40V
Cordless
Lawnmower
S4037CR
Important - Please read these instructions
fully before starting assembly
These instructions contain important information that will help
you get the best from your mower, ensuring it is assembled
correctly and safely. If you need help or have damaged or
missing parts, call the Customer Helpline on 0345 605 2068
ORIGINAL
INSTRUCTION
MANUAL
AFTER SALES SUPPORT
0345 605 2068
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Spear & Jackson S4037CR
Summary of Contents for Spear & Jackson S4037CR
- Page 1 ORIGINAL INSTRUCTION MANUAL Cordless Lawnmower S4037CR Important - Please read these instructions fully before starting assembly AFTER SALES SUPPORT These instructions contain important information that will help 0345 605 2068 you get the best from your mower, ensuring it is assembled correctly and safely.
- Page 2 SPEAR & JACKSON SINCE 1760 For more than 250 years gardeners have enjoyed high quality performance and great results using Spear & Jackson tools. Our garden power tools combine continuous innovation and the latest in manufacturing technologies with a proud heritage. Each product is carefully designed with performance,comfort and durability firmly in mind,which has earned Spear &...
-
Page 3: Table Of Contents
CONTENTS Safety Information ........................4 Intended Purpose ..........................4 Warning Symbols ..........................4 Work Area Safety ..........................6 Electrical Safety ..........................6 Personal Safety ..........................7 Battery & Charger ..........................7 Operating Safety ..........................8 Maintenance and Storage Safety ....................12 Intended Use ............................ -
Page 4: Safety Information
SAFETY INFORMATION INTENDED PURPOSE The following warning symbols appear throughout this assembly manual and indicate the appropriate safety measures you should take when assembly and operating the mower. WARNING SYMBOLS Take extra care, beware Warning. Beware of of hazards. electric shocks. Do not use the machine Wait until all moving in the rain or leave it... - Page 5 SAFETY INFORMATION exist. Check your Local acquaint yourself with the Authority or retailer for machine, its correct usage recycling advice. and all safety requirements. • Keep this manual in a safe place so that the information Batteries contain Li-ion, is available at all times. waste batteries should li-ion be sorted for ecofriendly.
-
Page 6: Work Area Safety
SAFETY INFORMATION WORK AREA SAFETY increased risk of electric shock if your body is • Inspect the area where earthed or grounded. the machine is to be used and remove all objects • Do not expose Charger which can be thrown by to rain or wet conditions. -
Page 7: Personal Safety
SAFETY INFORMATION PERSONAL SAFETY facilities, ensure these are connected and properly • Stay alert, watch what used. Use of dust collection you are doing and use can reduce dust-related common sense when hazards. operating the machine. Do not use the machine while you are tired or under the BATTERY&... -
Page 8: Operating Safety
SAFETY INFORMATION OPERATING SAFETY screws or other small metal objects, that can make TRAINING a connection from one • Read the instructions terminal to another. Shorting carefully. Be familiar with the the battery terminals controls and the proper use together may cause burns of the machine. - Page 9 SAFETY INFORMATION machine. after any impact, check for signs of wear or damage • Before using, always and repair as necessary. visually inspect to see that the blade, blade bolt and • Always remove the battery the blade assembly are pack not worn or damaged.
- Page 10 SAFETY INFORMATION • Do not use the product if the instructions and with feet cord is damaged or worn. well away from the blade(s). • Warning! The cutting blade • Do not tilt the machine when may continue to move after switching on the motor, the product is switched off.
- Page 11 SAFETY INFORMATION • inspect for damage, potential risks of injury and damage remain. The • replace or repair any following dangers can arise damaged parts, in connection with the • check for and tighten any structure and design of this loose parts.
-
Page 12: Maintenance And Storage Safety
SAFETY INFORMATION MAINTENANCE AND STORAGE SAFETY with the relevant safety regulations. To avoid • Keep all nuts, bolts and danger, equipment must screws tight to be sure the only be repaired by qualified machine is in safe working technicians. condition. •... -
Page 13: In The Box
IN THE BOX PARTS Upper handle Upper cover of Rear wheel Cable clip grass collection bag Quick release lever Front wheel Safety button Lower cover of Lower handle Battery Switch Lever grass collection bag compartment cover Grass collector Battery Cutting height handle Carry Handle adjustment handle... -
Page 14: Assemble
ASSEMBLE Unpacking i. Unpack all parts and lay them on a flat, stable surface. ii. Remove all packing materials and shipping devices if applicable. iii. Make sure the delivery contents are complete and free of any damage. If you find that parts are missing or show damage do not use the product but contact the aftersales helpline within 28 days of purchase. - Page 15 ASSEMBLE Assemble the grass bag i. Insert the handle in the upper cover of grass bag. ii. Place the metal frame inside the grass collection bag, Make sure that these clips are fully secured to the metal frame. iii. Lift up the safety guard before assemble the grass bag. Hang the collection bag on the mower AFTER SALES HELPLINE 03456 052 068...
