Daikin RE09HV2S Removal Procedure page 10

Removal of Outer Panels / Fan Motor
Step
4. Remove the right side
panel.
Remove the 3 screws
1
and disconnect the
connecting wire.
Remove the screw and
2
remove the wire clamp.
Lift up and remove the
3
guard net.
Remove the 2 screws
4
on the rear side.
8
Procedure
Wire
clamp
Guard net
Connecting
wire
(R15377)
(R8284)
(R15237)
Si01-882
Points
Removal Procedure
