Furniture Values International aspenhome I240-400-RIV Assembly Instructions Manual

aspenhome
ah
ITEM NO: I240-400-RIV
I240-402-RIV
I240-403-RIV
Thank you for purchasing this quality product. Be sure to check all packing material carefully for
small parts that may come loose inside the carton during shipment.
I240-400
I240-402
HARDWARE LIST: I240-400
Description
No.
Bolt Ø5/16"*2-1/2"
A
Bolt Ø1/4"*1-1/2"
B
Lock Washer Ø5/16"
C
Flat Washer Ø5/16" *3/4"
D
E Allen Wrench 4mm
HARDWARE LIST: I240-402
Description
No.
Hanger Bolt Ø5/16"*3-3/8"
F
G Half Moon Washer 5/16"
Lock Washer Ø5/16"
H
Hex Nut Ø5/16"
I
J Hex Wrench 12mm
K Wood Screw M4*1-1/4"
BEFORE USING THIS PRODUCT PLEASE READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
Save these instructions for future reference.
Page 1/3
R
Queen Sleigh HB
Queen Rails
Queen FB
UNIT SHOULD BE INSTALLED BY 2 OR MORE PERSONS.
I240-403
Quantity
Sketch
6 PCS
8 PCS
14 PCS
14 PCS
1 PC
Quantity
Sketch
8 PCS
8 PCS
8 PCS
8 PCS
1 PC
8 PCS
FOR INDOOR USE ONLY
MADE IN VIETNAM
ASSEMBLY INSTRUCTIONS
All Beds need to be set up in the exact final
location so that after full assembly it will not
need to be moved. Moving the bed will cause
the support legs to move out of perpendicular
(90 degree), weaken the support system, and
may allow the bed to collapse.
TOOLS REQUIRED (NOT PROVIDED)
PHILLIPS SCREWDRIVER
COMPONENTS LIST: I240-400
Description
No.
1 Headboard
Left Leg
2
Right Leg
3
4 Wood Stretcher
Center Support Leg
5
COMPONENTS LIST: I240-402
Description
No.
1 Bed rails
2 Slats
COMPONENTS LIST: I240-407
Description
No.
1 Footboard
Support Leg (for slats)
2
Quantity
Sketch
1 PC
1 PC
1 PC
1 PC
1 PC
Quantity
Sketch
2 PCS
4 PCS
Quantity
Sketch
1 PC
4 PCS
05-31-2017
