Vista VK-ENCODER4 Install And User Manual

Vip kit, four channel, composite to ip
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VK-ENCODER4 Install and user manual
Installation and user instructions for
Vista's VK-ENCODER4, four channel
Composite to IP Encoder

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VK-ENCODER4 and is the answer not in the manual?

Questions and answers

Related Manuals for Vista VK-ENCODER4

Summary of Contents for Vista VK-ENCODER4

  • Page 1 VK-ENCODER4 Install and user manual Installation and user instructions for Vista’s VK-ENCODER4, four channel Composite to IP Encoder...

  • Page 3: Explanation Of Graphical Symbols

    WARNINGS AND CAUTIONS: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMENT. CAUTION CAUTION RISK OF ELECTRNIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).

  • Page 4: Fcc Compliance Statement

    FCC COMPLIANCE STATEMENT FCC INFORMATION: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT.

  • Page 5: Important Safeguards

    IMPORTANT SAFEGUARDS 1. READ INSTRUCTIONS -- All the safety and operating instructions should be read before the appliance is operated. 2. RETAIN INSTRUCTIONS -- The safety and operating instructions should be retained for future reference. 3. CLEANING -- Unplug video monitor or equipment from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
  • Page 6 feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug. 10. POWER CORDS -- Do not allow anything to rest on the power cord. Do not locate video monitor or equipment where the cord will be abused by persons walking on it.

  • Page 7: Table Of Contents

    TABLE OF CONTENTS 1. Product Introduction ........................1  1.1 Components .......................... 1  1.2 NETWORK VIDEO SERVER’S External View and Port Description ........1  1.2.1 Front View ........................1  1.2.2 Back View ........................2  1.2.3 Side View........................2  1.2.4 Top View........................3  2.
  • Page 8 2.8 Power Connection ......................... 8  2.9 Encoder 4 fixing points ......................8  3. Operation by Web Browser ......................9  3.1 Connecting to the Encoder by Web Browser ................. 9  3.2 Real-Time Monitoring ......................9  3.3 ENCODER Setting....................... 11  3.3.1 Video Setting ......................11  3.3.2 Live View Setting .......................

  • Page 10: Product Introduction

    1. Product Introduction The Vista VK-ENCODER4 is a four channel composite to IP encoder. This will take four standard coax composite video signals and convert them to IP, allowing the image to be viewed remotely over a network. The Encoder also has Telemetry, Alarm and Audio capabilities.

  • Page 11: Back View

    1.2.2 Back View 5: Power Indicator 9: LAN Operation Check LED 6: Power Connector 10: LAN Connection Check LED 7: Alarm Input / Output 11: RJ-45 Connector 8: Analog Camera Output BNC Connector 1.2.3 Side View...

  • Page 12: Top View

    1.2.4 Top View...

  • Page 13: Encoder4 Installation

    2. Encoder4 Installation 2.1 Installation Order Ensure all cables are connected to the Encoder prior to power up, including Network, Alalrms, Audio and Telemetry. 2.2 Network Connection If connecting directly to a PC, use a Crossover cable. If connecting to a hub/switch use a direct patch cable.
  • Page 14 2.2.1.1 Web button Select network device and click the ‘WEB’ button. Users enter a network device IP directly. 2.2.1.2 IP Setting button Select network device and click the ‘IP Setting’ button. Select Ethernet Adapter and users enter a network device IP directly.

  • Page 15: Maintenance

    2.2.2 Maintenance Select network device and click the ‘Maintenance’ tab. Select maintenance tab and click the ‘Submit’ button. Restart: Restarts the network device. Userset: Initialise a user setting value of audio/video, alarm, etc. Restore: Restore all the values except a network-related setting to a basic value. Default: Restore all the setting values to a basic value.

  • Page 16: Analog Camera Connection

    2.3 Analog Camera Connection Analog Camera Input BNC Connector 4 analogue cameras can be connected via coax to the BNC connecters on the side of the Encoder. 2.4 Analog Monitor Connection Analogue Camera Output BNC Connector An analogue monitor can be connected to the video out to display the inputs locally. 2.5 Audio Connection The Encoder enables users to send and receive audio through the input/output connectors.

  • Page 17: Rs-485 Connection

    2.7 RS-485 Connection RS-485 Connector for PTZ Camera Control The RS-485 telemetry connector can be used to out-put Vista Powerdome Protocol.. 2.8 Power Connection Power Connector The Encoder requires a stable power supply for normal operation. It uses a DC 5V / 4A PSU ( included in packaging ).

