm Table 5-31 Event > Alarm In > Setup > Event : Alarm Item and Description Name Function Alarm-out...
  • Page 54 Alarm In > Schedule Schedule the event streaming time when alarm occurs across device sensors. Figure 5-31 Event > Alarm In > Schedule Table 5-32 Event > Alarm In > Schedule Item and Description Name Function Sensor Select the sensor to set the schedule. Schedule Type Select the types of schedules.

  • Page 55: Motion

    5.7.3 Motion Set and schedule the motions across channels. Motion > Setup Set the motions across channels. Figure 5-32 Event > Motion > Setup Table 5-33 Event > Motion > Setup Item and Description Name Function Display channels. Select/deselect whether to use motion function in the channel. Area Display the motion area.
  • Page 56 Figure 5-33 Event > Motion > Schedule Table 5-34 Event > Motion > Schedule Item and Description Name Function Select channels to set schedules. Schedule Type Select the types of schedules. Selection Schedule Table Display the schedule users set. Drag Field Display the area dragged with a mouse.

  • Page 57: Video Loss > Setup

    5.7.4 Video Loss > Setup Set the video loss across channels. Figure 5-34 Event > Video Loss > Setup Table 5-35 Event > Video Loss > Setup Item and Description Name Function Display channels. Select/deselect whether to use Video Loss in the channel. Beep Select use time of buzzer sound (null, 5 sec, 10 sec, 20 sec, 30 sec, 1 min, 10 min, 30 min, and 1 hour).

  • Page 58: Notification

    5.7.5 Notification Set and schedule periodical alarms. Notification > Periodic Set the periodical alarms. Figure 5-35 EVENT > Notification > Periodic Table 5-36 EVENT > Notification > Periodic Item and Description Name Function Periodic Notifica- Select/deselect whether to use periodical alarms tion Summary Send the event information.
  • Page 59 Notification > Schedule Schedule remote notification(alarm & motion). Figure 5-36 EVENT > Notification > Schedule Table 5-37 EVENT > Notification > Schedule Item and Description Name Function Schedule Type Select the types of schedules. Selection Schedule Table Display the schedule users set. Drag Field Display the area dragged with a mouse.

  • Page 60: Network

    NETWORK In NETWORK, users may set the network environment. 5.8.1 Basic > WAN Port Set the network environment. Figure 5-37 NETWORK > Basic > WAN Port Table 5-38 NETWORK > Basic > WAN Port Item and Description Name Function Static IP Check if you use static IP.

  • Page 61: Dvrns/Ddns

    5.8.2 DVRNS/DDNS Set DVRNS/DDNS DVRNS/DDNS > DVRNS/Dashboard Register DVRNS/Dashboard account. Figure 5-38 NETWORK > DVRNS/DDNS > DVRNS/Dashboard Table 5-39 NETWORK > DVRNS/DDNS > DVRNS/Dashboard Item and Description Name Function DVRNS Register DVRNS account ▪ ID: Enter DVRNS ID (default: MAC address of the unit) ▪...
  • Page 62 DVRNS/DDNS > DDNS Set the DDNS site for remote users to access in networking. Figure 5-39 NETWORK > DVRNS/DDNS > DDNS Table 5-40 NETWORK > DVRNS/DDNS > DDNS Item and Description Name Function DDNS Site Select DDNS site Host Name Enter the host name.

  • Page 63: E-Mail

    5.8.3 E-Mail Set the email server to send email on the occasion of event. Figure 5-40 NETWORK > E-Mail > E-Mail Table 5-41 NETWORK > E-Mail > E-Mail Item and Description Name Function Server Type Select SMTP server. ▪ gmail.com ▪...

  • Page 64: Notification Server

    5.8.4 Notification Server Notification Server > Notification Server Figure 5-41 NETWORK > Notification Server > Notification Server Table 5-42 NETWORK > Notification Server > Notification Server Item and Description Name Function Notification Server Select/deselect whether to use Notification Server. Type Select TCP or UDP Protocol.
  • Page 65 Figure 5-42 NETWORK > Notification Server > Notification Message Table 5-43 NETWORK > Notification Server > Notification Message Item and Description Name Function Deleted registered notification message. Notification message edit window pop-up. Camera channel. Event Display event type as Motion, Alarm, Video Loss. Message Display notification message.

  • Page 66: Webviewer

    Webviewer This chapter describes webviewer for monitoring videos through a PC in remote mode. Table 6-1 System Requirement for Webviewer Item Recommended Minimum Microsoft Ⓡ Windows Ⓡ 10 x86(64bit) Microsoft Ⓡ Windows Ⓡ XP Home SP3 (Home Premium, Professional, Ultimate) Microsoft Ⓡ...
  • Page 67 For using Viewer, users need to download Java. The way to download is shown as follows: In case of selecting Viewer(Internet Explorer) Click Viewer. When Java download screen opens, down- load and install JAVA. Live images may be monitored.
  • Page 68 In case of selecting Viewer(Chrome) After click Viewer, .jnlp file can be down- loaded. Click Keep button. Click webviewer_chrome.jnlp. When Java download screen opens, down- load and install JAVA. Live images may be monitored.
  • Page 69 In case of selecting Setup Users can set the menu in similar ways with local connected monitor. Figure 6-1 Setup screen...

  • Page 70: Products Specifications

    Products Specifications Item 16CH HD Encoder VIDEO Video Input Channel Up to16ch (16 BNC, 4 IP configurable) Video Input Type AHD, TVI, CVBS, IP Video Input Resolution 1080p, 720p, 960H, D1(CVBS) Local Display Output 1 VGA, 1 HDMI, 1 BNC(Spot, CVBS) Local Display VGA, HDMI 1920x1080, 1280x720, 1024x768...
  • Page 71 16CH HD ENCODER...