-
Page 16: Prepare
PREPARE Check battery capacity Push the power indicator to show remaining battery capacity. The battery is equipped with a charge-level indicator panel which indicates its’ charge condition. This charge-level indicator panel consists of 4 LEDs on the battery. Press and hold the charge indicator button on the battery to actuate the charge level indicator. - Page 17 PREPARE iii. The indicator lights on the charger show the charger status: Symbol Indicator lights Status charging paused red, flashing see instructions below. red, connected to continuous power supply green, charging flashing green, fully charged continuous The intelligent charger measures the charge level of the battery and charges the battery accordingly with the required current and voltage based on battery temperature and voltage.
- Page 18 PREPARE Fit the battery i. Lift the cover slide the battery along the rails and locks into position. ii. Insert the isolator key. Mowing tips • Verify that the lawn is free of stones, sticks, wires ,and other objects that could damage the lawn mower. •...
-
Page 19: Operate
OPERATE Switching on i. Press the button . ii. Pull the switch bar towards the handle and hold in position. Switching off Release the switch bar. Grass bag full indicator i. If the collection bag is empty or it is not full with grass, the grass full indicator will open. - Page 20 OPERATE Battery indicator panel • Battery indicator on the switch box can be used to indicate the battery status. Battery indicator • Push the press button to check on the battery status, 4 lights indicate a fully battery, 1 light indicates the battery Mode indicator need to be charged.
- Page 21 OPERATE Using as a Mulcher Do not attach the collection bag and the mulching plug at the same time. The mulching plug allows the grass clippings to be deposited back on the lawn during cutting. To install plug: i. Lift the safety flap and detach the grass collection bag.
-
Page 22: Maintenance
MAINTENANCE WARNING! Always switch the product off, disconnect it from the power supply and let the product cool down before performing inspection, maintenance and cleaning work! i. Keep the underbody and cutting blade clean and free of debris. Remove clippings from the discharge chute. ii. - Page 23 MAINTENANCE Storage • Switch the product off and disconnect from power supply. • Clean the product as described above. • To reduce storage space, the upper handle can be folded down, unscrew the wing nuts by approximately 6 revolutions. • We recommend using the original package for storing the product with a suitable cloth or enclosure to protect it against dust.
-
Page 24: Technical Data
Weight of charger 0.6kg Insulation protection of charger Battery pack Battery model 36LB2519 Rated voltage of battery Battery type Lithium-Ion Capacity of battery 2.5Ah Part number: 7366682(S4037CR) ACCESSORIES 211030014 Blade 211030102 Battery 111232114 Charger 211033123 211033125 Upper Quick release lever... - Page 25 TECHNICAL DATA Sound values Sound pressure level L : 83dB(A) Sound power level L : 92.1dB(A) Uncertainty K: 1.8dB(A) Guaranteed sound power level L : 96dB(A) Vibration values Hand arm vibration a : 3.369m/s² Uncertainty K: 1.69m/s² The sound values have been determined according to noise test code given in EN 60335-2-77, using the basic standards EN ISO 11201 and EN ISO 3744.
-
Page 26: Troubleshooting
TROUBLESHOOTING Suspected malfunctions are often due to causes that the user can fix themselves. Therefore, check the product using this section. In most cases the problem can be solved quickly. WARNING! Only perform the steps described within these instructions! All further inspection, maintenance and repair work must be performed by an authorised service centre or a similarly qualified specialist if you cannot solve the problem yourself! Gloves and appropriate protective clothing must be worn when performing these... - Page 27 TROUBLESHOOTING Fault Possible Cause Solution Area of cut (battery duration) Height of cut too low Increase height of cut and walk slower not large enough Grass too high Increase height of cut and walk slower Grass wet or damp Wait until grass is dry and walk slower Grass is dense Increase height of cut, walk slower...
-
Page 28: Warranty
WARRANTY If your device develops a fault, please don’t hesitate to contact our customer service department on 03456 052 068, the majority of problems can be solved directly on the phone. 1. These warranty terms cover additional warranty rights and do not affect your statutory warranty rights.
