- Page 1 All manuals and user guides at all-guides.com GLASS DOOR BOTTLE COOLERS METOS MAXIGLASS NOVERTA 4146700,4146702, 4146704, 4146706, 4146708, 4146710, 4146712, 4146714, 4146716, 4146718, 4146720, 4146722, 4146724, 4146726, 4146728, 4146730, 4146732, 4146734 USER MANUAL 05.10.2012...
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com Table of Contents Safety precautions ............................3 1.1. Refrigerant ..............................3 1.2. During operation ............................3 1.3. After use ..............................3 Product description ..........................4 2.1. Type plate ..............................4 Installation ..............................5 3.1. How does it work ............................5 3.2. Installing the appliance ..........................5 3.3. -
Page 3: Safety Precautions
All manuals and user guides at all-guides.com METOS Maxiglass Noverta 05.10.2012 Safety precautions Prior to use check • whether the power supply is suitable for this product • that the plug and the lead are not damaged • ensure that the product is standing fi rmly and level Hold the plug when removing the plug from the socket. -
Page 4: Product Description
All manuals and user guides at all-guides.com 05.10.2012 METOS Maxiglass Noverta Product description 1 Type plate (inside) 3 Air in/outlet 5 Thermostat 2 Door 4 On/off switch 2.1. Type plate Type Refrigerant type + volume Power consumption Supply Rated current Climate classifi... -
Page 5: Installation
All manuals and user guides at all-guides.com METOS Maxiglass Noverta 05.10.2012 Installation Never install the refrigerator next to a heat source. 3.1. How does it work A refrigerator works by extracting heat from the space to be refrigerated and to release this in the sur- rounding area. -
Page 6: Power Supply
All manuals and user guides at all-guides.com 05.10.2012 METOS Maxiglass Noverta 3.4. Power supply • If this device cable is damaged it must be replaced with an original cable supplied by the producer. • In case of emergency: remove the plug lead from the socket. -
Page 7: Using The Appliance
All manuals and user guides at all-guides.com METOS Maxiglass Noverta 05.10.2012 Using the appliance 4.1. Prior to use • Clean the cabinet prior to use. For further details we refer to the maintenance section. • Leave the installation to stand for at least 2 hours before switching on the cabinet. -
Page 8: Temperature Setting
All manuals and user guides at all-guides.com 05.10.2012 METOS Maxiglass Noverta 4.2.1. Temperature setting • Push and immediately release the SET key, the set point will be shown. • Push and relase of SET key or wait for 5 sec. to return to the normal view. -
Page 9: Alarm Signals
All manuals and user guides at all-guides.com METOS Maxiglass Noverta 05.10.2012 4.2.5. Alarm signals Mess. Cause Output Room probe failure Compressor output according to Con e COF Evaporator probe failure Defrost end is timed Condenser probe failure Condenser temperature alarm is... -
Page 10: Cleaning
All manuals and user guides at all-guides.com 05.10.2012 METOS Maxiglass Noverta Cleaning • Before fi rst use the cabinet should be cleaned using water and a mild detergent. • Intensive use requires regular cleaning. • The MG1/** has a maintenance free condenser. -
Page 11: Troubleshooting
All manuals and user guides at all-guides.com METOS Maxiglass Noverta 05.10.2012 Troubleshooting Always remove the plug from the socket when carrying out cleaning and repairs The cabinet does not start. • Check the plug. • Restore the power supply by replacing a fault fuse or by using the on/off switch. -
Page 12: Technical Information
All manuals and user guides at all-guides.com 05.10.2012 METOS Maxiglass Noverta Technical information Power supply 220...240V /50 Hz / 1 Refrigerant R134a Cooling capacity 240W* (5,08CC) Thermostate Electronic Temperature range +1...18°C (set value +6°C) TYPE MG1/140RGCS MG1/140RG MG1/140LGCS MG1/140LG Power con-... - Page 13 All manuals and user guides at all-guides.com METOS Maxiglass Noverta 05.10.2012 TYPE MG1/150SD Power con- 173 W* sumption Volume 150 l Weight 58 kg llumination 1 x 3 W Capacity 2x 50 kg/ door tray Dims. 602x506x900/910 mm incl. feet...
- Page 14 All manuals and user guides at all-guides.com 05.10.2012 METOS Maxiglass Noverta TYPE MG1/315G MG1/315GCS MG1/315SD Power con- 316 W* 316 W* 316 W* sumption Volume 315 l 315 l 315 l Paino 103 kg 103 kg 103 kg llumination 1 x 4 W...
- Page 15 All manuals and user guides at all-guides.com METOS Maxiglass Noverta 05.10.2012 CE declaration of conformity for machines (directive 2006/42/EC, Appendix II, sub A) Manufacturer: Gamko BV Address: Mon Plaisir 75 4879 AL, Etten-Leur The Netherlands Herewith declares that Gamko product range type: •...
- Page 16 All manuals and user guides at all-guides.com...
