Homewerks Worldwide H13L-421-CH Quick Start Manual

BATHROOM FAUCET WITH
PULL-DOWN SPRAY
H13L-421-CH – Polished chrome finish
H13L-421-BN – Brushed nickel finish
H13L-421-ORB – Oil rubbed bronze finish
PACKAGE AND HARDWARE CONTENTS
PART DESCRIPTION
A Faucet body
B Pop-up drain assembly
C Mounting nut
D
E
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble,
operate or install the product.
WARNING
• Protect your eyes with safety glasses when cutting or soldering water
supply lines.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare
parts with package contents list and hardware contents. If any part is missing or
damaged, do not attempt to assemble the product.
Contact customer service for replacement parts.
Estimated Assembly Time: 30 minutes
Tools Required for Assembly (not included): Adjustable wrench, thread sealant tape,
silicone
Need Help? Please call our toll-free line at (877) 319-3757 (8 am to 5 pm CST) for additional assistance or service.
Homewerks Worldwide, LLC • Lake Bluff, IL 60044 • www.homewerksww.com
QUANTITY
Clip
Weight
1
1
2
1
B
1
CAUTION
• If you solder the joints during installation, the seats, cartridges, and washers
must be removed before using a flame or the warranty will be voided on
these parts.
• Cover the drain to avoid losing parts.
Installations may vary depending on how the previous faucet was installed. Supplies
necessary for the installation of the faucet are not all included; however, they
are available wherever plumbing supplies are sold.
Prior to beginning installation, turn off the hot and cold water lines, then turn
on the old faucet to release built-up pressure. When installing the new faucet,
hand tighten the connector nuts. DO NOT OVERTIGHTEN. Connections
that are too tight will reduce the integrity of the system.
A
C
NSF 61
ADA
D
E
12-07-2018
