Installa�on -
Installa�on
Template Sheet
2
2
3
3
4
5
6
7
Disassemble the camera. See the sec�on
1
'Installa�on - Disassemble the camera' for
details.
2
Using the template sheet, mark and drill the
necessary holes.
3
Connect the network cable and power cable
respec�vely. See the sec�on 'Installa�on -
Cabling' for details.
Put the Lan cable into (a), then (b) will be assembled to (a)
�ghtly. As a final step, (c) need to be assembled to (b)
without making any space.
a
Once removing the rubber stopper, fix the bo�om case
4
on the ceiling.
To achieve desired view direc�on and orienta�on,
5
rotate 3-axis gimbal. To fix the se�ng, �ghten the �lt
stopper screw.
A�ach the dome cover to the bo�om case.
6
Detach the protec�on film from the dome cover.
7
8
c
b
