VA RS IT Y SERIES
6240M / MEDICAL LEG EXTENSION / LEG CURL
6240M
862-118 Leg Curl / Extension
Rev 1.2
July 23, 2013
Die lines. Do not print.
Black
Pantone 4715C
Pantone 719C
Pantone 1795C
Pantone 7409C
Pantone 7461C
Background Greys
85% Black
70% Black
Size:
93 x 311 mm
3.7 x 12.2 in
MAINTENANCE CHECKLIST
ACTION
Clean Upholstery *
Inspect Cables
Stretches
Clean Guide Rods
Inspect Hardware
Leg
Inspect Frame
Clean Machine
Extension
Clean Grips *
Lubricate Guide Rods †
For easy entry, adjust the upper pad into the
* Upholstery & Grips should be cleaned with a mild soap and
highest position. Set the seat to Leg Extension
water or a non-ammonia based cleaner.
position with adjustment under seat. Adjust tibia
pad to rest in the top crevice of the ankle.
† Guide rods should be lubricated with Teflon based lubricant. Apply
the lubricant to a cotton cloth and then apply up and down the
guide rods.
Start Finish
PRODUCT SPECIFICATIONS
TECH SPECS
Maximum User Weight
Maximum Training Weight
Product Weight
Overall Dimensions
LegCurl
(L x W x H)*
Weight Horn Diameter
(Weight Plate Storage)
For easy entry, adjust the upper pad into the
* Ensure a minimum clearance width of 914 mm / 36" for access
highest position. Set the seat to Leg Curl position
with adjustment under seat. Adjust ankle pad to
rest above the heel in the back cradle of the
ankle. Lower upper pad to top of thighs.
WARRANTY
Valid in USA only
Frame (not coatings) *
Start Finish
Weight stacks
Pulleys
Pivot bearings
Any items not specified
Labor (excludes upholstery/cables/grips)
Upholstery/cables/grips/springs
Part # 862-118
* Frame is defined as the welded metal base of the unit and does
not include removable parts.
FREQUENCY
Daily
Daily
Monthly
Monthly
Bi-Annually
As Needed
As Needed
As Needed
159 kg / 350 lbs.
96 kg / 212 lbs.
231 kg / 510 lbs.
147 x 119 x 178 cm /
58" x 47" x 70"
47.63 mm / 1.875"
to and passage around MATRIX strength equipment.
10 years
5 years
5 years
5 years
3 years
3 years
1 year
Rev 1.1 / 2012.02.05
