- Page 1 Quick Start Guide CYBERVIEW 411T-TAA 4 MP Outdoor Intelligent Varifocal Turret Camera Other Language www.gyration.com...
- Page 2 Waterproof Requirements Please waterproof cables in accordance with the following instructions. User shall assume all responsibility for device damage caused by water due to improper waterproof measures. NOTE! ⚫ Before you start, connect all the needed cables and cut off the copper wires for the cables that you don't use.
- Page 3 Tighten Tighten Tighten Waterproof tape Wrap the unused cables together into a bundle 3. Install the supplied waterproof components to the network cable in sequence. CAUTION! You need to mount the rubber ring onto the network cable interface first. 4. If your camera has a DC cable and you will not use it, insert the plug into the interface.
-
Page 4: Packing List
Packing List Contact your local dealer if the package is damaged or incomplete. The attachments may vary with models, please see the actual model for details. Name Unit Camera Waterproof components （1） Screw components （2） Mount accessory （3） User manual Remarks: * means optional and supplied with certain models only. -
Page 5: Maintenance
⚫ Do not overbend the cables during the installation, otherwise, poor cable contact may cause malfunction. ⚫ When connecting to an external interface, use an existing connection terminal, and ensure that the cable terminal (latch or clamp) is in good condition and properly fastened. -
Page 6: Cable Connection
129mm 5.1" Type B 129mm 5.1'' Cable Connection The appearance and tail cable may vary with device model. Type A... - Page 7 Network Type B Network 1. Bottom ring 2. Housing 3. Mic 4. Lens 5. Power interface(12 VDC) 6. Ethernet interface...
-
Page 8: Mount Your Camera
NOTE! Use a pin to press and hold the Reset button for about 15 seconds to restore factory default settings. Perform this operation within 10 minutes after the device is powered on or the reset will fail otherwise. Mount Your Camera You can adopt ceiling mount or wall mount and purchase hardware accessories by yourself. - Page 9 Loosen the fixing screw, then remove the housing. Loosen the fixing screw, then turn the housing to the position shown in figure to remove it. Connect the cable and then secure the bottom ring. Connect cable and protect it with waterproof tape (Optional) insert a micro SD card...
-
Page 10: Access Your Camera
housing with the tail cable outlet on the base, attach the housing gently and then rotate clock/counterclockwise at least 8 degrees to lock.To ensure proper image display and illumination effects, make sure the mark (see figure above) is aligned with the screw hole when installation is complete. Adjust the monitoring direction. - Page 11 In the login page, enter the default username and password (admin/123456), then click Login. NOTE! ⚫ DHCP is enabled by default. If a DHCP server is used in your network, your camera may be assigned an IP address, and you need to use the assigned IP address to log in.
- Page 12 Disclaimer and Safety Warnings Copyright Statement No part of this manual may be copied, reproduced, translated or distributed in any form by any means without prior content in writing from our company (referred to as us hereafter). The product described in this manual may contain proprietary software owned by our company and its possible licensors.
-
Page 13: Network Security
and recommendations in this manual are presented without warranty of any kind, expressed or implied, including, but not limited to, merchantability, satisfaction with quality, fitness for a particular purpose, and noninfringement. ⚫ Users must assume total responsibility and all risks for connecting the product to the Internet, including, but not limited to, network attack, hacking, and virus. - Page 14 ⚫ Choose username and password discretely: Avoid using the username and password of your social media, bank, email account, etc, as the username and password of your device, in case your social media, bank and email account information is leaked. ⚫...
-
Page 15: Regulatory Compliance
⚫ Use a UL certified power supply that meets LPS requirements if an adapter is used. ⚫ Use the recommended cordset (power cord) in accordance with the specified ratings. ⚫ Only use the power adapter supplied with your device. ⚫ Use a mains socket outlet with a protective earthing (grounding) connection. ⚫... - Page 16 to cause harmful interference in which case the user will be required to correct the interference at his own expense. LVD/EMC Directive This product complies with the European Low Voltage Directive 2014/35/EU and EMC Directive 2014/30/EU. WEEE Directive–2012/19/EU The product this manual refers to is covered by the Waste Electrical & Electronic Equipment (WEEE) Directive and must be disposed of in a responsible manner.