  • Page 18: Operation By Web Browser

    3. Operation by Web Browser 3.1 Connecting to the Encoder by Web Browser In order for video to be viewed across the Browser in is necessary for the correct Active-X components to be installed – These can be downloaded from the Internet if PC is connected to the Web or alternatively are available on the CD supplied with the product.
  • Page 19 If you change screen mode to “Quad”, you can watch the 4 input cameras on a single screen. When you set the screen mode to “Sequence”, a total of 5 screens including 4 respective channel and Quad screen are displayed. For more detailed settings, please see “3.3.2 Live View Setting – Sequence Mode”.

  • Page 20: Encoder Setting

    3.3 ENCODER Setting The Encoder setting is divided into video, live view, audio, alarm, PTZ, and system settings. And a detailed screen will be provided for each setting. 3.3.1 Video Setting For image settings, there are 6 divisions: Channel1, Channel2, Channel3, Channel4, Quad, and Sequence Channel Setting Setting method for Channel1 to Channel 4 are the same.
  • Page 21 Compression The amount of compression applied determines the quality of the picture. The default is 2000(Kbps). Note 1. A D1 resolution image with high compression will be of lower quality than a 160X128 image with low compression Note 2. A combination of Resolution and Compression determines the average file size of recorded images.
  • Page 22 Text Overlay Settings Allows On Screen Display of title etc. □ Enable Tick for the use of Text Overlay function. Content Enter characters for Text Overlay. Location Appoint a location for character reflection. MPEG4 Video Stream Frame rate Upon the real-time play, users should select a frame refresh rate per second. If the rate is high, the image will become smooth.
  • Page 23 Quad Setting Quad Mode allows 4 input images to be displayed on a single screen. These are set in the same way as the single channel video settings. Sequence Setting Sequence Mode shows 4 input images as an automatic sequential switching. These are set in the same way as the single channel video settings.

  • Page 24: Live View Setting

    3.3.2 Live View Setting Source Setting Set the channel by web browser-based connection and the allocated channel to BNC Out. Default Live View Set the channel by web browser-based connection. You can select one among the 5: Channel 1, Channel 2, Channel 3, Channel 4, and Quad Stream. The chosen screen is seen on the control screen as a basic one.
  • Page 25 BNC out Sequence Setting A sequence of all or any of the 4 inputs can be set up to be displayed via the BNC output or for the live view when connected via the network. Sequence Mode Setting □ Enable: Allow checking at time of an automatic screen switching function in operation. Use sequence mode in Live View Make it possible to see the automatic screen switching on the control screen.

  • Page 26: Audio Setting

    3.3.3 Audio Setting Basic Setting Users can use a microphone and speaker by using the audio function. Audio Setting □ Enable  Tick to activate the Audio function. Compression type Users can increase a transmission rate or enhance a tone quality by selecting an audio compression mode.
  • Page 27 Audio Input Source Users can select either MIC input or LINE input, but cannot use both at once. Input Volume Users can control the input volume by adjusting the microphone volume. Audio Output Output Volume Users can control the output volume of the speaker connected to the Network Video Server.

  • Page 28: Alarm Setting

    3.3.4 Alarm Setting This function enables user to configure the alarm input/output settings and event settings. Motion Setup Motion Detection is processed by splitting the screen into 64 areas. Each area can be selected by clicking with the mouse, and green point shown in the selected area. Green dots are active (will detect motion) clear blocks are inactive (will not detect motion) Applicable to each of the 4 channels and Quad screen.
  • Page 29 -Motion dwell time Sets up the event duration time when a motion occurs. This item can have a value between 0 ~ 6 seconds. When an event occurs, the motion icon at upper right of the screen blinks for the specified period.
  • Page 30 Alarm Out Setting When an Alarm event occurs (either from the alarm inputs or motion detection), this function enables users to receive an e-mail or image file sent to an FTP site.
  • Page 31 SMPT(E-mail) Setting □ Enable: Checks to activate the SMPT (E-mail) function. Sender: Enter an e-mail address to send a mail. Receiver list: Enter up to 10 e-mail addresses to receive a mail. E-mail test: Enter an e-mail address to test for sending a mail. Test button: Test for sending a mail with a value entered.
  • Page 32 Event Setup Alarm inputs can be generated via motion detection or either of the two physical alarm inputs on the Encoder. These events can be used to control the alarm out options, which include: the Alarm output port; sending of e-mails; sending of images to FTP servers; and sending domes to preset positions.

  • Page 33: Ptz Setting

    3.3.5 PTZ Setting Basic Control These buttons can be used to move the dome or to navigate within the dome setup menus. Click in the red area and the dome will move in relevant direction.
  • Page 34 -PTZ PAN / TILT Speed: It sets a speed when adjusting the PTZ Camera. The higher a value is, the faster a speed will be. Focus: Overrides auto focus. Moving the Zoom handle reactivates Auto Focus mode. Iris: Overrides auto iris. Moving the joystick reactivates Auto Iris mode.
  • Page 35 PTZ Setting □ Enable: Checks to activate the PTZ function. Protocol: If a PTZ Camera is to be installed select Vista485 option. Device ID: Setting PTZ Camera Address (ID) Com Port Setting Baud Rate: Setting PTZ Camera Baud Rate. (Default 9600 bps) Data Bits: Setting PTZ Camera Data Bits.
  • Page 36 MENU h, HOME HOME Ctrl CTRL PRST SCAN TOUR PTRN...

