STEP ONE

Place radius bar on the ground in the desired location.

Note: The end of the radius bar with the larger peg will be

the end on which the sweep gate will hinge.

Ensure tubing on sweep gate arch has not been

compromised during shipping. Remove any "dimples"

that may keep tube from sleeving over peg.

**Remove the attachment rods from

hinge side of sweep gate arch and

set aside for later use.

**Attachment rods are to be used to attach a squeeze chute, palpation cage, or additional alley panels.

Slide the second curved panel over the small peg on the radius bar and attach it to the 1st curved panel.

Slide the sweep gate arch (which contains the sweep gate)

over the larger peg on the radius bar.

Attach one of the curved panels to the sweep gate arch.

SETUP INSTRUCTIONS

VALUE 90 SWEEP TUB

90ST

Table of Contents

Do you have a question about the VALUE 90 SWEEP TUB 90ST and is the answer not in the manual?

Page 1 SETUP INSTRUCTIONS STEP ONE Place radius bar on the ground in the desired location. VALUE 90 SWEEP TUB Note: The end of the radius bar with the larger peg will be the end on which the sweep gate will hinge. 90ST STEP THREE Slide the sweep gate arch (which contains the sweep gate)
