Summary of Contents for Gyration CYBERVIEW 411B-TAA
- Page 1 Quick Start Guide CYBERVIEW 411B-TAA 4 MP Outdoor Intelligent Varifocal Bullet Camera Other Language www.gyration.com...
- Page 2 Waterproof Requirements Please waterproof cables in accordance with the following instructions. User shall assume all responsibility for device damage caused by water due to improper waterproof measures. NOTE! ⚫ Before you start, connect all the needed cables and cut off the copper wires for the cables that you don't use.
- Page 3 Tighten Tighten Tighten Waterproof tape Wrap the unused cables together into a bundle 3. Install the supplied waterproof components to the network cable in sequence. CAUTION! You need to mount the rubber ring onto the network cable interface first. 4. If your camera has a DC cable and you will not use it, insert the plug into the interface.
-
Page 4: Packing List
Packing List Contact your local dealer if the package is damaged or incomplete. The attachments may vary with models, please see the actual model for details. Name Unit Camera Waterproof components （1） Screw components （2） Mount accessory （3） User manual Remarks: * means optional and supplied with certain models only. -
Page 5: Maintenance
⚫ Do not aim the lens to any strong light source such as the sun or an incandescent lamp. It may cause permanent damage to the lens. ⚫ During transportation, special attention is required to protect the transparent dome cover from friction, scratch and stain, etc. Do not remove the protective film from the cover until mounting is finished. -
Page 6: Mount Your Camera
Audio output Sun shield Audio input Alarm output Lens Alarm input Power interface (DC 12V) IR LED Network Mount Your Camera (Optional) Insert the Micro SD Card For cameras that support Micro SD, you need to insert the Micro SD card after opening the bottom cover of camera. - Page 7 Paste the installation positioning sticker on the wall and align the cross center to the hole on the wall. Paste the installation positioning sticker on the wall and align the Lead the cables across the hole on the wall. cross center to the hole on the wall. Lead the cables across the hole on the wall.
- Page 8 Loosen the hex fillister-head screw using a 4# hex L-key to avoid damaging the universal joint. Hex fillister-head screw 4# Hex L-key Mount the camera onto the wall and connect all cables. Lead tapping screws through the guide holes in the base and fix them to the wall by using a screwdriver.
-
Page 9: Access Your Camera
Startup After you have installed the device, connect one end of the power adapter (purchased separately) to power supply, and then connect the other end to the power interface to start up the device. Access Your Camera Open your Web browser, enter the camera's IP address in the address bar, and then press Enter. -
Page 10: Copyright Statement
Disclaimer and Safety Warnings Copyright Statement No part of this manual may be copied, reproduced, translated or distributed in any form by any means without prior content in writing from our company (referred to as us hereafter). The product described in this manual may contain proprietary software owned by our company and its possible licensors. -
Page 11: Network Security
and recommendations in this manual are presented without warranty of any kind, expressed or implied, including, but not limited to, merchantability, satisfaction with quality, fitness for a particular purpose, and noninfringement. ⚫ Users must assume total responsibility and all risks for connecting the product to the Internet, including, but not limited to, network attack, hacking, and virus. - Page 12 ⚫ Choose username and password discretely: Avoid using the username and password of your social media, bank, email account, etc, as the username and password of your device, in case your social media, bank and email account information is leaked. ⚫...
-
Page 13: Regulatory Compliance
⚫ Use a UL certified power supply that meets LPS requirements if an adapter is used. ⚫ Use the recommended cordset (power cord) in accordance with the specified ratings. ⚫ Only use the power adapter supplied with your device. ⚫ Use a mains socket outlet with a protective earthing (grounding) connection. ⚫... - Page 14 to cause harmful interference in which case the user will be required to correct the interference at his own expense. LVD/EMC Directive This product complies with the European Low Voltage Directive 2014/35/EU and EMC Directive 2014/30/EU. WEEE Directive–2012/19/EU The product this manual refers to is covered by the Waste Electrical & Electronic Equipment (WEEE) Directive and must be disposed of in a responsible manner.