  • Page 37: System Setting

    3.3.6 System Setting Users Setting This Network Video Server’s Authority Policy 1. Anonymous User Access Permit Mode This mode enables any anonymous users to have an access to the Network Video Server monitor and set it. 2. Anonymous User Access Denial Mode Upon selecting this mode, the Network Video Server operates in two authority groups.
  • Page 38 User setting □ Enable anonymous viewer login: Check it when users want to use the Encoder with the user account. When using the user account, users have to try log-in at every access. Admin Setting User name: Enter a user name for the administrator use. Password: Enter the password for the administrator use.
  • Page 39 Modify User Information After selecting a user to be modified and changing its name and password, press the ‘modify’ button to save the settings. Delete User Account After selecting a user to be deleted, delete it by pressing the “Remove” button. Date &...
  • Page 40 Date & Time Current Time Indicate a current time. Date: Current day, month, and year. Time: Current time. Time zone Time Zone: Select a time zone to be used. □ Automatically adjust for daylight saving time changes: Check it if users are to apply DST. New Time Synchronize with computer time: Synchronize the time with that of a current user computer.
  • Page 41 Network Setting Setting in regard to network can be executed. Settings for IP, DNS, Host Name, Port, and Network traffic can be established, along with setting for DDNS and RTP. Basic Setting The Basic tab allows setting of: IP Addresses, DNS, Host Name, and Port. Bandwidth limitation through the Network Traffic section.
  • Page 42 IP address Configuration Obtain IP address via DHCP: Obtain an IP through the DHCP automatically. Use Following IP address: Users enter a Network Video Server IP directly. DNS Configuration Obtain DNS server address via DHCP: Obtain the DNS information through the DHCP. Use Following DNS server address: Users enter the DNS information directly.
  • Page 43 DDNS Setting Internet Dynamic DNS When using the high-speed Internet with the telephone or cable network, users can operate the Network Video Server even on the floating IP environment in which IPs are changed at every access. *Users should receive an account and password by visiting a DDNS service like http://www.dyndns.com/.
  • Page 44 RTP Setting (These settings are in place for future use and should not be changed) Settings for sending and receiving video and audio on a real-time basis. Stream RTP after camera start-up Enter a destination IP and Port to send movie data automatically through the RTP while the Network Video Server has booting.
  • Page 45 -Frame rate: Indicate a frame rate that is sent to the external extension storage when the multi stream works. Once the multi stream function is checked, the MPEG profile setting will be changed to the Advanced Simple Profile. RTSP/RTP settings Perform a multicast setting to send a video and audio to multiple users.
  • Page 46 Maintenance Maintain Server < Restart > Restart the Network Video Server. < Userset > Initialize a user setting value of audio/video, alarm, etc. < Restore > Restore all the values except a network-related setting to a basic value. < Default > Restore all the setting values to a basic value. Upgrade Server Bring out an upgrade file and click ‘Upgrade’...
  • Page 47 Backup Save a setting value that users enter to the Network Video Server, to a user PC. Restore Bring and apply the separately-saved set point from the Network Video Server. Program Support Information Troubleshooting When problems occur during operation, please consult with an installer. Server Report If its support is requested, please attach a server report.
  • Page 48 Log & Report Users can check the system log and server report. Logs Reports Logs Server Reports Parameter List Users can check the Users can check a Users can check a log for Network Video server report by parameter by clicking Server operation by clicking the <...

  • Page 49: Help

    Program Information 3.4 Help The Help information window will be provided as a popup window so that users can open and read it without a need for log-in. It will offer a description on setting and Help page by which users can manipulate the Video Server without a reference to the manual.

  • Page 50: Appendix

    4. Appendix 4.1 Troubleshooting If problems occur, verify the installation of the Encoder 4CH with the instructions in this manual and with other operating equipment. Isolate the problem to the specific piece of equipment in the system and refer to the equipment manual for further information. PROBLEM AREA TO CHECK Verify that power is connected to all pieces of equipment in the...

  • Page 51: Product Specifications

    4.3 Product Specifications Video Resolution D1 (NTSC : 720 X 480, PAL : 720 X 576) VGA (NTSC : 640 X 480, PAL : 640 X 480) CIF (NTSC : 352 X 240, PAL : 352 X 288) QCIF (NTSC : 160 X 112, PAL : 176 X 144) Frame rate Max 30 fps @ D1 resolution Video compression...
