Installa�on -
Installa�on Using Mount Plate
Template Sheet
2
3
4
5
6
7
8
9
Disassemble the camera. See the sec�on 'Installa�on -
1
Disassemble the camera' for details.
Using the template sheet, make the cabling hole on
2
the wall/ceiling.
A�er passing the cables through the hole, fix the
3
mount plate on the template sheet.
Connect the network cable and power cable
4
respectively.
See the sec�on 'Installa�on - Cabling' for details.
Put the Lan cable into (a), then (b) will be assembled to (a)
�ghtly. As a final step, (c) need to be assembled to (b)
without making any space.
b
a
Fix the bo�om case on the mount plate. Press 3 bezels
5
on bo�om case of camera �ll it sounds snap to lock
the camera to the mount plate.
To achieve desired view direc�on and orienta�on,
6
rotate 3-axis gimbal. To fix the se�ng, �ghten the �lt
stopper screw.
A�ach the dome cover to the bo�om case.
7
Detach the protec�on film from the dome cover.
8
c
