Before You Begin Read these instructions before installing or operating this product. Note: This installation should be made by a qualified service person and should conform to local codes. This manual provides installation and operation information. To use this document, you must have the following minimum qualifications: A basic knowledge of CCTV systems and components A basic knowledge of electrical wiring and low-voltage electrical connections...
Page 4
time to time without prior notice. WARNINGS AND CAUTIONS: To reduce the risk of fire or electric shock, do not insert any metallic objects through the ventilation grills or other openings on the equipment.
IMPORTANT SAFEGUARDS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. 8.
Overview This chapter describes device overview, components and their terms and features. This product is a device that displays images transmitted from an IP camera on and HDMI monitor. The device features include the following: Convenient UI from user’s viewpoint ▪...
Package Contents The device package contents consist of the following: Note Please check all components involved. Table 1-1 Package contents Name Name Decoder Mounting Bracket DC 12V Adaptor Bracket fixing screw Quick guide Program CD Decoder Description Each part is listed in the below: Figure 1-1 Name and Connection of each front section Table 1-2 Name and Function of each front section Name...
Page 9
Figure 1-2 Name and Connection of rear section Table 1-3 Name and Function of rear section Name Function NETWORK Network connector for IP Camera and CMS. AUDIO OUT Audio output port. CVBS CVBS(Spot Video) output port. HDMI HDMI output port. ALARM OUT Alarm output connector.
Installation You can fix the product on the wall using the supplied bracket. Refer to the drawing below for the hole position of the bracket. Figure 2-1 Dimension Starting System Power supply begins with system operation as follows: 1 Switching on initialize with below icons in order. 2 With buzzer sounds, the start screen is presented.
Quick Setup Select to Run for easy installation. 2.2.1 Account 1 Set ID and Password. ▪ Default ID/Password is admin/admin. Note ▪ Change the password for security. VK2-4KENCODER Quick Start guide V2.0...
2.2.2 System How to set the system of Easy Installation: 1 Set each item in System setting screen. Language: Select system language. Device Name: Enter the device name. Keyboard ID: Not Used HDMI: Set resolution of a monitor connected to the device. ...
2.2.3 Network How to set the network of Easy Installation: 1 Set each item in Network setting screen. WAN Port: Select whether to use static IP or dynamic IP. IP Address, Subnet Mask, Gateway, DNS, Port, and RTSP port server: As for dynamic IP, enter ...
2.2.5 Easy Installation Wizard 1 Select to run Easy Installation every time when the system start. 2 Press Save button to save set value and end Easy Installation. VK2-4KENCODER Quick Start guide V2.0...
Live Screen Configuration UI screen is configured like below figure. Figure 3-1 UI Screen Configuration Table 3-1 Items and Description of UI Screen Configuration Item Description Live screen Show live video of connected cameras. Quick menu Clicking the right button of a mouse displays Quick menu. See “3.4 Quick Menu”...
Icons in Live screen Each icon in the live screen displays a present setting status or a function. UI screen consists of like below. Chosen live screen is marked as a blue frame; mouse-located live screen is marked Note as yellow one. Figure 3-2 Live screen icon Table 3-2 Live screen icon and its description Icon...
Quick menu This chapter depicts Quick menu when users click the right button of the mouse in live screen. Figure 3-3 Quick menu Table 3-3 Quick menu Item and Description Item Description Screen Mode Selecting the partition mode of live screen. (Full, 2X2, 1+7, 3X3, 2+8, 4x4, PIP and Save Sequence) User can change the channel display order by pressing and holding the screen.
3.2.1 Channel Assign Users can assign the channel. Figure 3-4 Channel Assign Table 3-4 Camera Registration Item Description Search the device registered. Local Display registered image list. Display media file list. Drag & drop the desired media file. Drag the screen and drop it on the AVI to unregister the selected media file. Displayed registered device list.
Setup menu This chapter describes Setup menu. Figure 4-1 Setup menu Selecting the menu opens the setting screen. Setup screen is available to click Setup in Quick menu by clicking the right button of Note the mouse. Table 4-1 Setup menu Item and Description Item Description SYSTEM...
Web Setup Log In Enter ID and Password. Figure 5-1 Web Setup > Log In Table 5-1 Web Setup > Log In Item and Description ▪ Default ID/Password is admin/admin. ▪ Note Change the password for security. ▪ Max character length is 12c. VK2-4KENCODER Quick Start guide V2.0...
General buttons in Setup menu This section depicts General buttons in Setup menu. Figure 5-2 General buttons in Setup menu Table 5-2 Item and Description of General buttons in Setup menu Item Description Save Save the set content. Cancel Cancel the set value. Default Reverse changed setting value to default in factory.
