GENSD55
6,000 Surge Watts / 5,500 Running Watts
DIESEL GENERATOR INSTRUCTION MANUAL
CALIFORNIA PROPOSITION 65
WARNING: This product, or the exhaust from this generator, may contain chemicals, including lead, known to
the State of California to cause cancer and birth defects or other reproductive harm. Wash hands after
handling.
READ ALL INSTRUCTIONS AND WARNINGS BEFORE USING THIS PRODUCT.
This manual provides important information on proper operation & maintenance. Every effort has been
made to ensure the accuracy of this manual. These instructions are not meant to cover every possible
condition and situation that may occur. We reserve the right to change this product at any time without
prior notice.
IF THERE IS ANY QUESTION ABOUT A CONDITION BEING SAFE OR UNSAFE,
DO NOT OPERATE THIS PRODUCT!
DO NOT RETURN THIS PRODUCT TO THE RETAILER - CONTACT CUSTOMER SERVICE.
If you experience a problem, have questions or need parts for this product, visit our website at
http://www.proseriesbrand.com, or call Customer Service at 1-866-460-9436, Monday-Friday,
8 AM - 4 PM Central Time. A copy of the sales receipt is required.
FOR CONSUMER USE ONLY – NOT FOR PROFESSIONAL USE.
KEEP THIS MANUAL, SALES RECEIPT & APPLICABLE WARRANTY FOR FUTURE
REFERENCE.
SEEK THE ADVISE OF A LICENSED ELECTRICIAN FOR 120V / 240V WIRING
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Buffalo Tools GENSD55
Summary of Contents for Buffalo Tools GENSD55
- Page 1 2013 11 GENSD55 6,000 Surge Watts / 5,500 Running Watts DIESEL GENERATOR INSTRUCTION MANUAL CALIFORNIA PROPOSITION 65 WARNING: This product, or the exhaust from this generator, may contain chemicals, including lead, known to the State of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling.
- Page 2 GENSD55 6,000 Surge Watts / 5,500 Running Watts Diesel Generator FEATURES Generator Type : 6,000 Surge Watt • Diesel Fuel Only • Self Excited, 2 Pole, Single Phase • Voltage Regulator: Automatic (AVR) • Starting System: Electric Start • Engine Displacement: 418cc •...
-
Page 3: Table Of Contents
This warranty gives you specific legal rights, and you may have other rights that vary from state to state. This warranty gives you specific legal rights, and you may have other rights that vary from state to state. GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator... -
Page 4: Recognize Safety Symbols, Words And Labels
Additional regulations may apply if this generator will be used at a construction site. USE THIS GENERATOR ONLY OUTDOORS IN NON-CONFINED AREAS. DO NOT SECURE THE GENERATOR WITH A CHAIN OR ROPE, AS THIS WILL MAKE IT DIFFICULT TO MOVE IN AN EMERGENCY. GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator... - Page 5 • Do not use this generator in wet conditions (rain, snow, active sprinkler system, wet hands, etc.). Always keep this generator dry and operate it with dry hands. • Do not touch bare wires or outlets (receptacles). • Do not allow children or non-qualified persons to operate this generator. GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator...
- Page 6 You may choose to add a fuel conditioner to oxygenate the fuel and to help it run more efficiently. USE THIS GENERATOR ONLY OUTDOORS IN NON-CONFINED AREAS. DO NOT SECURE THE GENERATOR WITH A CHAIN OR ROPE, AS THIS WILL MAKE IT DIFFICULT TO MOVE IN AN EMERGENCY. GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator...
- Page 7 GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator...
- Page 8 In addition to the previously described safety information, familiarize yourself with all safety and hazard placards on this generator. GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator...
-
Page 9: Package Contents
PACKAGE CONTENTS The following items are supplied with this Model GENSD55 7,000 Surge Watts / 5,500 Running Watts Diesel Generator. Verify all items are included. STOP! If there are missing items, call 1-866-460-9436, Monday - Friday, 8 AM - 4 PM Central Time for customer service. -
Page 10: Preparing The Generator For Use
4. Securely tighten the fuel tank cap and immediately wipe up any spilled fuel with a dry cloth. Fuel Tank Capacity (gals /L) 3.3 Gallons Fuel Type Diesel Fuel GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator... -
Page 11: Ground The Generator
8. Move Circuit breaker to ON position. 9. Determine if you will use 120V or 120V/240V. Move the Toggle Switch left or right to the correct setting (Figure 6D) Figure 6B Figure 6C Figure 6D GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator... -
Page 12: Using The Generator
(1/3 HP) 1000 2000 window air conditioner (10000 BTU) 1200 1800 Confirm that the electrical device is switched off prior to window fan plugging it into this generator. GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator... -
Page 13: Dc Usage
• If battery acid is swallowed, drink large quantities of milk and immediately call a physician. Do not secure the generator with a chain or rope, which would prevent it from being moved in an emergency. GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator... -
Page 14: Stopping The Generator
Replace oil filter every year or 300 hours. Oil Filter Checking the Oil Level It is important to check the oil level in the engine crankcase before each use to ensure that there is a sufficient quantity. GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator... -
Page 15: Checking The Oil Level
When the engine crankcase is full, the oil level should reach the lower lip of the oil filling opening. Oil Capacity (fluid oz./L) 55.7 ounces (1.72 quart) Oil Type Recommended SAE 15W-40 Diesel Grade Oil Figure 8 Oil Cap Figure 8A Oil Drain Plug GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator... -
Page 16: Air Filter Maintenance
2 months to 1 year Empty the fuel tank. (See “Emptying the Fuel Tank” in the “Maintenance/Care” section.) 1 year or more Empty the fuel tank. (See “Emptying the Fuel Tank” in the “Maintenance/Care” section.) GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator... -
Page 17: Replacing The Carbon Brushes
Short in one of the connected devices. Disconnect any faulty or short-circuited electrical loads. Air filter is dirty. Clean or replace air filter. GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator... - Page 18 GENSD55 6,000 SURGE WATTS / 5,500 RUNNING WATTS DIESEL GENERATOR CONTROL PANEL DIAGRAM 1 DGG-H500-S01-E Ground pole 2 DGG-H500-S02-E Terminal - 3 DGG-H500-S03-E Terminal + 4.DGG-H500-S04-E Fuse 5 DGG-H500-S05-E Hour meter 6 DGG-H500-S06-E 120V AC socket 7.DGG-H500-S07-E 120V three hose socket...
- Page 19 PARTS DIAGRAM GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator...
- Page 20 GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator...
- Page 21 GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator...
- Page 22 GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator...
- Page 23 GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator...
- Page 24 GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator...
- Page 25 GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator...
- Page 26 GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator...
- Page 27 GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator...
- Page 28 Regulator – Rectifier Location of Regulator/Rectifier & Starter You can see the location of the starter and the regulator/rectifier for the 12V starting battery. The starter motor is located above the regulator/rectifier. GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator...
- Page 29 GENSD55 6,000 Surge Watts/5,500 Running Watts Diesel Generator...
