Daikin RE09HV2S Removal Procedure page 9

Outdoor unit

Table Of Contents

Advertisement

Si01-882

Step

Release the fan motor

7

lead wire from the

hooks.

Remove the 4 screws

8

and remove the fan

motor.

Removal Procedure

Procedure

Fan

motor

Removal of Outer Panels / Fan Motor

Points

(R15234)

(R15235)

7
