Product Specification Brief - A4Tech BatteryFREE NB-30D User Manual

Product specification brief

Mouse
Model name: NB-30D
Microprocessor: SN8P2602AP
Operating voltage: 3.3+ 5% V
Supply Power method: Electromagnetic Coupling
Current consumption:
(operating) MAX:25mA
Communication mode : Simplex
Duty Cycle: 240uS
Dimension(outside): 113 x 63 x 36 mm
weight: 77 gm
Transmission distance : Max:50mm(To Mouse pad distance)
Modulation Method: ASK
Modulation degree: Max: 15%
The Tracking Resolution: 800CPI
Micro Switch: Chock-per:1,000,000 Cycles
Number of Button/Wheel: 4 Button ,1 Wheel
Running life: 500 Miles
ration force in any direction: Max:100gf
Non-operating Vibration passed (10 to 300Hz at 2.0G)
5G 1/4 sine pulse, 11ms duration at any axis
(PASS)
Operating Shock
60G 1/4 sine wave, 11ms duration at any axis
( PASS)
Non-operating shock
Operating Vibration test passed (10 to 500Hz at 0.5G)
