Accessories

Parts
NOTE:
All the illustrations in this manual are for
explanation purpose only. Your air conditioner
may be slightly different. The actual shape shall
prevail.They are subject to change without
notice for future improuement.
Mobile air-conditioner air louver notes:
1. With automatic wind sweep function mod-
els, the air louver opening angle can not
be less than automatically wind smallest
outlet angle when use it.
2. No automatic wind sweep function models,
air louver minimum opening angle: from air
louver closed state breaking up 5 grid, air
louver opening angle can not be less than
the minimum open angle when use it.
Unpacking Inspection
• Open the box and check unit in area with
good ventilation (open the door and win-
Name of Accessories
Adaptor A, Exhaust duct, Adaptor B(flat mouth)
Window Slider Kit(#)
Type A Screws(#)
Type В Screws(#)
Security bracket(#)
Type A foam seal(adhesive)(#)
Type В foam seal(non-adhesive)(#)
Adaptor B(round mouth)(#), Wall exhaust
Adaptor(#)
Drain hose
Remote controller and Battery
Expansion screw sleeve(#),
Type C Screws(#)
dow) and without ignition source.
Note: Operators are required to wear anti-
static devices.
• It is necessary to check by professional
whether there is refrigerant leakage before
opening the box ; stop installing the air
conditioner if leakage is found.
• The fire prevention equipment and anti-
static precautions shall be prepared well
before checking.Then check the refriger-
ant pipeline to see if there is any collision
traces, and whether the outlook is good.
Safety Principles for Installing Air Conditioner
• Fire prevention device shall be prepared
before installation.
• Keep installing site ventilated.(open the
door and window)
• Ignition source, smoking and calling is not
allowed to exist in area where R290 refrig-
Air conditioner portable
Qty.
1 set
1 pc
2 pc
6 pc
1 pc
2 pc
1 pc
1 set
1 pc
1 pc
4pc
4pc
