IN THE BOX
1
2
3
1. Main mower deck (with upper handle attached)
2. Lower handle (with rope guider fixed)
3. Grass collection bag 1pc
4. Side discharge chute 1pc
5. Plastic mulching plug 1pc
6. Lower handle fixing knob with nut M8 and arch-head bolts 2pcs
7. Quick release 2pcs
8. Cable clip 1pc
9. Plug wrench 1pc
4
6
7
5
8
9
48cm 140cm
self propelled
3
Petrol
Lawnmower
XSZ48B-SD
Important - Please read these instructions
fully before starting assembly
These instructions contain important information that will help
you get the best from your mower, ensuring it is assembled correctly
and safely. If you need help or have damaged or missing parts,
call the Customer Helpline on 0345 605 2067
QUICK START
GUIDE
AFTER SALES SUPPORT
0345 605 2067
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Spear & Jackson XSZ48B-SD
Summary of Contents for Spear & Jackson XSZ48B-SD
- Page 1 QUICK START GUIDE 48cm 140cm self propelled Petrol Lawnmower XSZ48B-SD 1. Main mower deck (with upper handle attached) 2. Lower handle (with rope guider fixed) 3. Grass collection bag 1pc 4. Side discharge chute 1pc Important - Please read these instructions 5.
- Page 2 ASSEMBLE OPERATE Do not start the engine before putting 500ml of SAE 30 oil into the engine. Unpack the lawn mower ensuring all parts are present Failure to do so will result in irreparable damage to the engine and invalidate your warranty.
