- Page 1 Quick Start Guide CYBERVIEW 410B-TAA 4 MP Outdoor Intelligent Fixed Bullet Camera Other Language www.gyration.com...
- Page 2 Waterproof Requirements Please waterproof cables in accordance with the following instructions. User shall assume all responsibility for device damage caused by water due to improper waterproof measures. NOTE! ⚫ Before you start, connect all the needed cables and cut off the copper wires for the cables that you don't use.
- Page 3 Tighten Tighten Tighten Waterproof tape Wrap the unused cables together into a bundle 3. Install the supplied waterproof components to the network cable in sequence. CAUTION! You need to mount the rubber ring onto the network cable interface first. 4. If your camera has a DC cable and you will not use it, insert the plug into the interface.
-
Page 4: Packing List
Packing List Contact your local dealer if the package is damaged or incomplete. The attachments may vary with models, please see the actual model for details. Name Unit Camera Waterproof components （1） Screw components （2） Mount accessory （3） User manual Remarks: * means optional and supplied with certain models only. -
Page 5: Maintenance
properly fastened. Ensure that the cable is not tense during mounting, with a proper margin reserved to avoid poor port contact or loosening caused by shock or shake. ⚫ During transportation, special attention is required to protect the transparent dome cover from friction, scratch and stain, etc. Do not remove the protective film from the cover until mounting is finished. -
Page 6: Mount Your Camera
DC12V IN Type C DC12V IN Mount Your Camera (Optional) Insert the Micro SD Card For cameras that support Micro SD, you need to insert the Micro SD card after opening the bottom cover of camera. Do not hot plug the Micro SD card after it is inserted. - Page 7 separately. The following part takes wall mount as an example. Pendant mount is similar to wall mount and therefore is omitted here. Locate the positions of the holes. Paste installation positioning sticker on the wall and align the cross center to the hole in the wall.
- Page 8 Screw the locknut to loosen the universal joint before attaching your camera to the wall. Locknut Mount your camera onto the wall and connect all cables. Lead tapping screws through the guide holes in the base and fix them on the wall by using a screwdriver.
-
Page 9: Access Your Camera
Adjust the monitoring direction. Adjust the opening of the universal joints as required. Rotate the spherical hinge of the camera to get the desired monitoring direction. Tighten the locknut. NOTE! The preceding installation process is for concealed installation, during which holes are punched on the wall and cables are penetrated into the wall. - Page 10 In the login page, enter the default username and password (admin/123456), then click Login. NOTE! ⚫ DHCP is enabled by default. If a DHCP server is used in your network, your camera may be assigned an IP address, and you need to use the assigned IP address to log in.
-
Page 11: Copyright Statement
Disclaimer and Safety Warnings Copyright Statement No part of this manual may be copied, reproduced, translated or distributed in any form by any means without prior content in writing from our company (referred to as us hereafter). The product described in this manual may contain proprietary software owned by our company and its possible licensors. -
Page 12: Network Security
and recommendations in this manual are presented without warranty of any kind, expressed or implied, including, but not limited to, merchantability, satisfaction with quality, fitness for a particular purpose, and noninfringement. ⚫ Users must assume total responsibility and all risks for connecting the product to the Internet, including, but not limited to, network attack, hacking, and virus. -
Page 13: Safety Warnings
⚫ Choose username and password discretely: Avoid using the username and password of your social media, bank, email account, etc, as the username and password of your device, in case your social media, bank and email account information is leaked. ⚫... - Page 14 ⚫ Use a UL certified power supply that meets LPS requirements if an adapter is used. ⚫ Use the recommended cordset (power cord) in accordance with the specified ratings. ⚫ Only use the power adapter supplied with your device. ⚫ Use a mains socket outlet with a protective earthing (grounding) connection. ⚫...
- Page 15 to cause harmful interference in which case the user will be required to correct the interference at his own expense. LVD/EMC Directive This product complies with the European Low Voltage Directive 2014/35/EU and EMC Directive 2014/30/EU. WEEE Directive–2012/19/EU The product this manual refers to is covered by the Waste Electrical & Electronic Equipment (WEEE) Directive and must be disposed of in a responsible manner.
